ADJUSTMENT GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 11100 and is the answer not in the manual?

Questions and answers

Related Manuals for Kyocera 11100

Summary of Contents for Kyocera 11100

  • Page 1 ADJUSTMENT GUIDE...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction................................. 3 How to Read This Manual..........................4 Symbols Used in the Manuals........................4 Disclaimer................................4 Notes................................4 Machine Types............................... 5 Manuals for This Machine..........................6 About Printing Surfaces............................7 1. Adjustment Settings for Skilled Operators Displaying the [Adjustment Settings for Skilled Operators] Button..............9 Accessing Adjustment Settings for Skilled Operators..................12 Layout of Adjustment Settings for Skilled Operators..................
  • Page 4 Paper Presets in "Advanced Settings"......................99 Displaying the Paper Profile Version......................99 4. Details of Menu Items in Advanced Settings Menu Items and Functions..........................101 Setting Values..............................108 Paper Feed Adjustment..........................108 Paper Delivery Adjustment........................109 Image Position/Scaling Adjustment......................110 Line Speed Adjustment..........................116 Toner Adhesion Adjustment........................119 Transfer Adjustment...........................

  • Page 5: Introduction

    Introduction This manual contains detailed instructions and notes on the operation and use of this machine. For your safety and benefit, read this manual carefully before using the machine. Keep this manual in a handy place for quick reference.

  • Page 6: How To Read This Manual

    How to Read This Manual Symbols Used in the Manuals This manual uses the following symbols: Indicates points to pay attention to when using the machine, and explanations of likely causes of paper misfeeds, damage to originals, or loss of data. Be sure to read these explanations. Indicates supplementary explanations of the machine’s functions, and instructions on resolving user errors.

  • Page 7: Machine Types

    • Type 1: 9600 • Type 2: 11100 • Type 3: 13600 Certain types might not be available in some countries. For details, please contact your local dealer. Certain options might not be available in some countries. For details, please contact your local dealer.

  • Page 8: Manuals For This Machine

    Manuals for This Machine The following manuals are for skilled operators only. Adjustment Item Menu Guide This manual explains the items in [Adjustment Settings for Skilled Operators] and the advanced settings for custom paper adjustment in "Advanced Settings". Replacement Guide This manual explains how to replace the machine's components.

  • Page 9: About Printing Surfaces

    About Printing Surfaces Depending on the setting, printed copies are fed as follows: Side 1 is the surface of the paper printed during one-sided printing, or the surface of the first print during duplex printing. Side 2 is the surface of the paper printed on the back side of Side 1 during duplex printing. Single-sided printing: Printed side face down DSM008 A.
  • Page 10 Duplex printing DSM010 A. Side 1 B. Paper feed direction of Side 1 C. Side 2 D. Paper feed direction of Side 2...

  • Page 11: Adjustment Settings For Skilled Operators

    1. Adjustment Settings for Skilled Operators Displaying the [Adjustment Settings for Skilled Operators] Button To use the Adjustment Settings for Skilled Operators, you must first configure your machine's Administrator Authentication Management setting. Press the [User Tools] key on the control panel. CWW222 Press [System Settings] on the display.
  • Page 12 1. Adjustment Settings for Skilled Operators Press [Administrator Tools]. Press [ Next]. Press [Administrator Authentication Management]. Press [Machine Management].
  • Page 13 Displaying the [Adjustment Settings for Skilled Operators] Button Select [On] for "Admin. Authentication". Press [OK]. Press [Exit]. The [Adjustment Settings for Skilled Operators] button appears.

  • Page 14: Accessing Adjustment Settings For Skilled Operators

    1. Adjustment Settings for Skilled Operators Accessing Adjustment Settings for Skilled Operators Press [Adjustment Settings for Skilled Operators]. Press [Login]. Enter your login user name, and then press [OK]. If you are logging on as the administrator for the first time, enter "admin".
  • Page 15 Accessing Adjustment Settings for Skilled Operators Enter your login password, and then press [OK]. The Adjustment Settings for Skilled Operators appears.

  • Page 16: Layout Of Adjustment Settings For Skilled Operators

    1. Adjustment Settings for Skilled Operators Layout of Adjustment Settings for Skilled Operators This section explains how to use Adjustment Settings for Skilled Operators. DTJ001 1. Adjustment items are displayed in this area. Select the setting you want to specify or change. 2.

  • Page 17: Features Of The Displayed Items And Setting Operations

    Features of the Displayed Items and Setting Operations Features of the Displayed Items and Setting Operations The following operations are available for each adjustment item: • Value setting • Item setting • Executing • Display only Value setting Press [+] to increase the value, or [-] to decrease. Select [OK] to apply the new setting.
  • Page 18 1. Adjustment Settings for Skilled Operators Display only You can check the setting for the selected item.

  • Page 19: Notes On How Adjustment Settings Are Applied To Printed Copies

    Notes on How Adjustment Settings are Applied to Printed Copies Notes on How Adjustment Settings are Applied to Printed Copies The adjustment settings are applied to printed copies according to the settings specified for each paper tray, paper size, and paper weight. Depending on the adjustment setting, the same settings specified under different categories may be applied to printed copies concurrently.
  • Page 20 1. Adjustment Settings for Skilled Operators Settings for each paper size These adjustment settings can be specified for each paper size. The settings are applied only to printed copies of each paper size. • For information about the paper tray, paper thickness, and tray paper size settings that can be specified for a particular function, see the manual for the relevant function.

  • Page 21: Details Of Menu Items In Adjustment Settings For Skilled Operators

    Specify whether or not to detect multiple feeding of Detection] originals loaded in the Auto Document Feeder (ADF). *1 This is an internal function for adjusting skew correction and transfer timing. *2 This function is available for 11100 and 13600.
  • Page 22 2. Details of Menu Items in Adjustment Settings for Skilled Operators [Machine: Image Quality] For details about the following items, see page 34 "[Machine: Image Quality]". Item Description 0201 [Adjust Erase Margin With Adjust the mask width at the leading edge or trailing Feed Direction] edge of the image.
  • Page 23 Menu Items and Functions Item Description 0301 [Double Feed Detection] Specify whether or not to detect double feeding of paper. 0302 [When Double Feed is Specify how the machine behaves when it detects a Detected] double feed. 0304 [Skew Detection] Specify whether or not to detect paper skew.
  • Page 24 2. Details of Menu Items in Adjustment Settings for Skilled Operators [Machine: Maintenance] For details about the following items, see page 47 "[Machine: Maintenance]". Item Description 0502 [Execute Photoconductor Remove dust on the drum surface. Refreshing] 0503 [Unscrew/Screw-on Cap Screw on or unscrew the toner bottle cap. to Replace Toner Bottle] 0504 [Developer Fill]...
  • Page 25 Menu Items and Functions Item Description 0601 [Adjust Staple Position for Adjust the horizontal position of the booklet staples when Booklet] using Booklet Finisher SR5060. 0602 [Adjust Folding Position for Adjust the horizontal position of the folding when using Booklet] Booklet Finisher SR5060.
  • Page 26 2. Details of Menu Items in Adjustment Settings for Skilled Operators Item Description 0614 [Punch Skew Correction] Disable punch skew correction if jams or edge-folding problems occur particularly when punching lightweight paper using Finisher SR5050 or Booklet Finisher SR5060. 0615 [Z-fold Skew Correction] Specify how to correct skew (occurring during paper transport) when Z-folding with the folding unit.
  • Page 27 Menu Items and Functions *1 Guide for alignment of printed paper. Printed paper is centered by the right and left guides. [Finishing: Fold] For details about the following items, see page 76 "[Finishing: Fold]". Item Description 0701 [Half Fold Position (Multi- Adjust the fold position of half folded sheets when using sheet Fold)] the multi-folding unit.
  • Page 28 2. Details of Menu Items in Adjustment Settings for Skilled Operators Item Description 0902 [Paper Alignment in Adjust the width of the sub jogger when the high Stacker Tray Across Feed capacity stacker is installed. Direction 2] 0903 [Paper Alignment in Adjust the travel distance of the paper edge stopper Stacker Tray With Feed when the high capacity stacker is installed.

  • Page 29: Setting Values

    Setting Values Setting Values [Machine: Image Position] 0101: [Adjust Image Position With Feed Direction] Adjust the horizontal position of the print image. You cannot individually adjust the image position on sides 1 and 2. Side 1 Paper feed direction Default Left Right (Leading Edge)
  • Page 30 2. Details of Menu Items in Adjustment Settings for Skilled Operators • If the leading-edge margin on Side 1 of the paper is too narrow, paper jams may occur. • If the trailing-edge margin on Side 1 of the paper is too narrow, paper jams may occur when printing on the back side of paper during duplex printing.
  • Page 31 Setting Values Side 1 Paper feed direction Left Right Default (Leading edge) (Trailing edge) Bottom CEZ015 Press [+] to shift the image to the top. Press [−] to shift the image to the bottom. Side 2 Paper feed direction Left Right Default (Trailing edge)
  • Page 32 2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [Tray 1] -3.0 [Tray 2] [Tray 3] [Tray 4] [Tray 5] [Tray 6] [Tray 7] [2 Sided] [Tray T1] [Tray T2] [Tray T3] [Tray T4]...
  • Page 33 Setting Values 0104: [Adjust Registration Paper Buckle (Thick Paper)] Adjust the degree of paper arching at the registration gate when using paper of Paper Weight 5 to 8. By adjusting the degree of paper arching for relatively stiff thick paper, you can prevent image misalignment and paper skew.
  • Page 34 [Tray T4] 0106: [Select Test Pattern for Image Position Adjustment] This function is available for 11100 and 13600. Select the test image for adjusting the image position. If [Copy Image] is selected, the image scanned using the Auto Document Feeder (ADF) or exposure glass is printed.
  • Page 35 [Adjust Magnification With Feed Direction] 0108: [ADF Double Feed Detection] This function is available for 11100 and 13600. Specify whether or not to detect multiple feeding of originals loaded in the Auto Document Feeder (ADF). If [On] is selected, the machine stops printing and displays a message reporting a paper jam when it detects multiple feeding.

  • Page 36: [Machine: Image Quality]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators [Machine: Image Quality] 0201: [Adjust Erase Margin With Feed Direction] Adjust the mask width at the leading edge or trailing edge of the image. By increasing the mask width, you can increase the paper margin at the leading edge, or trailing edge of the paper.
  • Page 37 Setting Values 0202: [Adjust Image Density] Execute image density control manually. The machine adjusts the image density. This operation takes about 30 seconds during which a message appears on the control panel. Do not pull out the drawer while the message is being displayed. If the density does not change after applying this function several times, contact your sales or service representative.
  • Page 38 2. Details of Menu Items in Adjustment Settings for Skilled Operators • Increasing the toner adhesion might reduce fusibility, causing toner splatter or distorted text and thin lines. Default Max. Min. Setting Items Step Unit Value Value Value [Black] None 0205: [Adjust Line Width] Adjust the intensity of the laser for transferring image data to the drum.
  • Page 39 • Depending on the machine's other settings, changing this setting might increase the waiting time before a process is performed. Max. Min. Setting Items Default Value Step Unit Value Value [Temperature on 160 (13600) degree(s) Standby Mode] 155 (11100) [Temperature on 75 (13600) Low Power Mode] 160 (11100) [Temperature 175 (13600) Before Performing a...
  • Page 40 2. Details of Menu Items in Adjustment Settings for Skilled Operators • This setting is not effective for paper fed from paper trays with custom paper presets. For such paper, the value specified in 33: [Avoid Ppr Trns Shck Jitr: Fed Intvl Adj] in "Advanced Settings" takes precedence.

  • Page 41: [Machine: Paper Feed/ Output]

    Setting Values Setting Items Values Default Value [Productivity Priority] [On] [On] [Off] 0213: [Continuous Slip Sheet Feed Mode] Specify whether or not to temporarily stop imaging during continuous slip sheet feeding. Continuous slip sheet feeding causes the imaging unit to run idle, causing image problems including toner dispersion, scumming, streaks, uneven gloss, and gloss streaks.
  • Page 42 2. Details of Menu Items in Adjustment Settings for Skilled Operators The machine may not correctly detect double feeding when using special paper (two-ply paper such as release paper). In such a case, select [Off]. • This setting is not effective for paper fed from paper trays with custom paper presets. For such paper, the value specified in 04: [Double Feed Detection] in "Advanced Settings"...
  • Page 43 Setting Values Setting Items Values Default Value [When Double Feed is Detected] [Suspended] [Suspended After Ppr. Dvrsion.] [Suspended After Ppr. Dvrsion.] 0304: [Skew Detection] Specify whether or not to detect paper skew. If the machine detects a paper skew when [On] is selected, the machine will stop printing and display a message reporting a paper jam.
  • Page 44 2. Details of Menu Items in Adjustment Settings for Skilled Operators 0305: [Skew Detection Level] Adjust the permissible range of skew. By increasing the permissible range of skew, you can make the machine print without stopping for skews within the permissible range. This is enabled only if 0304: [Skew Detection] is set to [On].
  • Page 45 Setting Values • This setting is not effective for paper fed from paper trays with custom paper presets. For such paper, the value specified in 02: [Adjust Wide LCT Fan Level] in "Advanced Settings" takes precedence. Default Max. Min. Setting Items Step Unit Value...
  • Page 46 2. Details of Menu Items in Adjustment Settings for Skilled Operators • This setting is not effective for paper fed from paper trays with custom paper presets. For such paper, the value specified in 03: [Pickup Assist Setting] in "Advanced Settings" takes precedence. Setting Items Values Default Value...
  • Page 47 Setting Values Default Max. Min. Setting Items Step Unit Value Value Value [Tray 4: Wide LCT] 1000 millisecond(s) [Tray 5: Wide LCT] [Tray 6: Wide LCT] [Tray 4: LCT] [Tray 5: LCT] [Tray 6: LCT] [Tray 7] 0310: [Adjust Paper Curl] Specify the method for straightening curled sheets.
  • Page 48 2. Details of Menu Items in Adjustment Settings for Skilled Operators 0311: [Registration Jam Detection with Feed Direction] Specify whether or not to stop printing when the deviation in the feed direction exceeds the adjustable range (3 mm/0.1 inch) when feeding paper in the paper tray or duplex unit. If [On] is selected, an error message appears and the machine stops printing if the paper misalignment exceeds the adjustable range.

  • Page 49: [Machine: Maintenance]

    Setting Values Setting Items Values Default Value [Lower Jam Detection Strictness] [On] [On] [Off] [Machine: Maintenance] 0502: [Execute Photoconductor Refreshing] Remove dust on the drum surface. This operation takes about 4 minutes. Do not open the front covers during the operation. Setting Items Values [Execute Photoconductor Refreshing]...
  • Page 50 2. Details of Menu Items in Adjustment Settings for Skilled Operators 0505: [Developer Fill: Result] Display the result of filling developer. If the developer replenishment fails, check the displayed code and troubleshoot the problem accordingly. If countermeasures do not work or a code that is not on the list is displayed, contact your service representative.
  • Page 51 Setting Values 0507: [Developer Exhaust: Result] Display the result of discharging developer. If the developer discharge fails, check the displayed code and troubleshoot the problem accordingly. If countermeasures do not work or a code that is not on the list is displayed, contact your service representative.
  • Page 52 2. Details of Menu Items in Adjustment Settings for Skilled Operators Code Status Causes Solutions Developer setup failure • The developer bottle is Attach a new developer not attached to the bottle to the inlet, pull out outlet. the seal, and then try the operation again.
  • Page 53 Setting Values Setting Items Values [Developer] Press [OK] to apply the setting(s). [Photoconductor Unit] [Charge Unit] [Cleaning Unit for Photoconductor Unit] [Cleaning Unit for Intermediate Transfer Belt] [Transfer Unit] [Fusing Unit] [Cleaning Unit for Fusing Unit] [Paper Feed Roller: Tray 1] [Paper Feed Roller: Tray 2] [Paper Feed Roller: Tray 3] [Paper Feed Roller (Tray 4: Wide LCT)]...
  • Page 54 2. Details of Menu Items in Adjustment Settings for Skilled Operators Setting Items Remarks [Developer] Value display only. [Photoconductor Unit] [Charge Unit] [Cleaning Unit for Photoconductor Unit] [Cleaning Unit for Intermediate Transfer Belt] [Transfer Unit] [Fusing Unit] [Cleaning Unit for Fusing Unit] [Paper Feed Roller: Tray 1] [Paper Feed Roller: Tray 2] [Paper Feed Roller: Tray 3]...
  • Page 55 Setting Values Setting Items Remarks [Temperature] Value display only. [Humidity] 0518: [Temperature / Humidity outside the Machine] Display the external temperature and humidity. If your service representative requests it, report this information. Setting Items Remarks [Temperature] Value display only. [Humidity] 0520: [Back Up / Restore Custom Paper Data] Back up and restore custom paper profiles.

  • Page 56: [Finishing: Finisher]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [Fuser Unit No.] Setting Items Setting Items Unit [Current Value: Distance Counter: Fuser Unit] Value display only. [Current Value: Distance Counter: Fuser Cleaning Unit] [Current Value: Page Counter: Fuser Unit] sheet(s) [Current Value: Page Counter: Fuser Cleaning Unit]...
  • Page 57 Setting Values Paper feed direction CDS024...
  • Page 58 2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -1.0 [B4 JIS ] [A4 ] [B5 JIS ] [SRA3 ] [SRA4 ] [310 × 432m/m ] [226 ×...
  • Page 59 Setting Values Folding position Paper feed direction CDS025...
  • Page 60 2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -1.0 [B4 JIS ] [A4 ] [B5 JIS ] [SRA3 ] [SRA4 ] [310 × 432m/m ] [226 ×...
  • Page 61 Setting Values Leading Trailing edge edge Paper feed direction CZC212 Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] [B4 JIS ] [A4 ] [A4 ] [B5 JIS ] [B5 JIS ] [11 × 17 ] × 14 ] ×...
  • Page 62 2. Details of Menu Items in Adjustment Settings for Skilled Operators 0604: [Adjust Staple Position Across Feed Direction 2] Adjust the vertical position of the staples (dual) when using the Finisher SR5050 or Booklet Finisher SR5060. Press [+] to move the two stapling positions away from the center and each other or [−] to move them toward each other.
  • Page 63 Setting Values Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] [B4 JIS ] [A4 ] [A4 ] [B5 JIS ] [B5 JIS ] [11 × 17 ] × 14 ] × 13 × 11 ] × 11 ] [8K ] [16K ] [16K ]...
  • Page 64 2. Details of Menu Items in Adjustment Settings for Skilled Operators Leading Trailing edge edge Paper feed direction CZC216 Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] [B4 JIS ] [A4 ] [A4 ] [B5 JIS ] [B5 JIS ] [11 ×...
  • Page 65 Setting Values 0606: [Adjust Punch Position Across Feed Direction] Adjust the vertical position of the punch holes when using Finisher SR5050 or Booklet Finisher SR5060. Press [+] to move punch holes forward (up), or [−] to move them backward (down). 2 Holes Left 2 Holes Top 2 Holes Right...
  • Page 66 2. Details of Menu Items in Adjustment Settings for Skilled Operators 2 Holes Left 2 Holes Top 2 Holes Right Paper feed direction Paper feed direction CZC218 Default Max. Min. Setting Items Step Unit Value Value Value [2 Holes Type JP / EU] -4.0 [3 Holes Type US] [4 Holes Type EU]...
  • Page 67 Setting Values Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -0.5 [B4 JIS ] [A4 ] [B5 JIS ] [SRA3 ] [SRA4 ] [310 × 432m/m ] [226 × 310m/m ] [13 × 19 [13 × 19 ] [13 ×...
  • Page 68 2. Details of Menu Items in Adjustment Settings for Skilled Operators Factory default settings for additional booklet folds 1 to 13 sheets: 1 14 to 15 sheets: 2 16 to 25 sheets: 3 If you select a negative value (-1 to -3), values resulting in additional booklet folds below "0" will be counted as "0"...
  • Page 69 Setting Values Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -2.0 [B4 JIS ] [A4 ] [B5 JIS ] [SRA3 ] [SRA4 ] [310 × 432m/m ] [226 × 310m/m ] [13 × 19 [13 × 19 ] [13 ×...
  • Page 70 2. Details of Menu Items in Adjustment Settings for Skilled Operators Vertical alignment Jogger width Horizontal alignment Paper feed direction CEZ018 Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -1.0 [B4 JIS ] [A4 ] [A4 ] [B5 JIS ] [B5 JIS ] [11 ×...
  • Page 71 Setting Values 0612: [Paper Alignment in Shift Tray Across Feed Direction] Adjust the width of the paper alignment jogger in the shift tray when using Finisher SR5050 or Booklet Finisher SR5060. Use this to reduce the vertical variation in paper alignment due to differing size, thickness, or paper curl. Press [+] to make the width of the paper alignment jogger wider, or [−] to make narrower.
  • Page 72 2. Details of Menu Items in Adjustment Settings for Skilled Operators Press [+] to increase the travel distance, or [−] to decrease. Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -2.5 [B4 JIS ] [A4 ] [A4 ] [B5 JIS ] [B5 JIS ]...
  • Page 73 Setting Values 0615: [Z-fold Skew Correction] Specify how to correct skew (occurring during paper transport) when Z-folding with the folding unit. If [Off] is selected, skew is not corrected. If [On] is selected, skew is corrected by bringing the sheets flush against a guide. If [On (Reverse)] is selected, skew is corrected by bringing the sheets flush against a guide while the registration roller rotates in reverse to prevent the Z-folded sheets from passing through the registration roller.
  • Page 74 2. Details of Menu Items in Adjustment Settings for Skilled Operators 0618: [Correct Punch Skew] Adjust the amount of skew correction for punching when using Finisher SR5050 or Booklet Finisher SR5060. Use this to reduce punching skew due to differing size, thickness, or paper curl. If the sheets become skewed as a result of punching, press [+] to increase the degree of skew correction.
  • Page 75 Setting Values Depending on the type of paper, if too many sheets are sent to the staple unit at a time, they may not be aligned properly. If this happens, reduce the number of sheets. However, doing this will increase the time it takes to align the sheets and may reduce throughput.
  • Page 76 2. Details of Menu Items in Adjustment Settings for Skilled Operators Setting Items Selection Default Value [Adjust Output Tray Descending Position] [Paper Weight 1] [Paper Weight 2] [Paper Weight 2] [Paper Weight 3-8] 0622: [Adjust Exit Guide Close Timing (Booklet Fin)] Specify when to close the exit guide after paper is delivered to the finisher shift tray of Finisher SR5050 or Booklet Finisher SR5060.
  • Page 77 Setting Values Setting Items Selection Default Value [Output Fan Setting] [Auto] [Auto] [On] [Off] 0625: [Adjust Output Fan Level] Adjust the airflow of the shift tray for fanning the sheets when using Finisher SR5050 or Booklet Finisher SR5060. If sheets to the shift tray are stuck to each other when this setting is at its default value, increase the fan capacity.

  • Page 78: [Finishing: Fold]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators [Finishing: Fold] 0701: [Half Fold Position (Multi-sheet Fold)] Adjust the folded position (S) of half folded sheets when using the multi-folding unit. This setting will be applied if the multi-sheet fold function is enabled. Press [+] to increase and [−] to reduce (S).
  • Page 79 Setting Values Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -4.0 [B4 JIS ] [A4 ] [B5 JIS ] [SRA3 ] [SRA4 ] [310 × 432m/m ] [226 × 310m/m ] [13 × 19 [13 × 19 ] [13 ×...
  • Page 80 2. Details of Menu Items in Adjustment Settings for Skilled Operators mark indicates the leading edge (relative to the paper feed direction), and the mark indicates the trailing edge. Paper feed direction CDS015 Default Max. Min. Setting Items Step Unit Value Value Value...
  • Page 81 Setting Values Paper feed direction CDS015 Default Max. Min. Setting Items Step Unit Value Value Value [B4 JIS ] -4.0 [A4 ] [B5 JIS ] -3.0 × 14 ] -4.0 × 11 ] [Other Paper Sizes] 0704: [Letter Fold-in Position 1 (Multi-sheet Fold)] Adjust the fold position of the bottom segment (S) of letters fold-in sheets when using the multi-folding unit.
  • Page 82 2. Details of Menu Items in Adjustment Settings for Skilled Operators Paper feed direction CDS017 Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -4.0 [B4 JIS ] [A4 ] [B5 JIS ] [12 × 18 ] [11 ×...
  • Page 83 Setting Values Paper feed direction CDS017 Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -4.0 [B4 JIS ] [A4 ] [B5 JIS ] [12 × 18 ] [11 × 17 ] × 14 ] × 11 ] [8K ] -4.0 [Other Paper Sizes]...
  • Page 84 2. Details of Menu Items in Adjustment Settings for Skilled Operators Setting Items Values Default Value [Folding Unit Tray Full Detection] [On] [On] [Off] 0707: [Number of Sheets Folded after Full Detection] Specify the number of sheets the machine prints when it detects that the folding unit tray is full before displaying a warning message.
  • Page 85 Setting Values Paper feed direction DTJ002 Max. Min. Setting Items Step Unit Value Value [Adjust Z-fold Position 1] -4.0 0709: [Adjust Z-fold Position 2] Adjust the overall fold size (L) of Z- folded sheets when using the multi-folding unit. Press [+] to increase (L) and [−] to reduce it. mark indicates the leading edge (relative to the paper feed direction), and the mark indicates the trailing edge.

  • Page 86: [Finishing: Stacker]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators [Finishing: Stacker] 0901: [Paper Alignment in Stacker Tray Across Feed Direction 1] Adjust the width of the main jogger in order to reduce vertical variation in paper alignment due to difference in size, thickness, and paper curl when the high capacity stacker is installed.
  • Page 87 Setting Values Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -1.0 [B4 JIS ] [11 × 17 ] × 14 ] [Other Paper Sizes] 0903: [Paper Alignment in Stacker Tray With Feed Direction] Adjust the travel distance of the paper edge stopper in order to reduce horizontal variation in paper alignment due to difference in size, thickness, and paper curl when the high capacity stacker is installed.
  • Page 88 2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -1.0 [B4 JIS ] [A4 ] [A4 ] [B5 JIS ] [B5 JIS ] [A5 ] [A5 ] [11 ×...
  • Page 89 Setting Values Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -1.0 [B4 JIS ] [A4 ] [A4 ] [B5 JIS ] [B5 JIS ] [A5 ] [A5 ] [11 × 17 ] × 14 ] × 11 ] ×...
  • Page 90 2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -1.0 [B4 JIS ] [11 × 17 ] × 14 ] [Other Paper Sizes] 0906: [Paper Alignment in 2nd Stacker Tray With Feed Direction] Adjust the travel distance of the paper edge stopper in order to reduce horizontal variation in paper alignment due to difference in size, thickness, and paper curl when the second high capacity stacker is installed.
  • Page 91 Setting Values Default Max. Min. Setting Items Step Unit Value Value Value [A3 ] -1.0 [B4 JIS ] [A4 ] [A4 ] [B5 JIS ] [B5 JIS ] [A5 ] [A5 ] [11 × 17 ] × 14 ] × 11 ] ×...
  • Page 92 2. Details of Menu Items in Adjustment Settings for Skilled Operators Setting Items Selections Default Value [Large Size] [100%] [100%] [75%] [50%] [25%] [Small Size] [100%] [50%] [75%] [50%] [25%]...

  • Page 93: Custom Paper Settings For Administrators

    3. Custom Paper Settings for Administrators Accessing Advanced Settings Access Using the Control Panel Only the machine administrator can adjust the custom paper profiles registered in "Advanced Settings". To directly access the advanced settings for custom paper adjustment, you must first configure your machine's Administrator Authentication Management setting.
  • Page 94 3. Custom Paper Settings for Administrators Press [Login]. Enter your login user name, and then press [OK]. If you are logging in as the administrator for the first time, enter "admin". Enter your login password, and then press [OK]. Press the [Paper Setting] key. CWY003 Press [Edit Custom Paper].

  • Page 95: Access Using Web Image Monitor

    Accessing Advanced Settings Press [Change] for "Advanced Settings". The advanced settings for custom paper adjustment appear. Access Using Web Image Monitor Log in as the machine administrator from Web Image Monitor. Point to [Device Management], and then click [Configuration]. Click [Custom Paper] under "Device Settings". Check the radio button next to the number of the custom paper profile you wish to adjust, and then click [Program/Change].

  • Page 96: Description Of Paper Icons

    3. Custom Paper Settings for Administrators Description of Paper Icons You can check the custom paper status by checking the paper icon in the [Edit Custom Paper] screen. If you change the custom paper profile in the advanced settings, the paper icon changes as follows: CZC213 1.

  • Page 97: Deleting Saved Custom Paper Profiles

    Deleting Saved Custom Paper Profiles Deleting Saved Custom Paper Profiles Only the machine administrator can delete the custom paper profile saved in the paper library. To delete custom paper profiles, you must first specify the machine administrator authentication information. Press the [User Tools] key. Press [Login].
  • Page 98 3. Custom Paper Settings for Administrators Press [Delete Saved Custom Paper]. Select the program number of the custom paper profile you wish to delete. Press [Yes]. The custom paper profile is deleted.

  • Page 99: Backing Up And Restoring Custom Paper Profiles

    Backing up and Restoring Custom Paper Profiles Backing up and Restoring Custom Paper Profiles Backing up Custom Paper Profiles Saved in the Saved Paper Library The machine administrator can back up custom paper profiles saved in the Saved Paper Library to the SD card inserted in the back of the machine.

  • Page 100: Backing Up Custom Paper Profiles Registered Under The [Edit Custom Paper] Setting

    3. Custom Paper Settings for Administrators Press [Exit]. Backing up Custom Paper Profiles Registered Under the [Edit Custom Paper] Setting The machine administrator can back up and restore custom paper profiles registered under the [Edit Custom Paper] setting. Backing up the Data Insert an SD card into the SD card slot on the side of the control panel.

  • Page 101: Paper Presets In "Advanced Settings

    Paper Presets in "Advanced Settings" Paper Presets in "Advanced Settings" In "Advanced Settings", there are paper presets for various types of commercially-available paper. Even if you select a paper preset corresponding to a commercially-available paper from the Paper Library and register it in the [Edit Custom Paper] screen, the preset, depending on the custom paper profile version, may not be an exact match for the actual paper.
  • Page 102 3. Custom Paper Settings for Administrators...

  • Page 103: Details Of Menu Items In Advanced Settings

    4. Details of Menu Items in Advanced Settings Menu Items and Functions Paper Feed Adjustment For details about the following items, see page 108 "Paper Feed Adjustment". Item Description [Wide LCT Fan Setting] Specify the movement of the three-tray wide LCT (LCIT RT5080) fan.
  • Page 104 4. Details of Menu Items in Advanced Settings Item Description [Adj Image Position of Adjust the horizontal position of the image to be printed Side1 With Feed] on Side 1 of the paper. [Adj Image Position of Adjust the horizontal position of the image to be printed Side2 With Feed] on Side 2 of the paper.
  • Page 105 Menu Items and Functions Item Description [Transfer Timing Roller Feed Adjust the transfer timing roller speed. Speed Adj] [Fusing Feed Speed Adjust the fusing roller's speed. Adjustment] [Heat Pipe Motor Feed Adjust the speed of the heat pipe motor. Speed Adj] [Exit Motor Feed Speed Adjust the exit motor's speed.
  • Page 106 4. Details of Menu Items in Advanced Settings Item Description [Paper Transfer Current; Adjust the area at the leading edge of the paper for Lead Edge Dist] application of paper transfer current. [Paper Transfer Current; Adjust the paper transfer current at the trailing edge of Trail Edge] the paper.
  • Page 107 Menu Items and Functions Fuser Adjustment For details about the following items, see page 124 "Fuser Adjustment". Item Description [Put Pressure before Specify whether or not to have the fusing pressure roller Fusing] come into contact with the fusing belt before the printing operation (paper feeding) starts.
  • Page 108 4. Details of Menu Items in Advanced Settings Item Description [Decurler Feed Speed Adj: Adjust the paper feed speed of the decurler unit when Curl Adj Off] 0310: [Adjust Paper Curl] in the [Adjustment Settings for Skilled Operators] menu is set to "Off". [Decurler Feed Speed Adj: Adjust the paper feed speed of the decurler unit when Curl Adj Weak]...
  • Page 109 Menu Items and Functions Item Description [Double Parallel Fold Adjust the fold position of the bottom segment 2 of Position 2] double parallel folded sheets when using the multi- folding unit. [Adjust Gate Fold Position Adjust the fold width of the bottom segment 1 of gate folded sheets when using the multi-folding unit.

  • Page 110: Setting Values

    4. Details of Menu Items in Advanced Settings Setting Values Paper Feed Adjustment 01: [Wide LCT Fan Setting] Specify the movement of the three-tray wide LCT (LCIT RT5080) fan. If [On] is selected, air is discharged from the duct in the paper tray. By blowing air between the sheets, sheets stuck to each other can be separated.

  • Page 111: Paper Delivery Adjustment

    Setting Values Paper Delivery Adjustment 04: [Double Feed Detection] Specify whether or not to detect double feeding of paper. If [On] is selected, the machine stops when it detects paper double feeding, so as to prevent mixing of unprinted paper. The machine may not correctly detect double feeding when using special paper (two-ply paper such as release paper).

  • Page 112: Image Position/Scaling Adjustment

    4. Details of Menu Items in Advanced Settings Setting Items Max. Value Min. Value Step Unit [Color Paper Edge Detection Adjustment] 5.00 1.00 0.01 None 07: [Regist Jam Detection with Feed Dir] Specify whether or not to stop printing if the horizontal misalignment of the delivered paper exceeds the adjustable range (3 mm/0.1 inch).
  • Page 113 Setting Values Setting Items Max. Value Min. Value Step Unit [Adjust Image Position of Side 1 With Feed -3.0 Dir] 09: [Adj Image Position of Side2 With Feed] Adjust the horizontal position of the image to be printed on Side 2 of the paper. Press [+] to shift the image to the left (trailing edge).
  • Page 114 4. Details of Menu Items in Advanced Settings Paper feed direction Left Right Default (Leading edge) (Trailing edge) Bottom CEZ015 Setting Items Max. Value Min. Value Step Unit [Adjust Image Position of Side 1 Across -3.0 Feed Dir] 11: [Adj Image Position of Side2 Across Feed] Adjust the vertical position of the image to be printed on Side 2 of the paper.
  • Page 115 Setting Values 12: [Deactivate Image Position Adjustment] Specify whether or not the machine automatically detects paper pathway deviations during the paper feeding process and adjusts the vertical position of the print image accordingly. Printing will stop when the vertical position has deviated exceeding the adjustable range (3 mm/0.1 inch).
  • Page 116 4. Details of Menu Items in Advanced Settings Paper feed direction Leading edge Trailing edge Bottom CEZ021 Setting Items Max. Value Min. Value Step Unit [Adjust Erase Margin of Trailing Edge] 15: [Adj Magnification of Side1 Across Feed] Adjust the vertical image scaling on the Side 1 of the paper according to the paper expansion or shrinkage.
  • Page 117 Setting Values This allows you to adjust the image according to the paper expansion or shrinkage. Press [+] to increase the scaling and [−] to reduce it. Paper feed direction CEZ023 Setting Items Max. Value Min. Value Step Unit [Adjust Magnification of Side 1 With Feed 0.500 -0.500 0.025...

  • Page 118: Line Speed Adjustment

    Troubleshooting. 19: [Process Speed Setting] Adjust the machine's copy/print speed. Values below are those when printing is performed using in A4/LT size paper. • [High] (full speed) 136 cpm (13600) 111 cpm (11100) • [Middle] 111 cpm (13600)
  • Page 119 Setting Values • [Low] 96 cpm (13600) 96 cpm (11100) • In some cases, if you change this setting from [Low] to [Middle] or from [Middle] to [High], the toner may not properly fuse to the paper. • Depending on the type of paper, you can increase the toner gloss by changing this setting from [High] to [Middle] or from [Middle] to [Low].
  • Page 120 4. Details of Menu Items in Advanced Settings Setting Items Max. Value Min. Value Step Unit [Heat Pipe Motor Feed Speed Adj] -5.0 23: [Exit Motor Feed Speed Adjustment] Adjust the exit motor's speed. The exit motor drives the rollers at the paper exit. Press [+] to increase the speed and [−] to reduce it.

  • Page 121: Toner Adhesion Adjustment

    Setting Values Toner Adhesion Adjustment 26: [Adjust Toner Adhesion] Adjust the intermediate transfer belt toner adhesion. Use this to adjust the density of the printed image. Depending on the paper being used, it may be necessary to make this adjustment to achieve optimal toner adhesion. Press [+] to increase the toner adhesion and [−] to reduce it.
  • Page 122 4. Details of Menu Items in Advanced Settings 29: [Paper Transfer Current Setting: Side 2] Adjust the current applied to Side 2 for paper transfer. Use this to reduce image quality degradation due to the paper (for example, due to the paper's moisture content).
  • Page 123 Setting Values Use this to reduce image quality degradation at the trailing edge of the paper. Press [+] to increase the percentage and [−] to reduce it. Setting Items Max. Value Min. Value Step Unit [Paper Transfer Current; Trail Edge] 33: [Paper Transfer Current;...

  • Page 124: Paper Feed Adjustment: Two-Tray Wide Lct

    4. Details of Menu Items in Advanced Settings If there is a difference between the paper transfer speed and the imaging speed, the image may be distorted. Particularly in a high-temperature and high-humidity environments, or with thick paper, the image may be inappropriately extended.
  • Page 125 Setting Values Setting Items Max. Value Min. Value Step Unit [Side Fan] 39: [Vacuum Fan] Adjust the airflow of the vacuum fan of the two-tray wide LCT (Vacuum Feed LCIT RT5100). Press [+] to increase the airflow, or [−] to decrease. Setting Items Max.

  • Page 126: Fuser Adjustment

    4. Details of Menu Items in Advanced Settings Setting Items Values [Switch Paper Load Upper Limit] [Low] [High] 43: [Paper Feed Mode (Adjust Fan Level)] Specify how the two-tray wide LCT (Vacuum Feed LCIT RT5100) fan moves. Setting Items Values [Paper Feed Mode (Adjust Fan Level)] [Max Dble Fd Reduc.
  • Page 127 Setting Values Once a job starts, the fusing pressure roller comes into contact with the fusing belt after the time specified in this setting has elapsed. If this is set to 30 seconds, the fusing pressure roller comes into contact with the fusing belt 30 seconds after a job starts, and printing starts once warm-up is complete (when the temperature at which paper feeding is allowed is reached).
  • Page 128 4. Details of Menu Items in Advanced Settings • Decreasing the temperature too much may cause the toner to not properly fuse to the paper. (cold offset). Setting Items Max. Value Min. Value Step Unit [Fusing Pressure Roller Temperature degree(s) Adjustment] 48: [Fusing Nip Width Setting] Adjust the nip width between the fusing belt and the pressure roller.
  • Page 129 Setting Values The selected initial print speed reduction level in copies-per-minute (CPM) is applied only when printing starts (for approximately 15 to 20 seconds). This helps improve throughput if the fusing temperature can be kept constant. However, the throughput may decrease in an environment in which the temperature varies. •...
  • Page 130 4. Details of Menu Items in Advanced Settings 65% of full speed. • [Reduce Level 3] 50% of full speed. • The setting will take effect if the ambient temperature is higher than 17°C (62.6°F). Setting Items Values [Reduce Initial CPM: Normal/High Temp. [Do not Reduce] Environment] [Reduce Level 1]...

  • Page 131: Decurler Adjustment

    Setting Values Setting Items Max. Value Min. Value Step Unit [Adjust Adding Fusing Temperature 2] degree(s) Decurler Adjustment 55: [Decurler Feed Speed Adj: Curl Adj Off] Adjust the paper feed speed of the decurler unit when 0310: [Adjust Paper Curl] in the [Adjustment Settings for Skilled Operators] menu is set to "Off".

  • Page 132: Finishing Position Adjustment

    4. Details of Menu Items in Advanced Settings Finishing Position Adjustment 58: [Adjust Z-fold Position 1] Adjust the width of the bottom end segment (S) of Z- folded sheets when using the multi-folding unit. Press [+] to increase (S) and [−] to reduce it. mark indicates the leading edge (relative to the paper feed direction), and the mark indicates the trailing edge.
  • Page 133 Setting Values Setting Items Max. Value Min. Value Step Unit [Adjust Z-fold Position 2] -4.0 60: [Half Fold Position: Single-sheet Fold] Adjust the fold position (S) of half folded sheets when using the multi-folding unit. This setting will not be applied when the multi-sheet fold function is enabled. Press [+] to increase (S) and [−] to reduce it.
  • Page 134 4. Details of Menu Items in Advanced Settings Paper feed direction CEZ003 Setting Items Max. Value Min. Value Step Unit [Adjust Letter Fold-out Position 1: Single- -4.0 sheet Fold] *1 For B5 paper, any adjustment greater than 3 mm is rounded down to 3 mm. 62: [Letter Fold-out Posn 2: Single-sheet Fld] Adjust the overall fold size (L) of letter fold-out sheets when using the multi-folding unit.
  • Page 135 Setting Values 63: [Letter Fold-in Posn 1: Single-sheet Fold] Adjust the fold position of the bottom segment (S) of letter fold-in sheets when using the multi-folding unit. This setting will not be applied when the multi-sheet fold function is enabled. Press [+] to increase (S) and [−] to reduce it.
  • Page 136 4. Details of Menu Items in Advanced Settings Setting Items Max. Value Min. Value Step Unit [Adjust Letter Fold-in Position 2: Single- -4.0 sheet Fold] 65: [Double Parallel Fold Position 1] Adjust the fold position of the bottom segment 1 (S1) of double parallel-folded sheets when using the multi-folding unit.
  • Page 137 Setting Values Paper feed direction CEZ007 Setting Items Max. Value Min. Value Step Unit [Adjust Double Parallel Fold Position 2] -4.0 67: [Adjust Gate Fold Position 1] Adjust the fold width of the bottom segment 1 (S1) of gate folded sheets when using the multi-folding unit.
  • Page 138 4. Details of Menu Items in Advanced Settings 68: [Adjust Gate Fold Position 2] Adjust the fold width of the bottom segment 2 (S2) of gate folded sheets when using the multi-folding unit. Press [+] to increase (S2) and [−] to reduce it. The upper right illustration shows a partly opened, gate folded sheet, and the lower right illustration shows a fully folded sheet.
  • Page 139 Setting Values Paper feed direction CEZ010 Setting Items Max. Value Min. Value Step Unit [Adjust Gate Fold Position 3] -4.0...
