- Page 1 LX60ST/LW61ST Digital Projector User Manual...
-
Page 2: Table Of Contents
Table of contents Important safety Adjusting the sound ....... 36 Presenting from a USB Reader.... 37 instructions ......3 Shutting down the projector ....38 Introduction ......7 Direct power off........38 Menu operation ........39 Projector features........7 Shipping contents ........8 Maintenance...... -
Page 3: Important Safety Instructions
Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before In some countries, the line voltage is... - Page 4 Safety Instructions (Continued) Do not operate light sources beyond When the projector is under the rated light source life. Excessive operation, you may sense some operation of light sources beyond the heated air and odor from its ventilation grill. It is a normal rated life could cause them to fail on rare occasions.
- Page 5 Always place the projector on a level, disconnect it from the power supply's horizontal surface during operation. power outlet and call BenQ to have - Do not use if tilted at an angle of more the projector serviced. than 10 degrees left to right, nor at angle of more than 15 degrees front to back.
- Page 6 If you intend to mount your projector on the ceiling, we strongly recommend that you use a proper fitting BenQ projector ceiling mount kit and that you ensure it is securely and safely installed. If you use a non-BenQ brand projector ceiling mount kit, there is a safety risk that the projector may fall from the ceiling due to an improper attachment through the use of the wrong gauge or length screws.
-
Page 7: Introduction
Introduction Projector features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. The projector offers the following features. • ECO BLANK - With technology, the Eco Blank function will save up to 90% of your light source power at the same time your image is hiding •... -
Page 8: Shipping Contents
Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated. *The warranty card is only supplied in some specific regions. -
Page 9: Projector Exterior View
Projector exterior view External control panel Front/upper side (See "Controls and functions" on page for details.) Vent (cool air intake) Lens cover Focus ring Vent (heated air exhaust) Front IR remote sensor Projection lens AC power jack 12V DC output terminal Used to trigger external devices such as an electric screen or light control, etc. -
Page 10: Controls And Functions
Controls and functions Projector POWER indicator light Lights up or flashes when the projector is under operation. 10. AUTO Automatically determines the best picture timings for the displayed image. Right/ Increases the projector volume. When the On-Screen Display (OSD) menu is activated, the #6, #5, and #11 keys are used as directional arrows to select the desired menu items and to Focus ring... -
Page 11: Remote Control
Remote control MODE/ENTER Selects an available picture setup mode. Activates the selected On-Screen Display (OSD) menu item. LASER Emits visible laser pointer light for presentation purposes. PAGE UP/PAGE DOWN Operates your display software program (on a connected PC) which responds to page up/down commands (like Microsoft PowerPoint). - Page 12 18. ZOOM+/ZOOM- Magnifies or reduces the projected image size. 19. VOLUME+/VOLUME- Adjusts the sound level. 20. MUTE Toggles projector audio between on and off. 21. ASPECT Selects the display aspect ratio. 22. MIC/VOL +/- Adjusts the microphone sound level. 23. CAPTURE Captures the projected picture and save it as your startup screen.
-
Page 13: Remote Control Effective Range
Remote control effective range Infra-Red (IR) remote control sensors are located on the front and the rear of the projector. The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensors to function correctly. The distance between the remote control and the sensors should not exceed 8 meters (~ 26 feet). -
Page 14: Positioning Your Projector
Note that a special rear projection screen portability. and the BenQ Projector Ceiling Mount Kit are required for this installation location. Set Rear Ceiling in the SYSTEM SETUP: Basic > Projector Position menu after you turn the projector on. -
Page 15: Obtaining A Preferred Projected Image Size
Obtaining a preferred projected image size The distance from the projector lens to the screen, the zoom setting, and the video format each factors in the projected image size. Projection dimensions Refer to "Dimensions" on page 54 for the center of lens dimensions of this projector before calculating the appropriate position. - Page 16 All measurements are approximate and may vary from the actual sizes. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics.
-
Page 17: Connection
Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. • In the connections shown below, some cables may not be included with the projector (see "Shipping contents"... -
Page 18: Connecting Video Source Devices
• Many notebooks do not turn on their external video ports when connected to a projector. Usually a key combo like FN + F3 or CRT/LCD key turns the external display on/off. Locate a function key labeled CRT/ LCD or a function key with a monitor symbol on the notebook. Press FN and the labeled function key simultaneously. - Page 19 Once connected, the audio can be controlled by the projector On-Screen Display (OSD) menus. See "Audio Settings" on page 45 for details. The table below describes the connection methods for different devices, and where the sound is from. Device PC/Component Video Video/S-Video Microphone AUDIO IN 1/AUDIO IN...
-
Page 20: Operation
Operation Starting up the projector Plug the power cord into the projector and into a power outlet. Turn on the power outlet switch (where fitted). Check that the POWER indicator light on the projector lights orange after power has been applied. Please use the original accessories (e.g. -
Page 21: Adjusting The Projected Image
Adjusting the projected image Adjusting the projection angle The projector is equipped 2 adjuster feet. These adjusters change the image height and projection angle. To adjust the projector: Screw the adjuster feet to fine-tune the horizontal angle. To retract the feet, screw the adjuster feet in a reverse direction. -
Page 22: Correcting Keystone
Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen. To correct this, besides adjusting the height of the projector, if you want the projector to automatically correct image keystoning, be sure the Auto Keystone function in the DISPLAY menu is On. -
Page 23: Using The Menus
H. Size Operation Settings Digital Zoom Front+Rear Remote Receiver 3D Sync Panel Key Lock Disable 3D Sync Invert Background Color BenQ Teaching Template Splash Screen BenQ MyScreen Analog RGB MENU Exit Analog RGB MENU Exit Press MENU/EXIT twice* on to highlight the SYSTEM the projector or remote control SETUP: Basic menu. -
Page 24: Securing The Projector
Securing the projector Using a security cable lock The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock, such as the Kensington lock, to secure the projector. You can locate a Kensington lock slot on the projector. A Kensington security cable lock is usually a combination of key(s) and the lock. -
Page 25: If You Forget The Password
Customer Center. Write down the number and turn off your projector. Recall Code: 0 2 1 2 Seek help from the local BenQ service center to decode the number. You may be required to provide proof of purchase MENU Exit documentation to verify that you are an authorized user of the projector. -
Page 26: Disabling The Password Function
Disabling the password function To disable password protection, go back to the SYSTEM SETUP: Advanced > Security Settings > Change Security Settings menu after opening the OSD menu system. Press MODE/ENTER. The message “INPUT PASSWORD” is displayed. Enter the current password. i. -
Page 27: Switching Input Signal
Switching input signal The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. When starting up, the projector automatically searches for the available signals. Be sure the Quick Auto Search function in the SOURCE menu is On if you want the projector to automatically search for the signals. -
Page 28: Magnifying And Searching For Details
Magnifying and searching for details If you need to find the details on the projected picture, magnify the picture. Use the direction arrow keys for navigating the picture. • Using the remote control Press ZOOM+/ZOOM- to display the Zoom bar. Press ZOOM+ to magnify the center of the picture. - Page 29 About the aspect ratio • In the pictures below, the black portions are inactive areas and the white portions are active areas. • OSD menus can be displayed on those unused black areas. Auto Scales an image proportionally LW61ST LX60ST to fit the projector's native resolution in its horizontal or vertical width.
-
Page 30: Optimizing The Image
Optimizing the image Using Wall Color In the situation where you are projecting onto a colored surface such as a painted wall which may not be white, the Wall Color feature can help correct the projected picture’s colors to prevent possible color difference between the source and projected pictures. To use this function, go to the DISPLAY >... -
Page 31: Adjusting Brightness
Press to select a menu item to be changed and adjust the value with . See "Fine-tuning the image quality in user modes" below for details. When all settings have been done, highlight Save Settings and press MODE/ ENTER to store the settings. The confirmation message “Setting Saved”... - Page 32 There are many different shades that are considered to be "white" for various purposes. One of the common methods of representing white color is known as the “color temperature”. A white color with a low color temperature appears to be reddish white. A white color with a high color temperature appears to have more blue in it.
-
Page 33: Setting The Presentation Timer
Saturation is the amount of that color in a video picture. Lower settings produce less saturated colors; a setting of “0” removes that color from the image entirely. If the saturation is too high, that color will be overpowering and unrealistic. Press to highlight Gain and adjust its values to your preference by pressing . -
Page 34: Remote Paging Operations
To cancel the timer, perform the following steps: Go to the SYSTEM SETUP: Basic > Presentation Timer menu and highlight Off. Press MODE/ENTER. A confirmation message is displayed. Highlight Yes and press MODE/ENTER to confirm. You will see the message “Timer is Off”... -
Page 35: Locking Control Keys
Creating your own startup screen In addition to selecting the projector preset startup screen from among BenQ logo, Black or Blue screen, you can make your own startup screen that is a picture projected from your computer or video source. -
Page 36: Adjusting The Sound
If the action is successful, you see the message 'Captured Succeeded' on the screen. The captured picture is saved as MyScreen. To view the captured picture displayed as the startup screen, set MyScreen in the SYSTEM SETUP: Basic > Splash Screen menu and restart the projector. •... -
Page 37: Presenting From A Usb Reader
Presenting from a USB Reader This feature displays a slide show of images stored on a USB flash drive connected to the projector. It can eliminate the need for a computer source. Supported image formats: • JPEG(JPG) • • TIFF •... -
Page 38: Shutting Down The Projector
During a slide show Press go to previous or next image rotate the image by 90 degree clockwise/ (Rotation is temporary; the image returns to counterclockwise its original orientation when you go back to thumbnails) return to a previous page Auto start/stop a slide show Enter... -
Page 39: Menu Operation
Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected and the projector model you are using. Main menu Sub-menu Options Off/Light Yellow/Pink/Light Green/ Wall Color Blue/Blackboard Aspect Ratio Auto/Real/4:3/16:9/16:10 Auto Keystone On/Off Keystone Position... -
Page 40: System Setup
Eco Blank Timer min/25 min/30 min Disable/30 min/1 hr/2 hr/3 hr/4 Sleep Timer hr/8 hr/12 hr Remote Receiver Front+Rear/Front/Rear Panel Key Lock On/Off Background Color BenQ/Black/Blue/Purple Splash Screen BenQ/Black/Blue//MyScreen MyScreen High Altitude Mode On/Off Mute On/Off Volume Audio Settings Microphone Volume... - Page 41 Main menu Sub-menu Options 2400/4800/9600/14400/19200/ Baud Rate 38400/57600/115200 Test Pattern On/Off Closed Caption On/Off Enable Closed Caption Caption Version CC1/CC2/CC3/CC4 Network On/Off Microphone On/Off Standby Monitor Out On/Off Settings Off/Computer1/Computer2/ Audio Pass Video,S-Video/HDMI/Network Through display/USB display Status DHCP IP Address Wired LAN Subnet Mask SYSTEM...
-
Page 42: Description Of Each Menu
Description of each menu Function Description Corrects the projected picture’s color when the projection surface is Wall Color not white. See "Using Wall Color" on page 30 for details. There are several options to set the image's aspect ratio depending on Aspect Ratio your input signal source. -
Page 43: Function Description
Function Description Provides several preset patterns for various teaching purposes. Teaching Choose Blackboard or Whiteboard first by pressing Template press to choose the pattern you need. Press MODE/ENTER to display the selected pattern. Pre-defined picture modes are provided so you can optimize your Picture Mode projector image set-up to suit your program type. - Page 44 Function Description Quick Auto "Switching input signal" on page 27 for details. Search Color Space "Changing Color Space" on page 27 for details. Conversion Presentation Reminds the presenter to finish the presentation within a certain time frame. See "Setting the presentation timer" on page 33 for details.
- Page 45 "Utilizing the password function" on page 24 for details. Change Security Settings Security Power On Lock Settings Splash Screen Lock "Utilizing the password function" on page 24 for details. Web Control Lock BenQ Network Projector Operation Guide for details. Operation...
-
Page 46: Function Description
Function Description Selects a baud rate that is identical with your computer’s so that you can connect the projector using a suitable RS-232 cable and update or Baud Rate download the projector’s firmware. This function is intended for qualified service personnel. Selecting On enables the function and the projector displays the grid Test Pattern test pattern. - Page 47 Function Description Wired LAN Wireless LAN Remote Desktop Broadcasting Projection Log In Code BenQ Network Projector Operation Guide for details. Network AMX Device Discovery Settings When AMX Device Discovery is On, the projector can be detected by AMX controller. Mac Address Displays the mac address for this projector.
-
Page 48: Maintenance
Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens and case clean. Never remove any parts of the projector. Contact your dealer if any part needs replacing. Cleaning the lens Clean the lens whenever you notice dirt or dust on the surface. -
Page 49: Light Source Information
Light source information Getting to know the light source hour When the projector is in operation, the duration (in hours) of light source usage is automatically calculated by the built-in timer. "Setting Light Source Mode Selection as Economic" below for more information on Economic mode. To obtain the light source hour information: Press MENU/EXIT and then press to highlight the SYSTEM SETUP:... - Page 50 Timing of replacing the light source When the Light indicator lights up red or a message appears suggesting it is time to replace the light source, please consult your dealer. The following light source warning displays will remind you to change the light source. Status Message Install a new light source for optimal...
- Page 51 Indicators Light Status & Description Power events Stand-by mode. Orange Green Powering up. Flashing Normal operation. Green • The projector needs to cool for 5 seconds after the power is turned off. Orange • The projector has shut down automatically. If you try to Flashing re-start the projector, it will shut down again.
-
Page 52: Troubleshooting
Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC power jack on the projector, and plug the power cord into the There is no power from the power cord. power outlet. If the power outlet has a switch, make sure that it is switched on. -
Page 53: Specifications
Specifications Projector specifications All specifications are subject to change without notice. Optical Control Resolution RS-232 serial control (LX60ST) 9 pin x 1 1024 x 768 XGA LAN control (LW61ST) RJ45 x 1 1280 x 800 WXGA IR receiver x 2 Display system 12V trigger x 1 (Max. -
Page 54: Dimensions
Dimensions 393 mm (W) x 117 mm (H) x 298 mm (D) 105.5 76.6 (LX60ST) 75.95 (LW61ST) Wall mount installation Minimum installation requirements LX60ST Computer Resolution: SMART SMART Promethean Promethean Hitachi Diagram StarBoard Board Board ActivBoard ActivBoard CkassBiard2 StarBoard Image Reference FX-77 77.5... - Page 55 Distance from top of wall mount to ceiling (mm) Minimum Ceiling 2337.6 2565.6 2337.6 2583.6 3274.6 2320.6 2565.6 Height (mm) LW61ST Computer Resolution: WXGA Diagram SMART Promethean Hitachi FX- Hitachi FX- Image Resolution: Reference Board 685 ActivBoard 387 TRIO-88W DUO-88W WXGA Image Diagonal (inches) Image Height (mm)
- Page 56 The dimensions are based on the BenQ wall mount (P/N: 5J.J4R10.001). • All measurements are approximate and may vary from the actual sizes. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics.
-
Page 57: Timing Chart
1152 x 864 1152 x 864_75 67.5 1280 x 720 1280 x 720_60* 45.000 74.250 1280 x 768 1280 x 768_60* 59.87 47.776 79.5 BenQ Notebook 1024 x 576 60.0 35.820 46.966 Timing BenQ Notebook 1024 x 600 64.995 41.467 51.419 Timing WXGA_60* 59.810... - Page 58 119.989 97.551 115.5 (Reduce Blanking) 1152 x 864 1152 x 864_75 67.5 1280 x 768 1280 x 768_60 59.87 47.776 79.5 BenQ Notebook 1024 x 576@60Hz 60.00 35.820 46.996 Timing BenQ Notebook 1024 x 600@65Hz 64.995 41.467 51.419 Timing 1280 x 720 1280 x 720_60* 45.000...
- Page 59 Vertical Horizontal Pixel Timing Resolution Frequency Frequency Frequency Remark (Hz) (kHz) (MHz) 480i** 720 x 480 59.94 15.73 HDMI only 480p 720 x 480 59.94 31.47 HDMI only 576i 720 x 576 15.63 HDMI/DVI 576p 720 x 576 31.25 HDMI/DVI 720/50p 1280 x 720 37.5...
-
Page 60: Warranty And Copyright Information
Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ's only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects.
