BenQ LX60ST Specifications

LX60ST
DIGITAL
PROJECTOR
Features
Native XGA (1024 x 768) Resolution
2000 ANSI Lumens, 80000:1 Contrast Ratio
0.6 Throw Ratio, Light Source Pure Laser
LAN Control, Display, USB Reader/Display
20W Speaker, HDMI x 1, Wireless Display (optional)
Input and Output Terminals
1 2 3
4 5
6
1
12 V Trigger
2 LAN (RJ45)
3 USB (Type Mini B)
4
RS-232 (DB-9pin)
5 USB (Type A) x 2
HDMI
6
7
Monitor Out
7
BenQ America Corp.
15375 Barranca Parkway. Suite A-205. Irvine, CA 92618
BenQ is a registered trademark of BenQ Corp. DLP
Product names, logos, brands, and other trademarks featured or referred to in this materials are the property of their respective trademark holders.
Specifications subject to change without notice.
8 9
7
10 11
12 13 14
Computer-1/ Computer-2
8
S-Video
9
Audio L/R In (RCA)
10
Audio In 1 / Audio In 2
11
Video
12
13 Audio Out
14 Microphone in
Tel: (949) 255-9500
is a registered trademark of Texas Instruments. All rights reserved.
®
Specifications
Projection System
DLP
Native Resolution
XGA(1024 x 768)
Brightness 2000 ANSI lumens
Contrast Ratio 80000:1
Display Color
1.07 Billion
Lens
F=2.59, f=6.95mm
Aspect Ratio
Native 4:3 (5 aspect ratio selectable)
Throw Ratio 0.6 (81"@ 3.28ft)
Image Size (Diagonal)
80"~300"
Zoom Ratio
Fixed
Light Source
Laser Diode
Light Source Life (Nor/Eco Mode)* 10000/20000 hrs (Normal/Eco)
Keystone Adjustment
1D, Vertical +/- 30 degrees (Auto/Manual)
Projection Offset
130% +/- 5%
Resolution Support
VGA(640 x 480) to UXGA(1600 x 1200)
Horizontal Frequency 31K~102KHz
Vertical Scan Rate
23~120Hz
HDTV Compatibility
480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility
NTSC, PAL, SECAM
3D Compatibility (PC) 120Hz Frame Sequential 3D for resolutions up to WXGA
60Hz Top-bottom 3D for resolutions up to SXGA+
60Hz Frame Sequential 3D resolutions up to WXGA
3D Compatibility (Video)
60Hz Frame Sequential 3D for resolutions up to 480i
Interface
Computer in (D-sub 15pin) x 2 (shared with Component video)
Monitor out (D-sub 15pin) x 1
Composite Video in (RCA) x 1
S-Video in (Mini DIN 4pin) x 1
Audio in (Mini Jack) x 2
Audio L/R in (RCA) x 1
Audio out (Mini Jack) x 1
Microphone in (Mini Jack) x 1
Speaker 10W x 2
HDMI V1.3 x 1
LAN (RJ45) x 1 (LAN Control & LAN Display)
USB (Type A) x 2 (USB Reader&Keyboard/Mouse&Wireless Dongle)
USB (Type Mini B) x 1 (USB Display & Download & Page up/down)
DC 12V Trigger (3.5mm Jack) x 1
RS232 (DB-9pin) x 1
Dimensions (W x H x D)
15.5" x 5.89" x 11.73" (include adjustment footer)
Weight
11.24 lbs (5.1kg)
Power Supply 100 to 240 VAC, 50 to 60 Hz
Power Consumption 270W(Max), Standby<0.5W
Audible Noise 33/32 (Normal/Eco)
On-Screen Display Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/
Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/
Languages
Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/
Romanian/ Russian/ Simplified Chinese/Spanish/ Swedish/
Turkish/ Thai/ Traditional Chinese (28 Languages)
Picture Modes Dynamic/Presentation/sRGB/Cinema/User 1/User 2
Accessories (Standard) Remote Control w/ Battery, Power Cord, User Manual CD,
Quick Start Guide, Warranty Card, VGA(D-sub 15pin) Cable
0.6 Wall Mount
Accessories (Optional)
Wireless USB Dongle
3D Glasses
Carry Bag
3 Years Parts/Labor
Limited Warranty
*Lamp life results will vary depending on environmental conditions and usage. Actual product's features and specifications are subject
to change without notice.
www.BenQ.us
P/N: 5J.J4R10.001
P/N: 5J.J0614.A21
P/N: 5J.J0T14.011
LX60ST 12-06-11-BQus
