Terminal Overview
Intended Uses
Describes the general applications and purposes of PanelView operator terminals.
Terminal Types
Details the various options and configurations available for PanelView terminals.
PanelView 300 Micro Features
Defines the features of the PanelView 300 Micro keypad terminal, including front and back views.
PanelView 300 Features
Details the features of the PanelView 300 keypad terminal, covering front and back views.
PanelView 550 Features
Describes the features of PanelView 550 terminals, including Keypad, Keypad & Touch, and Touch Screen types.
PanelView 600 Features
Outlines the features of PanelView 600 terminals (Keypad, Keypad & Touch, Touch Screen).
PanelView 900/1000 Features
Details the features for PanelView 900 and 1000 terminals (Keypad and Touch Screen).
PanelView 1400 Features
Describes the features of PanelView 1400 terminals (Keypad and Touch Screen).
Applications
Explains how PanelView terminals operate with custom applications and the Configuration Mode menu.
Accessories
Lists available accessories such as software, legend kits, memory cards, and retainers.
Replacement Parts
Details available replacement parts like backlight lamps and clock modules.
Applying Power and Resetting Terminal
Wiring and Safety Guidelines
Provides essential guidelines for safe wiring and power connections to PanelView terminals.
Connecting AC Power
Details electrical ratings and procedures for connecting AC power to PanelView terminals.
Connecting DC Power
Explains electrical ratings and procedures for connecting DC power to PanelView terminals.
Resetting the Terminal
Describes how to reset PanelView terminals to re-initialize them and perform power-up sequences.
Power-up Sequence
Explains the terminal's self-tests and initial display upon power-up or reset.
Configuring the Terminal
Application Settings
Discusses how configuration parameters are set from the terminal or PanelBuilder32 software.
Accessing the Configuration Mode Menu
Provides instructions on how to access the Configuration Mode menu on different PanelView terminals.
Selecting a Language
Details how to select the display language for the PanelView terminal.
Using a Memory Card
Explains how to transfer applications between a memory card and the PanelView terminal.
Configuring Communications
Guides users on setting communication parameters for various protocols like DH-485, DH+, etc.
Configuring Presets
Describes how to set control object values for power-up using presets or last states.
Viewing Terminal Information
Explains how to display terminal information needed for technical support.
Adjusting Screen Parameters
Details how to adjust screen settings like contrast, video mode, and screen saver.
Setting the Time and Date
Provides instructions on how to reset the date and time on the PanelView terminal.
Setting up the Printer
Guides on setting parameters for terminals equipped with an RS-232 printer port.
Using a Memory Card
Supported Memory Cards
Lists the types of memory cards supported for application file transfer.
Using the Memory Card Retainer
Explains the use and purpose of the memory card retainer for secure installation.
Loading Application from a Memory Card
Details the procedure for loading an application file from a memory card into the terminal.
Loading Application on a Memory Card
Describes how to transfer an application from the terminal onto a memory card.
Storing Font Files on a Memory Card
Explains how to store font files for languages used by PanelView applications on memory cards.
Removing a Memory Card
Provides the procedure for safely removing a memory card from the PanelView terminal.
Running Applications
Application Information
Emphasizes the application designer's role in documenting operation before running.
Screen Security
Explains how access to application screens can be restricted using passwords.
Push Button Operation
Describes how push buttons function similarly to mechanical ones and their various appearances.
Control Lists
Details how control lists modify bits or values at controller addresses, similar to push buttons.
Numeric Entry Controls
Covers controls for numeric input via cursor points or keypad enable buttons using scratchpads.
ASCII Entry Controls
Explains how to send alphanumeric strings to a controller using ASCII entry controls and scratchpads.
Screen Selectors
Describes Screen List Selectors and Screen buttons for navigating application screens.
Display Objects
Covers List Indicators, Multistate Indicators, Bar Graph Displays, and Analog Gauges.
Message Displays
Explains message displays containing alphanumeric characters shown when triggered by a controller.
Time or Date
Describes how time and date information can appear as separate items or within control objects.
Printing
Details how PanelView terminals with an RS-232 port can print various types of information.
Alarms
Covers alarm features including Alarm Banner, Alarm buttons, and Alarm List.
Installing the PV300 Micro Terminal
Hazardous Locations
Specifies suitability for Class 1, Division 2 locations and related explosion hazard warnings.
Enclosures
Provides guidelines for mounting the terminal in a panel or enclosure for circuit protection.
Required Tools
Lists the tools necessary for installing the PV300 Micro terminal, besides panel cutout tools.
Mounting Dimensions
Shows the physical dimensions for mounting the PV300 Micro terminal.
Cutout Dimensions
Provides the recommended panel cutout dimensions for the PV300 Micro terminal.
Clearances
Specifies required clearances around the terminal for ventilation and maintenance.
Installing Terminal in Panel
Details the step-by-step process for installing the PV300 Micro terminal into a panel.
Installing the PV300 Terminal
Hazardous Locations
Addresses hazardous location certifications and explosion hazard warnings for PV300 terminals.
Enclosures
Guidance on mounting the PV300 terminal in an enclosure for internal circuitry protection.
Required Tools
Lists the tools needed for PV300 panel cutout and installation.
Mounting Dimensions
Illustrates mounting dimensions for the PV300 keypad terminals.
Cutout Dimensions
Provides reduced scale cutout dimensions for the PV300 terminal.
Clearances
Specifies space requirements for mounting, air flow, and maintenance of the PV300 terminal.
Installing the PV300 in a Panel
Step-by-step instructions for installing the PV300 terminal into a panel cutout.
Installing the PV550 Terminal
Hazardous Locations
Addresses hazardous location certifications and temperature code ratings for PV550 terminals.
Enclosures
Guidelines for mounting PV550 terminals in panels or enclosures for circuit protection.
Required Tools
Lists tools needed for PV550 panel cutout and installation.
Mounting Dimensions
Shows mounting dimensions for PV550 Keypad, Keypad & Touch, and Touch Screen terminals.
Clearances
Specifies space needed for mounting, air flow, memory card, and legend strip installation.
Cutout Dimensions
Provides cutout dimensions for PV550 Keypad & Touch Screen and Touch Screen terminals.
Installing the PV550 in a Panel
Step-by-step instructions for mounting the PV550 terminal into a panel.
Installing the PV600 Terminal
Hazardous Locations
Addresses hazardous location certifications and temperature code ratings for PV600 terminals.
Enclosures
Guidelines for mounting PV600 terminals in panels or enclosures for circuit protection.
Required Tools
Lists tools needed for PV600 panel cutout and installation.
Mounting Dimensions
Shows mounting dimensions for PV600 Keypad & Touch Screen and Touch Screen terminals.
Cutout Dimensions
Provides cutout dimensions for PV600 Keypad & Touch Screen and Touch Screen terminals.
Clearances
Specifies space needed for mounting, air flow, memory card, and legend strip installation.
Installing the PV600 in a Panel
Step-by-step instructions for mounting the PV600 terminal into a panel.
Installing the PV900/1000 Terminals
Hazardous Locations
Addresses hazardous location certifications and temperature code ratings for PV900/1000 terminals.
Enclosures
Guidelines for mounting PV900/1000 terminals in panels or enclosures for circuit protection.
Required Tools
Lists tools needed for PV900/1000 panel cutout and installation.
Mounting Dimensions
Shows mounting dimensions for PV900 and PV1000 terminals (Keypad and Touch).
Clearances
Specifies space needed for mounting, air flow, memory card, and legend strip installation.
Cutout Dimensions
Provides cutout dimensions for PV900 and PV1000 terminals (Keypad and Touch).
Installing the PV900/PV1000 in a Panel
Step-by-step instructions for mounting PV900/1000 terminals into a panel.
Installing the PV1400 Terminal
Enclosures
Guidelines for mounting PV1400 terminals in panels or enclosures for circuit protection.
Required Tools
Lists tools needed for PV1400 panel cutout and installation.
Mounting Dimensions
Shows mounting dimensions for PV1400 terminals (Keypad and Touch Screen).
Clearances
Specifies space needed for mounting, air flow, and memory card installation.
Cutout Dimensions
Provides cutout dimensions for PV1400 Keypad and Touch Screen terminals.
Installing the PV1400 in a Panel
Step-by-step instructions for mounting the PV1400 terminal into a panel using clips or studs.
Terminal Connections
Wiring and Safety Guidelines
Provides safety guidelines for wiring PanelView terminals, including conduit and grounding.
Cable Charts
Summarizes PanelView terminal connections to controllers and network interface modules.
Remote I/O Terminal Connections
Details connections for Remote I/O PanelView terminals, including ports, controllers, and pass-through.
DH+ Terminal Connections
Describes DH+ ports, system configuration, and making DH+ connections for PanelView terminals.
DH-485 Terminal Connections
Covers DH-485 ports, connecting to SLC controllers, networks, computers, and hand-held terminals.
RS-232 (DH-485) Terminal Connections
Details RS-232 (DH-485) connections to controllers, computers, and DH-485 links.
RS-232 (DF1) Terminal Connections
Explains DF1 connections, compatible controllers, terminal ports, and modem usage.
ControlNet Connections
Covers ControlNet protocol, controllers, ports, network layout, and making connections.
DeviceNet Terminal Connections
Details DeviceNet connectors, connections, and typical DeviceNet network configurations.
EtherNet/IP Connections
Describes EtherNet/IP communication capabilities, ports, connectors, and network configurations.
PanelView 300 Micro Terminal Connections
Explains RS-232 connections for PanelView 300 Micro to controllers, networks, and computers.
Connecting a Computer or Printer to the Terminal
Illustrates how to connect computers and printers to the PanelView terminal via RS-232.
Troubleshooting and Maintenance
Equipment Required
Lists the essential equipment needed for troubleshooting PanelView terminals.
Using the Troubleshooting Chart
Guides users on how to utilize the troubleshooting chart for common problems.
Indicators
Explains the meaning of COMM and Fault LED indicators on various PanelView terminals.
Cleaning the Display Window
Provides instructions on how to clean the display window safely without damage.
Replacing the Clock Module
Details the procedure and considerations for replacing the real-time clock module.
Replacing the Backlight
Explains the availability and replacement process for PanelView terminal backlights.
Specifications
PanelView 300 Micro
Presents detailed electrical, mechanical, display, terminal memory, and environment specifications.
PanelView 300
Provides detailed specifications for PanelView 300, including electrical, mechanical, and display features.
PanelView 550
Details specifications for PanelView 550 terminals: electrical, mechanical, display, and memory.
PanelView 600 Color Keypad & Touch
Lists specifications for PanelView 600 Color Keypad & Touch terminals.
PanelView 600 Color Touch Only
Presents specifications for PanelView 600 Color Touch Only terminals.
PanelView 900 Monochrome and Color
Details specifications for PanelView 900 Monochrome and Color terminals.
PanelView 1000 Color & Grayscale
Lists specifications for PanelView 1000 Color & Grayscale terminals.
PanelView 1400 Color
Provides specifications for PanelView 1400 Color terminals.
Communications
Summarizes communication parameters like baud rates and distances for various networks.
Messages, Codes and Self-Test Numbers
Types of Terminal Messages
Categorizes terminal messages into Status, Reminder, Warning, and Fault messages.
General Terminal Messages
Lists common terminal error messages, their meanings, and recommended corrective actions.
Terminal Codes
Explains terminal codes displayed during operation or configuration for various networks.
DeviceNet Codes
Details DeviceNet communication status codes, their indications, and recommended actions.
Self-test Numbers
Lists self-test numbers that appear during power-up and their corresponding indications.
European Union Directive Compliance
Intended Use of Product
Defines the intended industrial use of PanelView terminals as per EMC standards.
Wiring Recommendations
Provides recommendations for wiring PanelView terminals to reduce electrical noise.
Declarations of Conformity
States where Declarations of Conformity for PanelView terminals are available.
Glossary
application
Defines 'application' in the context of PanelBuilder32 software and PanelView terminals.
PanelBuilder32 software
Describes PanelBuilder32 as a Windows program for developing PanelView applications.
PLC controller
Defines a PLC controller as a programmable unit controlling machine or process elements.
RS-232
Defines RS-232 as an EIA standard for serial binary communication circuits.
subnet mask
Explains subnet mask as a 32-bit value interpreting IP addresses in networks.
Need help?
Do you have a question about the PV600 and is the answer not in the manual?
Questions and answers
