1 Introduction
1.1 MAXinBOX SHUTTER 4CH / 8CH
Introduces the KNX actuators for controlling motorised shutter/blind systems, highlighting key features like relay outputs and logic functions.
1.2 INSTALLATION
Device Components and Controls
Describes key hardware elements like pushbuttons, LEDs, and output ports for proper installation and operation.
1.3 START-UP AND POWER LOSS
Startup and Power Loss Handling
Explains the initial device startup behavior, LED indications, and how the system handles power failures and recovery.
2 CONFIGURATION
2.1 GENERAL
Details initial ETS setup and the General screen for enabling core features like Outputs, Logic Functions, and Manual Control.
2.2 OUTPUTS
Explains the device's 8/16 relay outputs configurable as 4/8 independent shutter channels for motorised systems.
2.2.1 MANUAL CONTROL
Describes manual shutter control via pushbuttons and introduces Test On/Off modes for operational use.
Test Off Mode
Details control via communication objects and pushbuttons in Test Off mode, including button press behavior.
Test On Mode
Explains control exclusively via pushbuttons in Test On mode, ignoring KNX commands and covering safety.
Manual Control Parameterisation
Covers ETS parameterization for Manual Control options and the Lock feature, including value and initialization settings.
2.3 LOGIC FUNCTIONS
Explains the module's capability to perform numeric/binary operations on KNX values and send results via communication objects.
2.4 SCENE TEMPORISATION
Allows imposing delays on the execution of configured scenes for shutter channels.
Scene Temporisation Configuration
Details how to configure delays for specific scenes across different channels using ETS parameterization.
