Summarization of Contents
Getting Started
Assembly Preparation and Tools
Verify parts, unpack carefully, check estimated time, and gather required tools.
Care and Maintenance
Guidelines for regular cleaning, tightening, and safety precautions.
Fan Weight Information
Details the net weight of the ceiling fan.
Package Contents
Component List
Lists all included parts such as blades, canopy, mounting bracket, and hardware.
Hardware and Accessories
Details loose parts bags containing mounting hardware, electrical hardware, and wire connectors.
Safety Information
General Safety Precautions
Covers power disconnection, wiring, clearance, and outlet box requirements.
Operational Safety Warnings
Includes warnings about blade handling, foreign objects, and speed control devices.
Grounding and Damp Location Safety
Ensures proper grounding and GFCI protection for damp locations.
Mounting Options
Standard and Angled Mounting
Details standard and angled mounting suitability and ceiling angle limits.
Closemount Mounting
Ideal for lower ceilings, offering a close-to-ceiling installation.
Clearance and Downrod Checks
Ensure proper blade clearance from obstructions and floor.
Mounting Bracket Installation
Bracket Removal and Detachment
Loosen mounting screws, detach bracket from canopy for later use.
Securing the Mounting Bracket
Attach bracket to outlet box using provided screws and washers.
Angle Mount Orientation
For angle mounts, ensure the open end of the bracket faces the ceiling peak.
Standard or Angle Mounting Instructions
Yoke and Downrod Preparation
Loosen set screws, remove downrod pin and clip, and thread wires.
Downrod Assembly
Slide downrod into yoke, align holes, reinstall pin and clip, tighten screws.
Standard or Angle Mounting Instructions
Downrod Installation
Install downrod into yoke, align holes, secure with pin and clip, and tighten set screws.
Lead Wire Preparation
Measure and cut lead wires if necessary, strip insulation, and twist wires.
Standard or Angle Mounting Instructions
Downrod Ball Installation
Install downrod ball into mounting bracket, aligning slot with tab.
Closemount Instructions
Canopy Preparation
Remove canopy cover; downrod, hanging ball, and cover are not used.
Canopy Attachment
Align canopy with motor housing screw holes and secure with screws and washers.
Temporary Fan Hanging
Raise fan and place canopy on mounting bracket hook for wiring access.
Wiring Instructions
General Wiring Precautions
Ensure proper grounding and consult electrician for color differences. Avoid incorrect connections.
Standard Wiring Connections
Connect ground wires, then black/blue to live, and white to neutral supply wires.
Optional Light Control Wiring
Connect blue fan wire to a second hot power wire for separate light control.
Canopy Installation
Final Canopy Securing
Lift canopy, align with mounting bracket screws, rotate, and secure with remaining screws.
Blade Installation
Blade Arm Attachment
Remove motor screws and plastic blocks. Attach blades to blade arms using twist lock connectors.
Securing Blade Arms
Insert and tighten motor screws through blade arm and isolator into the motor.
Switch Housing Installation
Switch Housing Connection
Connect motor plug to switch housing cap, align holes, and secure with screws.
Pull Chain Attachment
Attach pull chain extension or custom pull chain to the existing pull chain.
Operating Instructions
Fan Reverse Switch
Use the switch to optimize fan for seasonal airflow (summer/winter).
Summer Airflow (Cooling)
Push reverse switch left for downward airflow creating a wind chill effect.
Winter Airflow (Heating)
Push reverse switch right for upward airflow to circulate warm air.
Replacement Parts List
Part Identification
Lists part numbers for blade arms, blades, and loose parts bags for models 50201 and 50206.
Troubleshooting
Fan Does Not Move
Check power, connections, light kit fitter, and ensure blades are not overweight.
Fan Noise Issues
Tighten blade screws and blade arm screws. Replace cracked blades if necessary.
Excessive Wobbling
Tighten all screws, balance blades, verify mounting bracket security and flush fit.
Limited Lifetime Warranty
Warranty Coverage
Covers fan motor for life, parts for one year. Excludes glass, finishes, misuse, and improper installation.
Warranty Limitations and Disclaimers
Disclaims incidental/consequential damages and implied warranties. Warranty void if fan is resold.
Obtaining Warranty Service
Contact customer service with model number and proof of purchase.
