- Page 1 Instructions manual / GX Screwdrivers GX Screwdrivers (40 Volts) INSTRUCTIONS MANUAL INSTRUCTIONS MANUAL...
- Page 2 Instructions manual / GX Screwdrivers The tool delivered with this manual may been modified for specific needs. In that case, please give us the tool code number written on our shipping note or the appoximate tool delivery date when you will place an order for a new similar tool or for spare parts. In that way, you will be sure to get the required and/or spare part.
-
Page 3: Table Of Contents
Instructions manual / GX Screwdrivers SUMMARY 1. GENERAL SAFETY RULES ...................... 4 1.1 Work Area ................................. 4 1.2 Electrical Safety ............................... 4 1.3 Personal Safety ................................ 4 1.4 Tool use and Care ..............................4 1.5 SERVICE..................................5 2. SPECIFIC SAFETY RULES ....................... 5 2.2 Never lubricate aerosol oil on to the electrical part. -
Page 4: General Safety Rules
Instructions manual / GX Screwdrivers 1. GENERAL SAFETY RULES WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury SAVE THESE INSTRUCTIONS 1.1 Work Area - Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents. - Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. -
Page 5: Service
Instructions manual / GX Screwdrivers - Maintain tools with care. Keep cutting tools sharp and clean. Properly maintained tools, with sharp cutting edges are less likely to bind and are easier to control. - Check for misalignment or binding of moving parts, breakage of parts, and any other condition that may affect the tools operation. -
Page 6: Electric Specification
Instructions manual / GX Screwdrivers 3. Electric specification Items Power controller Screwdriver GX150, GX220, GX450, Model XS-40D GX150P, GX220P, GX450P Input 110 / 230VAC (selectable) DC40V Output 30/40VDC ( selectable ) Rated power 2.5A 95W Maximum output current Intermittent operation... -
Page 7: Screwdriver Specification
Instructions manual / GX Screwdrivers 6. Screwdriver Specification ■ Specification Features (available Torque No load speed option) Type Model Start (Kgf.cm) (rpm) GX 150/ESD 3~15 800~1700 ○ ○ (○) GX 220/ESD LEVER 6~22 600~1250 ○ ○ (○) GX 450/ESD 7~45 300~650 ○... -
Page 8: Torque Curve (At No Load Max. Speed)
Instructions manual / GX Screwdrivers 7. Torque curve (at No load Max. speed) GX 150 GX 220 GX 450 8. Panel of each model ■ Standard (Speed control) / GX___ ■ Soft start & Double hit / GX___+ ■ Angle control & Auto reverse / GXT___ 9. -
Page 9: Operation
1250 GX450 10.2 Soft start & Double hit ( GX___+ ) Model : GX150+, GX220+, GX450+, GX150P+, GX220P+, GX450P+ The Plus option drivers have the single speed of the maximum in the speed range. ■ Double Hit When "Double Hit" is chosen by the Double Hit button, LED A will light Orange color. -
Page 10: Angle Control & Auto Reverse ( Gxt
Instructions manual / GX Screwdrivers 10.3 Angle control & Auto reverse ( GXT____ ) Model : GXT150, GXT220, GXT450 One triggering by the lever can make 3 step operation sequence in a cycle ■ Start, Stop and Direction in a cycle →... - Page 11 Instructions manual / GX Screwdrivers ■ Angle setting for first RUN ① Keep the first Run button pressed over 2 sec. for angle setting. Then press one by one for the desired rotating angle ② Select the R position of F/R switch for increasing set angle or F position for decreasing set angle ③...
- Page 12 Instructions manual / GX Screwdrivers ■ Rotating speed setting ① Keep the both first Run & stop time buttons pressed over 2 sec. for unlock. Then click one by one for the desired rotating speed. ② Select the R position of F/R switch for increasing speed or F position for decreasing speed ③...
- Page 13 Instructions manual / GX Screwdrivers ■ Application Example First RUN Stop HOLD Auto Reverse Applications with different sequence in Angle Time Angle a cycle Normal Normal screwdriver screwdriver It stops at the set torque Angle control ON(1) It stops at set angle(1) Tapper or ON(3) It stops at set angle(1) and waits for set...
- Page 14 Instructions manual / GX Screwdrivers...
- Page 15 Instructions manual / GX Screwdrivers...
- Page 16 Instructions manual / GX Screwdrivers...
