• INSTRUCTION MANUAL
• MANUAL DE INSTRUCCIONES
• MODE D'EMPLOI
• BEDIENUNGSANLEITUNG
SAP-XRV96EH
SAP-XRV126EH
SAP-XRV186EH
This air conditioner uses the new refrigerant R410A.
Save These Instructions!
Guarde estas instrucciones
Conserver ce mode d'emploi
Bewahren Sie bitte diese
Bedienungsanleitung auf.
Pub. OI-37.4196.127.0
SAP-FRV96EH
SAP-FTRV126H
SAP-FTRV186EH
SAP-FTRV246EH
© SANYO 2010
Inverter-Controlled
Split System Air Conditioner
Acondicionador de aire de dos unidades
controlado por invertidor
Climatiseur de type séparé contrôlé par
inverseur
Splitsystem-Klimagerät mit Inverter-
Steuerung
SAP-URV96EH
SAP-URV126EH
SAP-URV186EH
SAP-URV246EH
COOL/DRY/HEAT Model
Advertisement
Table of Contents
Related Manuals for Sanyo SAP-XRV96EH
Summarization of Contents
Features
Microprocessor Controlled Operation
Explains automatic control via microprocessor for ease of use.
Simple One-touch Wireless Remote Control
Describes the ease of operation and features of the wireless remote.
24-Hour ON or OFF Timer
Details the 24-hour timer function for scheduling unit operation.
1-Hour OFF Timer
Explains the one-hour timer for automatic shutdown.
Night Setback
Describes temperature adjustment for energy saving during sleep.
Automatic and 3-step Fan Speed
Covers automatic and manual fan speed settings.
Air Sweep Control
Explains the oscillating flap for optimal air distribution.
Auto. Flap Control
Details automatic flap positioning for optimal airflow.
Automatic Switching between Cooling and Heating
Describes auto mode for automatic temperature control.
Hot Start Heating System
Explains feature to prevent cold air blasts at start-up.
Automatic Restart Function for Power Failure
Covers auto restart after power interruption.
High Power Operation
Details the maximum output mode for quick temperature adjustment.
Anti-Mold Filter
Describes the filter that inhibits mold and bacteria growth.
Names of Parts (Models XRV)
Remote Control Unit
Identifies the remote control device.
Remote Control Sensor
Identifies the sensor on the remote control.
Receiver
Identifies the signal receiver on the indoor unit.
Air Outlet
Identifies where conditioned air is expelled.
Air Intake Latch
Identifies the latch for the air intake.
Air Intake Grille
Identifies the grille for air entry.
Air Filter
Identifies the component for air purification.
Suspension Brackets
Identifies mounting supports for the indoor unit.
Refrigerant Couplings
Identifies connections for refrigerant lines.
Condensate Drain Connection
Identifies the outlet for draining condensed water.
Electric Junction Box
Identifies the box for electrical connections.
Indoor Unit Sensor
Identifies the sensor on the indoor unit detecting room temperature.
Operation Selector
Identifies the manual operation mode switch.
Operation Lamp
Identifies the indicator light for unit operation.
Service Lamp
Identifies the indicator light for service faults.
Timer Lamp
Identifies the indicator light for timer activity.
Names of Parts (Models FTRV-FRV)
Remote Control Unit
Identifies the remote control device.
Sensor
Identifies the room temperature sensor on the remote.
Air Outlet
Identifies where conditioned air is expelled.
Air Intake
Identifies the opening for air entry.
Remote Control Receiver
Identifies the signal receiver on the indoor unit.
Operation Selector
Identifies the manual operation mode switch.
Operation Lamp
Identifies the indicator light for unit operation.
Service Lamp
Identifies the indicator light for service faults.
Timer Lamp
Identifies the indicator light for timer activity.
Names of Parts (Models URV)
Remote Control Unit
Identifies the remote control device.
Sensor
Identifies the room temperature sensor on the remote.
Receiver
Identifies the signal receiver on the indoor unit.
Air Outlet
Identifies where conditioned air is expelled.
Air Filter
Identifies the component for air purification.
Suspension Brackets
Identifies mounting supports for the indoor unit.
Refrigerant Couplings
Identifies connections for refrigerant lines.
Condensate Drain Connection
Identifies the outlet for draining condensed water.
Electric Junction Box
Identifies the box for electrical connections.
Operation Selector
Identifies the manual operation mode switch.
Operation Lamp
Identifies the indicator light for unit operation.
Service Lamp
Identifies the indicator light for service faults.
Timer Lamp
Identifies the indicator light for timer activity.
Remote Control Unit Display
Operation Mode Symbols
Displays symbols for AUTO, HEAT, DRY, COOL, FAN modes.
Fan Speed Symbols
Displays symbols for automatic, high, medium, low fan speeds.
Temperature Setting Symbols
Shows how temperature is displayed and set.
Timer Symbols
Displays symbols for timer functions (ON, OFF, 1-hour).
Night Setback Symbol
Indicates when Night Setback mode is active.
Transmission Confirmation
Shows symbol indicating successful signal transmission.
Flap Angle Symbols
Displays symbols for flap position and sweep.
High Power Operation Symbol
Indicates when High Power mode is active.
Remote Control Unit Operation
Transmitter Function
Explains how the remote transmits signals.
Sensor Function
Describes the remote's built-in temperature sensor.
Display Information
Details what information is shown on the remote display.
ON/OFF Operation Button
Explains how to turn the unit on and off.
1-Hour Timer Button
Details the function of the 1-hour timer button.
Remote Control Unit Functions
Temperature Setting Buttons
How to adjust the desired temperature.
Mode Selector Button
How to choose operation modes (AUTO, HEAT, DRY, COOL, FAN).
Fan Speed Selector Button
How to select fan speed (auto, high, medium, low).
Night Setback Button
How to activate energy-saving night mode.
Flap Button
How to adjust airflow direction.
High Power Button
How to activate the maximum output mode.
On/Off Time Setting Buttons
How to set timers for operation start/stop.
Remote Control Unit Settings and Battery Installation
Sensor Button Operation
How to switch between remote and indoor unit sensors.
Temperature Display Selector
How to switch between Celsius (°C) and Fahrenheit (°F).
Time Display Selector
How to switch between 12-hour and 24-hour time formats.
ACL Button (All Clear)
Explains the function of the all-clear button for reset.
S/M Switch (Single/Multiple)
Explains the switch for single or multiple unit operation.
How to Install Batteries
Step-by-step guide for battery replacement.
Remote Control Unit Installation and Mounting
Installation Position Guidelines
Where NOT to install the remote for optimal performance.
Mounting the Unit
Instructions on how to mount the remote control holder.
Holding the Unit
How to hold the remote and ensure signal transmission.
Fan Speed Adjustment and Fan Only Mode
Automatic Fan Speed
How to set fan speed automatically based on room temperature.
Manual Fan Speed
How to manually select fan speed.
Fan Only Operation
How to use the unit for air circulation only.
Night Setback Mode
Cooling and Dry Mode Operation
Explains temperature increase in cooling/dry modes for energy saving.
Heating Mode Operation
Explains temperature decrease in heating mode for energy saving.
Special Remarks
DRY Operation Details
Explains how DRY mode functions and its limitations.
Heating Performance Considerations
Discusses efficiency at low outdoor temperatures.
Defrosting Process
Explains the automatic defrost cycle operation.
Cold Draft Prevention System
Describes how cold air is managed during heating start-up.
Power Failure Restart
Details how the unit restarts after a power outage.
Clicking Sound Explanation
Explains normal clicking sounds from thermal expansion.
Remote Control Signal Frequency
Notes how often the remote sends settings to the unit.
Setting the Timer
How to Set Present Time
Step-by-step guide to set the current time on the remote.
How to Set OFF Time
Step-by-step guide to set the unit to automatically turn off.
Timer Settings and Cancellation
How to Set ON Time
Step-by-step guide to set the unit to automatically turn on.
Daily ON/OFF Repeat Timer
How to set recurring daily timer schedules.
Cancelling Timer Programs
How to cancel set timer functions.
1-Hour OFF Timer and Energy Saving Tips
1-Hour OFF Timer Function
How to use the one-hour auto-off function.
Timer Interaction
How different timer functions interact and priority.
Energy Saving Recommendations
Tips to reduce energy consumption for the air conditioner.
Adjusting Airflow Direction (Models XRV)
Sweep Function Operation
How to activate the oscillating airflow for wide coverage.
Manual Airflow Adjustment
How to set airflow direction manually.
Auto Flap Function
How the flap automatically adjusts position for optimal airflow.
Adjusting Airflow Direction (Models FRV/FTRV/FRV)
Sweep Function Operation
How to activate the oscillating airflow for wide coverage.
Manual Airflow Adjustment
How to set airflow direction manually.
Care and Cleaning
Casing and Grille Cleaning
Instructions for cleaning the indoor unit's exterior casing and grille.
Air Filter and Condensate Drain Pan Maintenance
Air Filter Cleaning Procedure
Detailed steps for cleaning the air filter.
Condensate Drain Pan Removal
Instructions for removing and cleaning the condensate drain pan.
Air Filter Cleaning (Models FTRV-FRV/URV)
Filter Removal and Cleaning
Steps for cleaning the air filter for specific models.
Air Clean Filter Installation
Installing the Air Clean Filter
Steps for fitting the optional "Air Clean" filter.
