Panamax M7500-PRO Specifications

LOOKING FOR CRYSTAL CLEAR PICTURE & SOUND?
MAX 7500-PRO
®
HOME THEATER POWER MANAGEMENT
TOP BENEFITS
1 The MAX 7500 PRO has been specifically engineered to
®
improve the performance and life expectancy of home the-
ater equipment. The combination of sophisticated power
conditioning and the world's finest power protection has
resulted in an audio/video power center that meets the power
quality needs for the entire entertainment system.
At the heart of the MAX 7500-PRO is an advanced power fil-
2
®
tration system featuring a 720VA isolation transformer, that
provides power for digital source components and displays.
3 In addition, any noise generated by digital source compo-
nents is isolated and prevented from reaching key audio or
video components. The MAX
feature mechanically interrupts ground loops, making the
MAX 7500-PRO especially useful for applications with unsta-
ble power or ground issues. IP addressable, the MAX 7500-
PRO is also ideal for multi-zone audio/video whole-home
automation and wherever remote diagnostics are needed.
RS-232 communication comes standard with the unit and a
TCP/IP card is optional. End users can configure each outlet
bank individually to customize for their home theater system.
7500-PRO's ground isolation
®
www.panamax.com
FEATURES
• Remote diagnostics (IP-ready with optional Ethernet card)
• Ground Isolation – Advanced Video Filtration
• Voltage regulation and Balanced Power
• Automatic Voltage Monitoring (AVM)
• Universal Coax Connectors for Satellite (SAT)
• and Cable Access Television (CATV) protection
• Telephone (TEL) and Local Area Network (LAN) protection
• Auto dimming meters
• DC trigger Input & Output
• 11 Outlets: 2 Always On, 6 Switched, 2 High Current,
• 1 Convenience (front)
• Rack Mounting Brackets Included
• Optional Silver Bezel
• Convenience lamp
L576 REV D 8/07
