Summarization of Contents
Important Safety Instructions
Electrical Safety Warnings
Cautionary notes regarding electric shock, opening the unit, and proper earthing connections.
Outdoor Use Prohibition
Prohibits use of ZxA1 speakers outdoors in direct exposure environments.
Hearing Damage Risk
Warns about sound pressure levels causing permanent hearing damage to users.
Temperature Limit Warning
Specifies maximum ambient temperature for trouble-free operation.
Tripod and Floor Monitor Operation
Floor Monitor Setup
Instructions for using the ZxA1 as a floor monitor, focusing on stability and cable management.
Tripod Mounting Guidelines
Guidelines for mounting the ZxA1 on tripod stands, ensuring stability and proper setup.
Amplifier Controls
Master Level Control
Adjusts overall amplification for line and microphone inputs; recommended setting 0dB to +6dB.
Limit LED Indicator
Indicates when the power amplifier is at its limits; constant light needs volume reduction.
Subwoofer/Fullrange Mode Switch
Activates a 100 Hz highpass filter for subwoofer use or as a floor monitor.
Line Input Connector
Electronically balanced input for high-level sources using 1/4" TRS or XLR connectors.
Master Output Connector
Output connector for sending signal to another speaker or subwoofer; sums MIC and LINE IN.
Microphone Level Control
Adjusts microphone input level independently of the master level.
Microphone Input Connector
XLR input for low-level signals like microphones; can be used with Line In as a 2-channel mixer.
Power Switch and Indicator
AC switch for turning the ZxA1's power ON or OFF; LED indicates power status.
Mains Power Connection
AC connection via IEC-connector; specifies voltage requirements for 120V and 230V operation.
