Protherm Panther 28 KTV Operating Instructions Manual

Panther 24 KTV / 24 KOV / 28 KTV
The boiler's Serial No. is shown on the plate which is attached to the rear side of the
control panel. The control panel is accessible after removing the front cover.
In section "Operating Instructions" you will fi nd description of the boiler's main functi-
ons and guidelines how to handle the boiler safely. Section "Installation Instructions" is
Obsah

Table of contents

Introduction........................................... 2
OPERATING INSTRUCTIONS
Controls and signals ............................. 4
Selacting Read mode ........................... 5
Selecting Setup mode ......................... 5
Schematic diagram of boiler control ..... 7
Error codes .......................................... 8
Starting the boiler up and shutting it down
.............................................................. 9
Boiler control ....................................... 10
Protection functions ............................. 12
Service and maintenance ................... 13
Warranty and warranty conditions ...... 14
Technical parameters ......................... 15
Connection dimensions ...................... 18
Usable pressure into system ............... 19
for skilled workers only.
INSTALLATION INSTRUCTIONS
Boiler operation scheme...................... 20
Introduction ......................................... 21
Installation distances ........................... 22
Delivery ............................................... 23
Special delivery ................................... 23
Delivery completeness ....................... 23
Preparing for installation ..................... 24
Installing the boiler .............................. 25
Air supply and combustion gases removal
system for KTV boilers ........................ 29
Electrical wiring ................................... 33
Converting to different fuel ................ 34
Electrical wiring diagram .................... 35
1
