Protherm Panther 24(12) KTO Operations & Installation Manual

Panther 24 (12) KTO and 24 (12) KOO
The boiler's Serial No. is shown on the plate which is attached to the rear side of the
control panel. The control panel is accessible after removing the front cover.
In section "Operating Instructions" you will find description of the boiler's main functions
and guidelines how to handle the boiler safely. Section "Installation Instructions" is for
Table of contents
Introduction ........................................... 2
OPERATING INSTRUCTIONS
Control and signals ............................... 4
Selecting Read mode ........................... 5
Selecting Setup mode ......................... 5
Schematic diagram of boiler control ..... 7
Error codes .......................................... 8
Starting the boiler and shutting it down 9
Boiler control ....................................... 10
Protection functions ............................ 11
Service and maintenance ................... 13
Warranty and warranty conditions ...... 14
Technical parameters ......................... 15
Connection dimensions ...................... 17
Usable presure into system ................. 18
Schematic diagram of boiler operation 19
Supplied By www.heating spares.co Tel. 0161 620 6677
skilled workers only..
INSTALLATION INSTRUCTIONS
Introduction ......................................... 20
Delivery completness .......................... 22
Preparing for boiler installation ........... 23
Installing boiler .................................... 24
Air supply and comustion gases removal
system (type KTO) ............................... 28
Electrical wiring of boiler ...................... 32
Interconnecting the boiler to water tank 33
Converting to different fuel ................. 34
Electical wiring diagram ...................... 35
