- Page 1 SupraPr SupraPr o I.D. o I.D. SupraPr o I.D. o I.D. SupraPr SupraPr o I.D. INSTALLATION AND OPERATION INSTRUCTIONS...
-
Page 2: Table Of Contents
MISSING PARTS ......................24 WARRANTY STATEMENT ..................... 25 UPS RETURN SERVICE ....................26 HOW TO OBTAIN SERVICE - INTERNATIONAL ............28 Copyright © 1995, 1996 Eagle Electronics All rights reserved. All features and specifications in this manual are subject to change without notice. -
Page 3: Introduction
The SupraPro I.D. has powerful features available through easy-to-use menus. To get started with your Eagle unit, first read the installation section. This is where it all begins. Improper installation can cause problems down the road. After you’ve read the instructions, install the unit, then read the rest of the manual. -
Page 4: Installation
INSTALLATION - Bracket You can install the SupraPro I.D. on the top of a dash or from an overhead with the supplied bracket. It can also be installed in the dash with an optional IDA-3 mounting kit. If you use the supplied bracket, you may be interested in the optional GBSA-1 swivel bracket kit. -
Page 5: Power Connections
DASH MOUNT POWER CONNECTIONS NOTE! INSTALL THE TRANSDUCER BEFORE MAKING THE POWER CONNECTIONS! The SupraPro I.D. works from a 12 volt DC system only. For the best results, run the power cable directly to the boat’s battery. Keep the power cable away from other boat wiring, especially the engine’s wires. -
Page 6: Portable Installation
SUPRAPRO I.D. PORTABLE ASSEMBLY INSTALLING THE BATTERIES Release the latch on the front of the battery case. Open the compartment and install four "D" cell batteries into the adapter. For the longest life, we recommend you use alkaline batteries. This battery case will also hold one rechargable battery instead of the "D"... - Page 7 portable units result from stale batteries. Make certain the ones you buy are fresh. Always remove batteries from the battery compartment before storing the unit as dead batteries can leak and corrode the contacts. In cold weather the efficiency of dry cell batteries drops with the tempera- ture.
- Page 8 Clean the chosen area of the hull before attaching the suction cup. Locate the transducer on the hull as shown below. Don't allow the bracket to go below the hull, as water pressure against it can cause the suction cup to come off at speed.
-
Page 9: Buttons Description
KEYBOARD BASICS The unit sounds a tone when you press any key. This tells you the unit has accepted a command. ON/CLEAR Use this key to turn the unit on. It also clears menu selections and the menus from the screen. This key turns the unit off. -
Page 10: Operation
OPERATION MENUS The SupraPro I.D. use menus to guide you through the unit’s functions and features. The menu key accesses these features, allowing you to custom- ize the unit to your particular needs and water conditions. All you have to do to leave one menu and enter another is press the menu key repeatedly. -
Page 11: Zoom
ZOOM The zoom feature enlarges all echoes on the screen. If the unit is in the automatic mode, it tracks the bottom signal, always keeping it near the bottom of the screen. This lets you see small detail, at the same time enlarging all echoes that appear on the screen. -
Page 12: Fishtrack
Fish ID feature’s menu appears as shown at right. Now press the down arrow key. This turns the feature off. To turn it back on, repeat the above steps, but press the up arrow key instead. The Fish ID feature can’t be used when the SupraPro I.D. -
Page 13: Sensitivity
changes all echoes to short horizontal lines, making it easy to determine the depth of a target.To change modes, press the MENU key until the “DISP MODE” (Display Mode) menu appears. Then press the up or down arrow keys to switch between modes. Mode 2 is shown at right. -
Page 14: Chart Speed
CHART SPEED The rate echoes scroll across the screen is called the chart speed. It’s adjustable by press- ing the menu key until the chart speed menu appears as shown at the top of the next page. Chart speed is set to maximum when the SupraPro I.D. -
Page 15: Back Light
alarm setting. When the number reaches the desired setting, release the arrow key. When the bottom depth goes shallower than the alarm’s setting an alarm tone sounds. At the same time the alarm sounds, a message box appears on the screen as shown at right. Press the up arrow key to silence the alarm. -
Page 16: Display Contrast
DISPLAY CONTRAST The unit’s display contrast is adjustable to suit different lighting conditions. This will help you see the screen from different angles, or at various times of the day. To adjust the contrast, press the menu key until the DARK/LIGHT menu appears. To de- crease it, press the down arrow key. -
Page 17: Simulator
The angle between the outside edges of the cone is the cone angle. Eagle offers a choice of transducers with either an 8 or 20 degree cone angle. The SupaPro I.D. can use many of these, however it requires a TA-301 adapter cable.The transducer supplied with the SupraPro I.D. -
Page 18: Signal Interpretation
20 degree cone angle allows you to see more of the underwater world. In 15 feet (5 meters) of water the 20 degree cone covers an area about six feet (2 meters) across. The 8 degree transducer covers only about a two foot (less than 1 meter) circle. - Page 19 SURFACE LAYER ABSORBS HEAT FROM THE SUN EPILIMNION THERMOCLINE MOST PRODUCTIVE ZONE FOR FISHING HYPOLIMNION While some fish have a wider temperature tolerance than others, each has a certain range within which it tries to stay. Schooling fish sus- pended over deep water lie at the level that provides this temperature. We assume they are the most comfortable here.
-
Page 20: Fish Arches
FISH ARCHES Fish arches are created when the cone of sound from the transducer passes over a fish. The distance to a fish when the cone first strikes it is shown as "A" below. When the center of the cone strikes the fish, the distance is shorter as shown "B". -
Page 21: Surveying A Lake
One of the best ways to get fish arches is to expand or “zoom” a segment of the water. For example, from 30 to 60 feet. The smaller the segment, the better the screen resolution will be. The easiest way to do this on the SupraPro I.D. -
Page 22: Sonar Troubleshooting
Most bait fish concentrate within five feet of the surface where sunlight promotes the growth of the plankton on which they feed. One method of fishing is to use the SupraPro I.D. to find the bait fish first. With the Fish ID feature off, a school of bait fish will look like a “cloud”... - Page 23 3. The water may be deeper than the sonar’s ability to find the bottom. If the sonar can’t find the bottom signal while it’s in the automatic mode, the digital will flash continuously. It may change the range to limits far greater than the water you are in.
- Page 24 ELECTRICAL NOISE A major cause of sonar problems is electrical noise. This usually appears on the sonar’s display as random patterns of dots or lines. In severe cases, it can completely cover the screen with black dots, or cause the unit operate erraticly, or not at all.
-
Page 25: Menu Summary
MENU SUMMARY The menus listed below are shown in order as you press the MENU key while the SupraPro I.D. is in the normal mode with automatic and Fish ID on. The order of the menus (and the menus themselves) will change as different features are selected, however this is the order the menus are in when the unit is first turned on. -
Page 26: Missing Parts
NOTICE! Please check the items in the box against this list. You should have all of the items shown on this page. If you are missing any of the items, please call our special toll-free number: 1-800-324-1353 A RECORDED MESSAGE will request the following information. Please have it ready before you call. -
Page 27: Warranty Statement
EAGLE ELECTRONICS FULL ONE-YEAR WARRANTY “We”, “our”, or “us” refers to EAGLE ELECTRONICS, a division of LEI, the manufacturer of this product. “You” or “your” refers to the first person who purchases this product as a consumer item for personal, family, or household use. -
Page 28: Ups Return Service
United States, use the enclosed UPS shipping label for easy, free shipping to our factory customer service department. There are six easy steps: 1.Call Eagle at the toll-free number on the front of this flyer for a Return Authorization (RA) number and instructions about what accessories to return. - Page 29 This UPS shipping offer is good only in the continental United States (excludes Alaska and Hawaii). Eagle Electronics may find it necessary to change or end our shipping policies, regulations, and special offers at any time. We reserve the right to do so without notice.
-
Page 30: How To Obtain Service - International
Notes:... -
Page 31: Accessory Ordering Information
How to Obtain Service (Canadian Customers Only) We back your investment in quality products with quick, expert service and genuine Eagle replacement parts. If you need service or repairs, contact the Eagle Factory Customer Service Department at the toll-free number listed below. A technician may be able to solve the problem and save you the inconvenience of returning your unit. -
Page 32: Eagle Electronics Po Box
Your unit is covered by a full one-year warranty. (See page 25 for complete warranty details.) If your unit fails and the failure is not covered by the original warranty, Eagle has a flat-rate repair policy that covers your unit and accessories packed with the unit at the factory. There is a 180-day warranty on all non-warranty repairs from the factory, which is similar to the original warranty, but is for 180 days rather than one year.
