Toshiba SG20 - Magnia - Web Server Customization Manual page 16

Customization
The file system reflects the following elements in its directory organization:
Directory
/sa2/templates
/sa2/lang
/sa2/triggers
/sa2/firewall
/sa2/conf
/sa2/lib
/sa2/web
/sa2/firewall
/sa2/log
/sa2/bin
This directory contains the configuration file templates
that are used to regenerate the system configuration
files.
This directory contains the HTML and other files used to
generate the actual Magnia SG20 user interface are
contained in this directory. Because the Magnia SG20
can support multiple languages, this area of the system
is separated into various language directory trees. For
example, the "/sa2/lang/en" tree is used to support
English.
This directory contains the trigger scripts invoked to
perform system reconfiguration and other maintenance.
This directory contains definition files for special firewall
rules. By adding new directories and files here, you can
add your own optional firewall rules.
This directory contains all the Magnia SG20 specific
configuration files. These configuration files are specific
to the Magnia SG20 implementation. These
configuration files do not replace the standard Linux
configuration files. The primary configuration file of
interest is "main.conf", which is the central file in which
most configuration items from the user interface are
placed.
This directory contains Perl and other modules used as
general routines to support the CGI code and other Perl
programs.
The Perl scripts, Java scripts, graphics and other Web-
based CGI code driving the Magnia SG20. Web sites
represented here are:
- System Administration (/sa2/web/admin)
- Preinstall Intranet (/sa2/web/intranet)
This directory contains subdirectories for each custom
firewall rule. Each subdirectory corresponds to a firewall
rule the user can enable or disable through the advanced
firewall settings option in the Web administration UI.
This directory contains logs specific to features
implemented in the Magnia SG20 user interface. The
logs in this directory do not replace the standard Linux
application logs typically contained in /var.
This directory contains general utility scripts and
programs used by the Magnia SG20 to interface with the
Linux system and the system hardware.
General system architecture
Description
16
