- Page 1 Installation Guide Media Application Server IMPORTANT! Installing Technician Please Read! This guide contains the essential information for the proper installation of the Media Application Server Chassis S T R A T A Media Application Server...
- Page 2 The Media Application Server (MAS) is registered in accordance with the provisions of Part 68 of the Federal Communications Commission’s Rules and Regulations. Service or Repair: For service or repair, contact your local Toshiba telecommunications distributor. To obtain the nearest Toshiba telecommunications distributor in your area, log onto www.toshiba.com/taistsd/pages/support_dealerlocator.html or call (800) 222-5805 and ask for a Toshiba Telecom Dealer.
- Page 3 TOSHIBA AMERICA INFORMATION SYSTEMS, INC. (“TAIS”) Telecommunication Systems Division License Agreement IMPORTANT: THIS LICENSE AGREEMENT (“AGREEMENT”) IS A LEGAL AGREEMENT BETWEEN YOU (“YOU”) AND TAIS. CAREFULLY READ THIS LICENSE AGREEMENT. USE OF ANY SOFTWARE OR ANY RELATED INFORMATION (COLLECTIVELY, “SOFTWARE”) INSTALLED ON OR SHIPPED WITH A TAIS DIGITAL SOLUTIONS PRODUCT OR OTHERWISE MADE AVAILABLE TO YOU BY TAIS IN WHATEVER FORM OR MEDIA, WILL CONSTITUTE YOUR ACCEPTANCE OF THESE TERMS, UNLESS SEPARATE TERMS ARE PROVIDED BY THE SOFTWARE SUPPLIER.
- Page 4 Stratagy ES or the use of a UPS not equivalent to that specified by TAIS are not covered by this warranty. The sole obligation of TAIS or Toshiba Corporation under this warranty, or under any other legal obligation with respect to the equipment, is the repair or replacement by TAIS or its authorized dealer of such defective or missing parts as are causing the malfunction with new or refurbished parts (at their option).
-
Page 5: Table Of Contents
MAS Modem Installation (Optional) ..................... 16 Step 1: Install Modem Driver Software on MAS................16 Step 2: Install Hardware and Configure Windows on MAS............17 Step 3: Client Configuration ......................... 19 Dial-up the MAS Modem ....................... 20 Strata CIX Media Application Server Installation 07/06... - Page 6 This page is intentionally left blank.
-
Page 7: Hardware
The monitor, keyboard and mouse are customer-supplied options. The MAS can be accessed via the network by using the Windows® XP Remote Desktop feature. *Monitor *Key Board *Mouse Network Switch *Optional Figure 1 MAS Connection Block Diagram Strata CIX Media Application Server Installation 07/06... -
Page 8: Physical Specifications
Two full length PCI card slots for FAX/Modem cards. Figure 2 MAS Front View Mouse Connector USB Ports Monitor Output Serial Port Keyboard Connector 1 Gb LAN Connector 10/100 Mb LAN Figure 3 MAS Connector Detail Strata CIX Media Application Server Installation 07/06... - Page 9 Hardware Input Power AC Input Power Switch Power Switch Reset < Switch AC Power Connector Figure 4 MAS Rear Panel Strata CIX Media Application Server Installation 07/06...
- Page 10 This page is intentionally left blank.
-
Page 11: Installation
The nut plate must go behind the post. The rail flange goes between the nut plate and the post. Nut Plate Outer Rail Rack Post Front Post Figure 6 Outer Rail Attachments Strata CIX Media Application Server Installation 07/06... -
Page 12: Step 2: Network Connection
The MAS requires a static IP Address. The MAS and the CIX (LCTU card) should be in the same network segment. The LIPU address must be assigned so that it can be pinged by the MAS. Strata CIX Media Application Server Installation 07/06... -
Page 13: Step 3: Configure Software
The LIPU card IP Address must be accessible by all IP devices (IPT, MAS). If IPT stations are going to be placed on the public internet, or Strata Net IP will be run on the public network without a VPN, the LIPU should have a public IP address. -
Page 14: Approved Third Party Application Software
Voice Mail. The third column shows the constraints of a system that is only configured with ACD. Table 2 Toshiba SES and Feature Flex - Maximum Number of Licenses Shown Voice Mail SES and... - Page 15 Installation MAS Configuration Requirements Table 2 Toshiba SES and Feature Flex - Maximum Number of Licenses Shown (continued) LICMAS-FG-UM, LICMASUM10SEATS, One Seat Unified Messaging Upgrade. LICMASUM25SEATS, Unlimited Unlimited LICMASUM50SEATS, LICMASUMUNLIMT One Number Access Enable LICMAS-FF-ONUM Text-To-Speech Feature Group. LICMASFGTTSETI Table 3...
-
Page 16: Step 4: Mas Licensing
For example; 20 voice mail ports and 10 ACD ports will require two MASs. Step 4: MAS Licensing For information about CIX Licensing see Chapter 10 in the Strata CIX and Strata CTX Programming Manual Volume 1 for CIX Licensing. -
Page 17: Step 4B: Upload Licenses
The MAS License Container File is an XML file generated by the FYI application. The file can be downloaded from FYI or the file can be mailed from FYI. If uploaded using this function, use the following procedure. Strata CIX Media Application Server Installation 07/06... -
Page 18: Step 4C: Issue Licenses
Windows scheduling process. Step 4E: Log out of eManager From the eManager Menu, click Logout to exit eManager. Strata CIX Media Application Server Installation 07/06... -
Page 19: Step 4F: Set Mas Static Ip Address
5. Restart the MAS by pressing the Reset Button the rear panel. Refer to Figure 4 page The computer will boot from the CD into the recovery environment. Note Until the recovery is complete the mouse will not function. Strata CIX Media Application Server Installation 07/06... -
Page 20: Step 1B: Setup For Windows Mini-Setup Wizards
A Caution dialog box stating that All data on the hard drive will be lost. Press the Y key on the keyboard. The Clearing Hard Disk Drive box will appear. Then the Toshiba - Symantec status screen will appear. -
Page 21: Step 1D: Setup Network Connections
6. Click on OK. END OF RECOVERY PROCEDURE Post Recovery Procedure The MAS is now in its as shipped condition. Go to “MAS Licensing” on page To setup the SES and ACD refer to their manuals. Strata CIX Media Application Server Installation 07/06... -
Page 22: Mas Software Backup
A Backup and Restore Utility is available for managing customer database information for all of the applications on the MAS. This utility is available for download, at no charge, on the Toshiba FYI website. Product Bulletin PBCIX-0031 describing this utility and how to use it is also available on the FYI website. -
Page 23: Step 2: Install Hardware And Configure Windows On Mas
6. In the Advanced Connection Options, click Accept incoming connections > Next. 7. In the Devices for Incoming Connections dialog box (shown right), check-mark Zoom V92USB Faxmodem, then click Next. 8. Select Do not allow virtual private connections (shown right), then click Next. Strata CIX Media Application Server Installation 07/06... - Page 24 11. In the Completing dialog box (shown right), click on Finish. 12. The MAS setup is complete. The remaining steps are performed at the computer that will be used to dial into the MAS. Strata CIX Media Application Server Installation 07/06...
-
Page 25: Step 3: Client Configuration
Typically this is through the Settings / Control Panel from the Start menu. 2. Select Connect to the network at my workplace, then click Next. 3. Select Dial-up connection as the Network Connection type (shown right). Strata CIX Media Application Server Installation 07/06... -
Page 26: Dial-Up The Mas Modem
Dial-up the MAS Modem 1. From the remote location computer, open the Network Connection. 2. In the Connect dialog box enter Valued Customer as the User Name. Enter the password, then click Dial. Strata CIX Media Application Server Installation 07/06... - Page 27 This is the last page of the document.
