2.4. STEP 4: Completing the Setup
Wizard
The first time you log in to the Dashboard, the Setup Wizard will load
in you browser (Fig. 13). The Setup Wizard consists of three sections
to be filled out that will help you to configure your d2 Network 2.
a. General Settings: Modify the Machine Name (optional - a
name may only contain letters (case sensitive), numbers, or
a hyphen. Maximum of 15 characters) and create the admin
login name and password (minimum 4 characters)).
IMPORTANT INFO: You may enter 4 to 20 characters using let-
ters (case sensitive), numbers, the hyphen, and the underscore. No
other symbols, punctuation, or spaces may be used. Do not begin
or end with a hyphen and/or an underscore.
IMPORTANT INFO: If for whatever reason you do not complete
the Setup Wizard, the default login credentials will be admin/admin.
b. Time Configuration: Select whether the time and date should
be set manually or synchronized with a third party server.
Press the Test button to ensure synchronization is working.
When the time synchronization option is selected, you can't
modify the time and date settings.
c. Disk Configuration: Specify how much of the total stor-
age should be made available when the drive is connected
to your computer via USB, and how much for when your
computer is connected to the network. You can modify this
amount from 0 GB to up to half the total capacity (default
is 0 GB).
If you choose to increase the USBShare size, it is necessary
to format the share. After completing the Setup Wizard, navi-
gate to Drive Information > USB Drive and select Format (for
details, see 4.11. Dashboard: Drive
Once you've finished, you can proceed to the Dashboard by clicking
Finish (Fig. 13).
Your d2 Network 2 is configured and ready to use. Proceed to the
following sections: 3. Accessing and Transferring Files and 4. Admin-
istering Your LaCie d2 Network
• DESIGN BY NEIL POULTON
Information).
2.
Fig. 13
IMPORTANT INFO: LaCie strongly recommends you do not in-
crease the USBShare size to more than 128 GB unless you format
USBShare to either NTFS or HFS+ using your operating system's
native disk utility.
NOTE: The machine name can be modified later from the Dash-
board.
NOTE: You can also change the language on this page (Fig.
TECHNICAL NOTE: If you need to assign a static IP address, refer
to section 2.6. Assigning a Static IP
Connecting to a Network
page 17
13, D).
Address for details.
