LaCie d2 Network 2
User Manual
1.4.3.
LED Behavior
The front LED indicates drive status and activity. This section describes the behavior of the LED indicators.
TECHNICAL
NOTE: Even if you have turned off the front LED using the administration page ("Dashboard", see 4.12. Dashboard: Eco Manage-
ment), events triggering a red light will always cause the front LED to turn on.
Front LED Color
Blinking blue
Occurs as the drive is booting; will cease once the drives are fully initialized
Solid blue
Drive working (read/write)
Temperature alert (first level)
Blinking red
Power supply has been cut but power is still being supplied through the UPS
Temperature alert (critic level) – the product will shut off
Solid red
Power supply has been cut and the UPS has run out of reserve power – the product will shut off
• DESIGN BY NEIL POULTON
d2 Network 2 State
Introduction
page 11
