Lexicon DC-1 Quick Reference page 2

DC-1 Dolby Digital
Exclusive RECORD/ZONE 2 Control Mode
RECORD/ZONE 2 Control
mode allows use of the
DC-1 in another room while
the room in which the DC-1
is located remains muted.
To enter RECORD/ZONE
2 Control mode, turn on the
DC-1 by pressing the
RECORD/ZONE 2 key on
the remote.
RECORD/ZONE 2 Control from the normal operating mode
In normal operation, press-
ing RECORD/ZONE 2 as-
signs (or de-assigns) the
current input selection to
the Record/Zone 2 outputs
without affecting the Main
outputs.
Pressing any key other than
the input selectors, MUTE,
VOLUME or BALANCE will
display the message:
ZONE 2 MODE ENABLED
KEY INVALID
To exit, press OFF.
* TAPE and VCR1 are normally
"BLOCKED" but can be changed in the
Setup Input Configuration menu.
Holding down RECORD/
ZONE 2 allows Volume and
Mute adjustments to affect
only the Record/Zone 2 out-
puts.
Lexicon, Inc. 3 Oak Park • Bedford MA 01730-1441 USA • Tel: (781) 280-0300 • Fax: (781) 280-0490
® ®
/DTS Quick Reference
Digital inputs can be se-
lected for the Record/Zone
2 outpus under the follow-
ing conditions:
• A digitial input must be as-
signed to the input via the
Setup menu.
• The input must have
Record/Zone 2 set to DIGI-
TAL.*
• The input must be selected
for Main outputs.
To access remote control
Zone 2 functions, press and
hold ACCY, then press
RECORD/ZONE 2. To re-
store remote control of the
main outputs, press and
hold ACCY, then press
SELECT.
Remote Control ACCY Functions
*To clear an assigned effect, while holding down ACCY, press BYPASS, then
press the associated input button.
Press and hold ACCY while pressing DONE to activate a
"You Are Here" mode which:
• Disables mute
• Sets Main and Zone 2 volume
to -30dB
• Centers Balance controls
• Loads the Pro Logic Effect
Input Effect Assignments
Note any Effects you have
assigned to the remote con-
trol input keys.
• Selects the VCR1 input
• Activates On-Screen display
with 2 second timeout
• Sets Remote Trigger ON
• Sets all tone controls to 0dB or
OFF
VCR1 _____________
VCR2 _____________
V-DISC ____________
TV _____________
AUX _____________
CD _____________
TUNER _____________
TAPE _____________
