Summarization of Contents
Installation
Positioning
Explains optimal placement for loudspeakers, considering distance and stability.
Levelling (spiked floor-stand mounting only)
Details the procedure for leveling loudspeakers using spikes and a spirit level.
Connecting
General
Important safety instruction to switch off all system components before making connections.
Terminals
Describes the binding-post terminals and how to connect various cable types.
Cable-routing
Explains routing cables through the stand for an invisible connection on specific models.
Configuration options
Introduces various connection options for improved sound quality.
Passive single-wiring
A single amplifier channel connects to the loudspeaker using one cable.
Passive multi-wiring (bi-wire, tri-wire or quad-wire)
Single amp channel uses two, three, or four cables for improved sound.
Passive multi-amping (bi-amp, tri-amp or quad-amp)
Multiple amp channels connect to the loudspeaker for better performance.
AKTIV operation
Replaces passive crossovers with external AKTIV ones for superior control and performance.
Link strip information
Details how to remove, fit, and modify link strips for different wiring configurations.
Wiring / amping configurations
Single-wiring
Describes single-wiring with no link adjustments required, using one cable from the amp.
Bi-wiring or bi-amping
Explains bi-wiring/bi-amping using two cables from one or two amp channels.
Tri-wiring or tri-amping
Details tri-wiring/tri-amping using three cables from one or three amp channels.
Quad-wiring or quad-amping (KOMPONENT 110 & 106)
Describes quad-wiring/quad-amping using four cables/channels on specific models.
AKTIV configuration
Explains AKTIV configuration, requiring modifications and careful connection of amplifier cables.
