L i n n A V P e r s o n a l H a n d s e t U s e r ' s G u i d e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AV Personal Handset and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Linn AV Personal Handset

Summary of Contents for Linn AV Personal Handset

  • Page 1 L i n n A V P e r s o n a l H a n d s e t U s e r ’ s G u i d e...
  • Page 2 The information in this manual is furnished for informational use only, is subject to change without notice, and should not be construed as a commitment by Linn Products Limited. Linn Products Limited assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.

  • Page 3: Table Of Contents

    Personal Handset...7 Key layout...7 General use of the handset...11 Recording macros...12 Examples of macros...13 using the AV 5101 with Linn equipment...14 Controlling Linn CD players...14 Controlling Linn tuners...16 Controlling Linn preamplifiers and amplifiers...17 Using the AV 5101 Personal Handset with KNEKT...18 programming the AV Personal Handset...19...
  • Page 4 n o t e s...

  • Page 5: Introduction

    – and so does your pleasure in viewing it. In designing your Linn AV system, we have set out to create the ultimate experience of cinema and music in the home and every component has been carefully designed to give you exactly that.

  • Page 6: Av 5101 Personal Handset

    AV 5 1 0 1 P e r s o n a l H a n d s e t The power and flexibility of the Linn AV system is entirely under your control, from wherever you are in the room, with the AV 5101 Personal Handset.

  • Page 7: Av 5140 Floor-Standing Loudspeaker

    AV 5 1 4 0 F l o o r - S t a n d i n g L o u d s p e a k e r The AV 5140 Floor-Standing Loudspeaker is the perfect choice for use as the front speakers in a surround sound installation.

  • Page 8: Av 5110 Local Loudspeaker

    The AV 5150 Active Isobarik Bass Speaker extends the bass performance of the whole system to give you totally involving cinematic effects and enhance the impact of music. We designed the AV 5150 Active Isobarik Bass Speaker to reproduce bass sounds as faithfully as our full-range loudspeakers, with the result that its contribution to the overall sound is extremely natural and unobtrusive.

  • Page 9: Making It Real

    … M a k i n g i t r e a l The Linn AV system has been designed to give you the most exciting and satisfying experience of cinema it is possible to achieve in the home. Our aim is to bring you the complete film as its creators intended: with images and sound working together in the most memorable way.

  • Page 10: About The Av 5105 Stereo Power Amplifier

    A b o u t t h e AV 5 1 0 5 S t e r e o P o w e r A m p l i f i e r The Linn AV 5105 Stereo Power Amplifier is intended for use in high performance audio and audio/video systems. It combines high output power, ruggedness, and ease of use with our passion for quality.

  • Page 11: Using The Personal Handset

    P e r s o n a l H a n d s e t The Linn AV 5101 Personal Handset puts you in control of your entire AV and hi-fi system from wherever you are sitting.
  • Page 12 Handset operation keys These keys determine the operation of the whole handset, or instruct it to learn commands: What it does STANDBY Switches the System Controller or a source to standby. KNEKT Selects the source from the main system in a KNEKT Multi-Room system.
  • Page 13 FM tuners. Press one of the Audio/Video source select keys to specify which source you want to control. The source control keys are initially set up to control Linn products. You can also program them for any of your other equipment using the Personal Handset LEARN function.
  • Page 14 These keys provide additional functions for controlling your audio and video sources. They can be programmed for the other equipment in your system using the LEARN function. These keys can also be used with Linn CD players and FM tuners to enter a track number, preset number, or station frequency.

  • Page 15: General Use Of The Handset

    STANDBY key, and KNEKT key can operate either the AV 5103 System Controller or another amplifier, if the Personal Handset has learnt its commands; see Programming the AV Personal Handset, page 19. To change from operating the AV 5103 to operating a learnt amplifier: Press the Audio/Video source select key for the learnt amplifier.

  • Page 16: Recording Macros

    R e c o r d i n g m a c r o s A very convenient and powerful feature built into the Personal Handset is the ability to record a sequence of your commands, and replay them with a single key press.

  • Page 17: Examples Of Macros

    E x a m p l e s o f m a c r o s Playing a video at night The following macro switches the System Controller on, selects Midnight Movie mode, selects the VCR source, and starts the video playing: STANDBY, QUIET, PROG, VCR, PLAY.

  • Page 18: Using The Av 5101 With Linn Equipment

    A V 5 1 0 1 w i t h L i n n e q u i p m e n t The Linn AV Personal Handset provides a range of special functions for controlling the Linn AV 5103 System Controller, and for setting it up to suit the other equipment in your system. For full information about using the Personal Handset with the System Controller please refer to the AV 5103 System Controller Owners Manual.
  • Page 19 Select a track by number like this Press the corresponding digit on the Personal Handset. To enter a track number greater than 9 press and hold down the key for the first digit until a dash appears on the CD player display, then press the key for the second digit.

  • Page 20: Controlling Linn Tuners

    C o n t r o l l i n g L i n n t u n e r s The Personal Handset lets you operate most of the functions of the Linn KREMLIN or KUDOS radio tuners. Select the radio tuner like this Press the TUNER Audio/Video source select key on the Personal Handset.

  • Page 21: Controlling Linn Preamplifiers And Amplifiers

    C o n t r o l l i n g L i n n p r e a m p l i f i e r s a n d a m p l i f i e r s You can control the Linn MAJIK control amplifier or WAKONDA and KAIRN preamplifiers using the Personal Handset, as described in the following sections.

  • Page 22: Using The Av 5101 Personal Handset With Knekt

    U s i n g t h e AV 5 1 0 1 P e r s o n a l H a n d s e t w i t h K N E K T Every KNEKT system is uniquely configured to suit your requirements; please consult your KNEKT installer for detailed information about using the Personal Handset with your installation.

  • Page 23: Programming The Av Personal Handset

    System Controller and any other Linn equipment in your system, the Personal Handset can learn commands from the infra-red handsets for other equipment you may own. This allows you to program your Linn Personal Handset so that it is the only handset you need in your system, allowing you to control all your hi-fi, audio, and video components from a single convenient keypad.

  • Page 24: Alignment Of Handsets

    A l i g n m e n t o f h a n d s e t s Before attempting to learn new commands align the AV 5101 Personal Handset and the infra-red handset as described in Diagram 1.

  • Page 25: Learning Commands From An Infra-Red Handset

    L e a r n i n g c o m m a n d s f r o m a n i n f r a - r e d h a n d s e t The AV 5101 can learn two distinct sets of commands these being either for a source (TV, CD, VCR, etc) or an amplifier.
  • Page 26 (C) Learning keys Press the programmable key you want to program on the Personal Handset. For example to program the PLAY key press PLAY. The LEARN indicator will flash slowly to show that the Personal Handset is ready to receive a function from the other infra-red handset. Press and hold the key you want to learn on the infra-red handset.

  • Page 27: Leaving The Learn Process

    L e a v i n g t h e L e a r n P r o c e s s In order to exit the Learn Process after having successfully learnt key functions from another handset. Press the LEARN key. The LEARN indicator will turn off to show that the Personal Handset is now back in normal mode.

  • Page 28: Maintenance

    m a i n t e n a n c e This chapter gives information about cleaning your Personal Handset, and replacing the batteries. C l e a n i n g t h e P e r s o n a l H a n d s e t Clean the Personal Handset like this Use a length of sellotape or masking tape to remove dust, hairs, etc.
  • Page 29 Replace the batteries like this Remove the old batteries and replace with four AAA or LR03 type batteries, checking the polarity carefully. Note: Do not touch the exposed contacts on the handset panel as this may damage the handset with static electricity. Re-assemble the handset like this Replace the panel in the handset case, locating the three LEDs in the corresponding holes in the case first.

  • Page 30: Appendix

    a p p e n d i x A U X 1 – A u d i o s t a c k r e c o r d p l a y e r Handset key Function STANDBY STOP * Stop PAUSE = Pause...

  • Page 31: Av 5103 System Controller

    AV 5 1 0 3 S y s t e m C o n t r o l l e r Handset key Function STANDBY Standby K N E K T Knekt QUIET Quiet SURR Surround MODE Program FROM Record from Record to PROG A/V Source...

  • Page 32: Laser - Laserdisc Player

    L A S E R – L a s e r D i s c p l a y e r Handset key Function STANDBY STOP * Stop PAUSE = Pause PLAY > Pl a y RECORD • SEARCH ¯ Search Reverse SEARCH ¼...

  • Page 33: Tape/Dat - Tape/Dat Recorders

    TA P E / D AT – Ta p e / D AT r e c o r d e r s Handset key Function STANDBY STOP * Stop PAUSE = Pause PLAY > Pl a y RECORD • Record SEARCH ¯...

  • Page 34: Tv - Tv Receiver

    T V – T V r e c e i v e r Handset key Function STANDBY STOP * Stop PAUSE = Pause PLAY > Pl a y RECORD • Record SEARCH ¯ Last Program/Channel SEARCH ¼ Search Up MULTI Scroll SKIP ”...
