Simrad PI Spread/Depth
Adding a Remote/Depth sensor
12
1
To reset the unit, set all six sensors to default sensor type
None.
2
Choose the sensor you wish to use for the PI Spread/Depth
sensor; 1 to 6.
3
Define the sensor type (by default None) to Dual.
4
Set
to the correct update rate.
Update
5
Set
to the chosen sensor type Spread.
Measure 1
6
Set the communication
7
Set
to the chosen sensor type Depth 300M, Depth
Measure 2
600M or Depth 1000M depending on the depth rating on
your PI Spread/Depth sensor.
8
Set the communication
9
Press the
button to save the changes and exit.
ENT
All sensors are provided with default communication channels
and update rates. Refer to the table in section About sensor
configuration on page 13.
As previously stated, the PI Spread/Depth sensor will occupy
two channels on your PI system. This means that although the
menu shows that six sensors are available, the last
Sensor setup
sensor will not have any measurements left. This is because you
are offered six measurements, and you have already used two of
these by putting the PI Spread/Depth sensor to work.
In order to achieve full control of the trawl, you may wish to add
a Remote/Depth sensor on the starboard trawl door. This sensor
will communicate with the Spread/Depth sensor to establish the
distance between the trawl doors, and it will provide you with the
accurate depth of the starboard trawl door. The Remote/Depth
sensor will only occupy one channel on your PI system.
to its correct value.
Channel
to its correct value.
Channel
315549/A
