Instruction Manual
1
INSTRUCTIONS FOR SAFE AND PROPER USE _____________________ 4
2
3
POSITIONING OF THE HOB _____________________________________ 8
4
ELECTRICAL CONNECTION ____________________________________ 13
5
GAS CONNECTION ___________________________________________ 14
6
ADAPTATION TO DIFFERENT TYPES OF GAS _____________________ 16
7
FINAL OPERATIONS __________________________________________ 19
8
USING THE HOB______________________________________________ 22
9
CLEANING AND MAINTENANCE_________________________________ 25
THESE INSTRUCTIONS ARE VALID ONLY FOR END USER COUNTRIES
WHOSE IDENTIFICATION SYMBOLS APPEAR ON THE COVER OF THIS
MANUAL.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the
authorized person who is to check the gas supply system and install,
commission and test the appliance.
INSTRUCTIONS FOR THE USER: these contain user advice,
description of the commands and the correct procedures for cleaning
and maintenance of the appliance.
@
Further product information is available from the website www.smeg.com
Contents
3
