Acme Furniture Madison II 19557EK-HB(3A) Assembly Instruction

ASSEMBLY INSTRUCTION FOR ACME FURNITURE
MODEL # 19557EK-HB(3A) / 19558EK-FB(3A) / 19559EK-R(3A)
Thank you for purchasing the quality product.Be sure to check all packing material carefully for small parts which may
have come loose inside the carton during shipment.Separate,indentify and count all parts and metal hardware. Compare
with all parts list to be sure all parts are present.If any part(s) are missing or damaged, please contact your local furniture
dealer. For efficient and speedy service,please indicate the model number and code letter of parts(s) needed.
DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
***Do not fully tighten screws until fully assembled***
COMPONENT PARTS
HEADBOARD
HEADBOARD LEFT & RIGHT
HEADBOARD LEG SUPPORT
FOOTBOARD
SLAT
CENTER SLAT
SLAT SUPPORT
TRUNDLE DRAWER FRONT PANEL
TRUNDLE DRAWER SIDE PANEL
TRUNDLE DRAWER BACK PANEL
TRUNDLE DRAWER BOTTOM PANEL
TRUNDLE DRAWER BOTTOM
SUPPORT WITH CUSTOR WHEEL
TRUNDLE DRAWER BOTTOM
SUPPORT
SIDE RAIL(L&R)
PART NAME Q'TY (PCS)
1
2
1
1
9
2
4
2
4
2
2
4
4
2
PAGE 1/5
