Kuryakyn 5019 Installation Manual

ENGINE GUARD MOUNT DRIVING LIGHTS
PARTS INCLUDED
2 Driving Lights with Pivot Mount
2 Engine Guard Clamp Assemblies Including:
2 Clamp Caps-Installed on Clamp
2 3/8"-16 Nylock Hex Nuts-Under Clamp Cap
4 #10-24 X 1/2" Socket head Cap Screws
1 Wiring Kit Containing:
6 Female Scotch Locks
6 Male Scotch Locks
4 Bullet Connectors
4 Male Bullet Connectors
1 Pin Terminal Connector
1 Contact Receptacle
10 6" Black Cable Ties
2 Dielectric Grease Packs
1 Installation Instructions
Please read and understand entire instructions before starting installation.
THANK YOU FOR CHOOSING K
IN ORDER TO PROTECT YOU AND OTHERS FROM POSSIBLE INJURY AND/OR
PROPERTY DAMAGE OR LOSS, PLEASE PAY CLOSE ATTENTION TO ALL
INSTRUCTIONS, WARNINGS, CAUTIONS AND NOTICES REGARDING THE USE
AND CARE OF THIS PRODUCT.
IF INSTALLING THIS PRODUCT FOR ANOTHER PARTY,
PLEASE MAKE SURE THEY RECEIVE THIS COPY OF THE
INSTALLATION INSTRUCTIONS SO THEY ARE AWARE OF
THE IMPORTANT INFORMATION CONTAINED IN THEM.
TOOLS SUGGESTED
Set of Hex and Torx Wrenches, Wire Strippers/Crimpers, Test Light, Phillips Screwdriver
STRICTLY OBSERVE THE FOLLOWING GUIDELINES IN ORDER TO USE THE
PRODUCT PROPERLY AND AVOID POTENTIALLY DANGEROUS ACCIDENTS.
STEP 1
Read and understand all steps in the instructions before starting the
installation. Park the motorcycle on a hard, level surface and turn off the
ignition. Let cool.
5019-23MC-0513 -cont.-
ϋ
RYAKYN!
THIS INDICATION ALERTS YOU TO THE FACT THAT
IGNORING THE CONTENTS DESCRIBED HEREIN CAN
RESULT IN POTENTIAL DEATH OR SERIOUS INJURY.
This indication alerts you to the fact that ignoring the
contents described herein may negatively affect product
performance and functionality.
This indication alerts you to the fact that ignoring
the contents described herein can result in potential
injury.
INSTALLATION
5019
CUSTOMER SERVICE
877.370.3604 (toll free)
INSTALLATION QUESTIONS
techsupport@kuryakyn.com
or call 715.247.2983
