Kuryakyn 5670 Installation Instructions

SADDLEBAG TOP TRIM
Thank You For Choosing Küryakyn!
Protect yourself and others from potential injury and property damage or loss. Pay close attention to all instructions, warnings, cautions, and notices
regarding the installation, use, and care of this product.
ENSURE THAT THE FOLLOWING PARTS HAVE BEEN INCLUDED IN THE KIT:
1 Left Front Accent
1 Right Front Accent
1 Left Rear Accent
1 Right Rear Accent
2 Alcohol Pads
1 Installation Instructions
YOU WILL ALSO NEED:
Warm, soapy water and clean rag, masking or painter's tape, marker
STEP 1 Read and understand all steps in the instructions before starting the installation. Park the motorcycle on a hard, level surface and turn
IGN OFF.
STEP 2 Refer to PIC 1. Using warm soapy water and a clean
rag, remove all dirt and debris from the installation
areas; allow the areas to dry completely.
Wipe the installation areas with the included alcohol
pads to remove any wax or polish; allow the areas to
dry completely.
STEP 3 Test fit the Accents as shown in PIC 2. "Hook" the bot-
tom tip on the edge of the saddlebag; align the Accent
with the existing lower trim. Rotate the Accent up into
place; align it so the reveal is even. Use masking tape
to make alignment marks; remove the Accents.
STEP 4 Use your fingernail to rub the adhesive backing; this will
activate the adhesive. Remove and discard the backing.
STEP 5 Align the Accents; press into place for one minute; full
bonding will occur after 24 hours. Remove and discard the masking tape.
STEP 6 Repeat for the other side.
NOTE: If the bike is going to be operated before full bonding occurs, secure the Accent to the fairing with a good quality
masking or painter's tape.
5670-11MC-0715
This indication alerts you to the fact that ignoring the contents described herein may negatively affect product per-
formance and functionality or damage the product itself or the product to which it is being attached.
FRONT OF SADDLEBAG
ALIGN THE
TOP SO
THERE IS AN
EVEN REVEAL
PIC 1
CLEAN + DRY
REAR OF SADDLEBAG
PIC 2
"HOOK" THE ENDS;
ALIGN WITH EXISTING
LOWER TRIM
5670
