Adesso 3677-01 Assembly Instructions

Part (G)
Pole (F)
Pole (E)
Pole (D)
Pole (C)
Pole (B)
Base (A)
Assembly Instructions (English)
ASSEMBLY INSTRUCTIONS FOR
SWIVEL FLOOR LAMP
Model # 3677-01
Model # 3677-22
Shade (H)
Socket Ring (I)
Point (J)
1. Screw the pole (B) clockwise into the base (A)
to tighten.
2. Screw the pole (C) clockwise into the pole (B)
to tighten.
3. Screw the pole (D) clockwise into the pole (C)
to tighten.
4. Screw the pole (E) clockwise into the pole (D)
to tighten.
5. Screw the pole (F) clockwise into the pole (E)
to tighten.
6. Screw the part (G) clockwise into the pole (F)
to tighten. Pull the remaining slack of the power
cord out carefully through point (J).
7. Remove socket ring (I) from shade holder on the
part (G) and hold shade (H) on socket while
re-attaching socket ring to secure the shade to
the shade holder.
GENERAL PRODUCT INFORMATION:
This product is suitable
for dry locations only.
IMPORTANT SAFETY INSTRUCTIONS:
This portable lamp has a polarized plug (one
blade is wider than the other) as a feature to
reduce the risk of electric shock. This plug will fit
in a polarized outlet only one way. If the plug does
not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician. Never
use with an extension cord unless p ug can be
fully inserted. DO NOT ALTER THE PLUG.
BULB TYPE: (1) 3-way 100 watt incandescent or
26 watt CFL equivalent.
(not included)
21 Penn Plaza Suite 909 New York, NY 10001
Tel: (212) 736 4440 Fax: (212) 736 4806
3677 1.0
