460 HORIZON DR. SUITE 400 | SUWANEE, GA 30024 | PHONE: 770-614-6101 | FAX: 770-614-6069 | info@omix-ada.com
Contents:
1. Upper Clamp Bracket
2. Lower Clamp Bracket
3. Crossbar Bracket
NOTICE
Crossbar adapters are designed to work Thule® and Yakima® accessories and
mount to Rugged Ridge® 11703.01, 11703.02 or other 2" or 50mm tubing.
PHONE: M-F 8am - 5pm EST 1-800-449-6649 | EMAIL: techsupport@omix-ada.com
Crossbar Adapters
(4)
(4)
(4)
3
4
2
Read all instructions thoroughly before installation.
OMIX-ADA
FOR WARRANTY INFORMATION VISIT: www.Omix-Ada.com
Copyright © 2013 Omix-Ada
4. M6x20 Flange Bolts
5. M6 Nylon Lock Nuts
6. M6 Flat Washer
5
TECHNICAL SUPPORT
®
, Inc.
®
1
6
Page 1/2
11703.10
(16)
(24)
(24)
