brondell VivaSpring FF-15 Installation Manual

VivaSpring FF-15
Replacement Cartridge Installation
BEFORE YOU BEGIN
When changing the Filter Cartridge, rubber gloves are recommended to
help get a better grip on the housing.
While installing or re-installing the VivaSpring filtered shower head, we
recommended wrapping a rag or small towel around the Inlet Collar
before you tighten with a wrench to avoid scratching the finish.
Caution - Risk of Personal Injury! If the water temperature is
set too high, scalding will occur. The water temperature should
never be set above 120°F (49°C). Do not use this Brondell
low-flow product with a shower valve that allows the water
temperature to become too hot.
FILTER REPLACEMENT
10,000 gallons, or six months of use, with the Brondell FF-15
Replacement Filter Cartridge.
1. Open the Shower Head: Rubber gloves are recommended to help
get a better grip on the housing. With one hand, grasp the back half
of the Shower Head tightly. Using your other hand, turn the front
half of the Shower Head counter-clockwise until the two halves are
separated.
2. Remove the used Filter Cartridge by pulling it out from the Filter
Housing in the back half of the Shower Head.
Cartridge into the housing – the Cartridge can be installed either
side up.
4. Close the Shower Head by screwing the two halves back together
tightly.
5. Turn water on and check for leaks. Tighten the connection as
necessary. Flush the Filter Cartridge by running the shower for 2
minutes, or until the water runs clear.
PERFORMANCE DATA SHEET
Brondell, Inc.
PO Box 470085
San Francisco, CA 94147-0085
888-542-3355
Replacement Filter Catridge Model #FF-15
SPECIFICATIONS and OPERATIONAL LIMITS
Rated service flow
Capacity
Operating pressure range
Operating temperature range 40°–120° F / 4°–49° C
This system has been tested according to NSF/ANSI 177 for the reduction of
free available chlorine. The concentration of free available chlorine in water
entering the system was reduced to a concetration less than or equal to the
permissable limit for water leaving the system, as specified in NSF/ANSI 177.
The system has not been evaluated for free available chlorine reduction per-
formance in the presence of chloramines. Free available chlorine reduction
performance may be impacted by the presence of chloramines in the water
supply. Please contact your local water utility to determine if chloramines are
used in treating your water.
INFLUENT
PARAMETER
CHALLENGE
Free Available 2mg/L FAC
Chlorine (FAC)
Testing was performed under standard laboratory conditions. Actual
performance may vary.
GENERAL INSTALLATION/OPERATION/MAINTENANCE REQUIREMENTS
• Install in compliance with state and local laws and regulations.
• Filter Cartridge should be replaced when rated capacity is reached, or
when there is a reduction of flow.
• The system is not to be used for drinking water purposes.
System Tested and Certified by IAPMO against
NSF/ANSI Standard 177 for the reduction of
free available Chlorine (FAC).
2.0 gpm / 7.6 lpm
10,000 gallons / 38,000 liters
40–100 psi / 280–690 kPa
MINIMUM CHLORINE
REDUCTION
≥ 50% FAC
