Summary of Contents for Hohem iSteady X3
- Page 1 User Manual V1.0 Tutorial Video...
-
Page 2: Table Of Contents
08 Buttons & Working Mode · ··············· Buttons ··························· Working Mode · ······················ 09 Remote Control Operation · ·············· 10 Indicators · ························ 11 Hohem Joy App ······················ Downloading ························ Gimbal Connection · ··················· Camera Interface · ···················· 12 Auto Calibration & Firmware Update · ········... -
Page 3: Product List
Product List iSteady X3 Magnetic Fill Light Remote Controller USB-C Charging Cable Hex Key Storage Pouch Quick Start Guide Warranty Card... -
Page 4: Overview
Overview Front ① Magnetic Fill Light ② Phone Clamp ③ Magnetic Mount ④ Folding Lock ⑤ Safety Locks ⑥ Folding Arm ⑦ Mounting Hole ⑧ Built-in Extension Rod ⑨ Side Wheel ⑩ Bluetooth Indicator ⑪ Gimbal Battery Indicator ⑫ Remote Connection Indicator ⑬ Pogo Pins Magnetic Remote Controller ⑲ Joystick ⑭ Adjustment Button & Indicator ⑳ Remote Connection ⑮ Bluetooth... -
Page 5: Charging
If the pan motor's base is loose, use the included hex key to tighten the hex screw clockwise. Charging Please fully charge iSteady X3 before using it for the first time. Charging Method: Please use the standard USB-Type C charging cable to connect to the Type-C charging port on the gimbal handle for charging. -
Page 6: Unfolding & Folding
To set the default orientation for your smartphone upon startup with the iSteady X3： *Ensure that the gimbal's Bluetooth is connected to your smartphone. Tutorial Video ① Open the Hohem Joy App ② Tap to "Gimbal Parameter on your smartphone. Tap Settings". "Settings". ①... -
Page 7: Folding
② Folding lock Mounting hole Usage Modes There are 3 usage modes of iSteady X3: Handheld Mode, Extended Mode, and Remote Mode. Handheld Mode Simply unfold the gimbal for on-the-go shooting. Extended Mode Pull out the built-in extension rod upwards and slightly tilt the hinge area to the preferred angle for shooting. -
Page 8: Magnetic Fill Light
Magnetic Fill Light Attachment Attach the magnetic Fill light, make sure it is aligned with the magnetic mount. Operation The fill light supports three color temperatures: cool, warm, and neutral, along with stepless dimming from 4% to 100%. Side Wheel Long press: Turn on/off the fill light Double press: Switch color temperature C/W/ Scroll up: Increase the brightness... -
Page 9: Bluetooth Connection
Bluetooth Connection ① Make sure the gimbal is powered on. ② Activate Bluetooth on your smartphone and select the device named "SX3-XXXXXX" from the list of available devices. ③ Follow the on-screen instructions to connect and pair. ④ A steady light on the Bluetooth indicator signifies a successful connection. -
Page 10: Working Mode
Working Mode iSteady X3 three-axis gimbal includes three axes of rotation: pan, tilt, and roll axes. The collaborative work between different axes results in the creation of 4 Working Modes, each tailored to specific filming needs: Tutorial Video Roll axis... -
Page 11: Remote Control Operation
*Notes: This feature requires the gimbal to be connected to the smartphone via Bluetooth. 2. It is available exclusively through the Hohem Joy App after connecting via Bluetooth. 3. When the remote control is attached to the gimbal, it can... -
Page 12: Indicators
Indicators Gimbal Handle ① ② ③ Solid light: Bluetooth connected Quick flash*3: Bluetooth pairing cleared (remote control power on/off) ① Bluetooth Indicator Slow flash: Gimbal firmware updating Off: Bluetooth disconnected Solid light: Battery level 50%-100% Solid light: Battery level 20%-50% ② Gimbal Battery Solid light: Low battery Indicator Quick flash: Shutting down soon... - Page 13 Remote Control ② ⑤ ① ③ ④ Solid light: Roll rotation control Flash: Fill light control ① Adjustment Off: Zoom in/out Indicator Solid light: Bluetooth connected Quick flash*3: Bluetooth pairing cleared (remote control power on/off) Slow flash: Gimbal firmware updating ② Bluetooth Off: Bluetooth disconnected Indicator ③ Working Mode...
-
Page 14: Hohem Joy App
Hohem Joy App Downloading Scan the QR code or search "Hohem Joy" in App Store / Google Play to download the App. Download on the Gimbal Connection ① Attach your smartphone and turn on iSteady X3. ② Turn on Bluetooth on your smartphone. -
Page 15: Auto Calibration & Firmware Update
Mode indicators pulsing, indicating standby mode. Double-tap the power button to exit standby and retry calibration. Firmware Update You will be prompted in the Hohem Joy App if a new firmware update is available. Follow the on-screen instructions in the App to update firmware. -
Page 16: Specifications
(Used without Fill light unit) Approx. 4 hours (Used with the fill light at maximum Operating Time brightness) *Data sourced from Hohem Laboratory. Measured under ideal conditions with the gimbal fully balanced. Charging Time Approx. 2 hours (5V-2A) 0.8W (Used without the fill light, measured... -
Page 17: Compliance Information
EM emission above the reference level as specified in EC Council Recommendation(1999/519/EC). Hereby,[Shenzhen Hohem Technology Co.,Ltd.] declares that the radio equipment type [HPG-X3P, HRT-04] is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www. - Page 18 RF Exposure This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. IC Statement This device complies with CAN ICES-003 (B)/NMB-003(B). This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 19: Warning & Disclaimer
Warning & Disclaimer Thank you for purchasing the Hohem product. By using this product, you hereby signify that you have read this disclaimer and warning carefully. In addition, you understand and agree to abide by the terms and conditions herein. You acknowledge that you are solely responsible for your own conduct while interacting with this product, and for any consequences thereof. -
Page 20: Call Center -Toll Free
CALL CENTER -Toll Free UNITED STATES: +1(888)9658512 Mon-Fri: 9:00AM-5:00PM(EST) UNITED KINGDOM: +44(0)808 2737578 Mon-Fri: 2:00PM-10:00PM(GMT +0) CANADA: +1(855)758 8939 Mon-Fri: 9:00AM-5:00PM(EST) BRAZIL: +55 (0)800 5911897 Mon-Fri: 10:00AM-6:00PM(GMT -3) Email: service@hohem.com Website: www.hohem.com Manufacturer: Connect us at Shenzhen Hohem Technology Co., Ltd. Facebook... - Page 21 www.hohem.com...
