- Page 1 WHITE ROCK LIGHTS + Magnet INSTRUCTION MANUAL SPECIFICA TIONS Input Voltage DC 12V Input Power Max 2.4Watts per pod LED Color 12pcs - White per pod Raw Lumens 1100 LM (8 Pods Combined) Waterproof IP68 (Only Pod) Operating Temperature -5℉ - 120℉...
-
Page 2: Main Components
MAIN COMPONENTS 8 X PHOTON WHITE 8 X VHB DOUBLE SIDED ROCK LIGHT POD ADHESIVE TAPE 16 X HIGH QUALITY 32 X MOUNTING SCREWS 30 X ZIP TIE MAGNETS WHERE TO INST ALL FRONT REAR RECOMMENDED LOCATIONS FOR ROCK LIGHT PODS... - Page 3 3 WA YS TO MOUNT THE ROCK LIGHT POD STEP 1 There are 3 installation methods for you to choose, you can refer to the following methods to install. Use “Strong Magnets” for mounting as OPTION 1 shown in Fig. 1 FIGURE 1 Use “Self-Drilling Screws”...
- Page 4 Dustproof Light indication EASY TO CONTROL OPT7 Rock Lights 5-Pin ON/OFF Rocker Switch with Jumper Wires are designed to turn on/off the Photon Rock Lights easier. Light Indication Design: Easy to operate and locate in plain sight or darkness. Dustproof Design: Avoid dust cluttering rocker switch...
- Page 5 The installation guide is provided as assistance to reduce set up time. DISCLAIMER OPT7 Lighting is not liable for damages or personal injuries while installing this product. The Installation Guide is intended as assistance to reduce setup time. OPT7 Lighting assumes no responsibility for improper installation.
