modway Veer EEI-825-BLK Assembly Instruction

PART QTY
①
1 Star Base
②
1 Cylinder Column
③
1 Control Mechnism
④
1 Seat
⑤
1 Back Frame
NOTE:The discarded packaging for the unit can be used as a helpful way to support it during the assembly process.
STEP 1.
STEP 4.
UNDERSIDE OF CHAIR
· USE THIS PRODUCT ONLY FOR SEATING ONE PERSON AT A TIME.
· DO NOT USE THIS CHAIR AS A STEP STOOL/LADDER.
· DO NOT SIT ON ANY PART OF THE CHAIR EXCEPT THE SEAT.
· DO NOT USE CHAIR UNLESS ALL BOLTS, SCREWS AND KNOBS ARE
TIGHT.
· IT'S ADVISED TO PERIODICALLY CHECK ALL BOLTS, SCREWS
AND KNOBS TO BE SURE THEY ARE TIGHT.
ASSEMBLY INSTRUCTION
Remove all items from the carton.Verify all pieces before assembly
PART QTY
⑥
1
⑦
1
A 4
B 4
C 4
STEP 2.
AS WITH ALL MOVABLE MECANICAL DEVICES; IT
IS ADVISED TO PERIODICALLY CHECK TO MAKE
SURE ALL BOLTS, SCREWS AND KNOBS ARE
FULLY TIGHTENED TO ENSURE STABILITY.
PREVENTIVE MAINTENANCE AND WARNING!
Veer office chair - EEI-825
www.modwayfurniture.com
Left Arms
Right Arms
Allen Bolt 6 x 25 x10 mm
Allen Bolt 6 x 20 x 10 mm
Allen Bolt 6 x 35 x10 mm
· IF ANY PARTS ARE MISSING, BROKEN, DAMAGED OR WORN, STOP USE
OF THE PRODUCT UNTIL REPAIRS ARE MADE USING FACTORY
AUTHORIZED PARTS.
WARNING: TO AVOID DANGER OF SUFFOCATION, KEEP THIS PLASTIC BAG AWAY FROM BABIES &
CHILDREN. DO NOT USE THIS BAG IN CRIBS, BEDS, CARRIAGES, PLAY PENS OR AS HEAD COVERING.
· FAILURE TO FOLLOW THESE WARNINGS COULD RESULT IN SERIOUS INJURY.
KEEP THIS PAGE FOR FUTURE REFERENCE.
PART QTY
D
4 Washer
E 1
Allen Wrench
F 5
Caster
G 2
Cap Cover (Upper)
H 2
Cap Cover(Lower)
STEP 3.
BACK OF CHAIR
NOTICE:
ATTACH BACK TO ARMS,
AND FULLY TIGHTEN ALL SCREWS.
CONTROL MECHANISM SUPPLEMENT
1.While seated,lean forward,lifting your
body weight from the seat.Reach
underneath the right side of the chair and
located the Height Adjustment Handle.lift
the handle up slowly to allow the chair to
rise to the desired height.To lower the
seat height,lift the handle slowly while
seated.
2.Use the Tilt adjustment Knob to control
how far back your chair will lean.
TO ALLOW free movement,rotate the Tilt
Adjustment Knowb toward the LEFT.
TO INHIBIT free movement,rotate the Tilt
Adjustment Knob toward the RIGHT
