Siemens GNF322RA Manual

Cat. No. GNF322RA Cat. No.
Non-Fusible General Duty Safety Switch
60 Amps Maximum
Type 3R Rainproof
HP Ratings
Max. HP
Suitable for use as Service Equipment when used with ground bar kit HG61234 on 3 phase,
3 wire systems or when used with HN22A neutral kit on 1 phase, 3 wire or 3 phase, 4 wire
systems.
Fuse and Short Circuit Information
This switch is suitable for use on a circuit capable of delivering not more than 100,000
amperes, RMS symmetrical, 240 volts maximum when protected by class J, R or T fuses rated
60 amperes maximum.
Danger! Unless Class J, R or T fuses are used to protect this switch, it may present a risk
of fire and injury to persons if installed on circuits capable of delivering more than 10,000
amperes, RMS symmetrical.
This switch is suitable for use on a circuit capable of delivering not more than 10,000 amperes,
RMS symmetrical, 240 volts maximum, when protected by Class K fuses, Class H fuses or a
UL Listed Circuit Breaker rated for 10,000 amperes, RMS symmetrical, 240 volts maximum.
This switch is suitable for use on a circuit capable of delivering not more than 10,000 amperes,
250 volts DC maximum, when protected by fuses marked with an interrupting rating of 10,000
amperes, 250 volts DC.
Danger! Unless fuses marked for an interrupting rating of 10,000 amperes at 250 volts DC
are used to protect this switch, this switch may present a risk of fire and injury to persons if
installed on circuits capable of delivering more than 10,000 amperes.
Terminal & Wire Information
Description
Line / Load Lugs
Neutral Lugs
USE 75°C COPPER WIRE ONLY
Accessories
Ground Lug Kit: HG61234
Neutral Kit: HN22A
Hub Kits: ECHA075 (3/4"), ECHA100 (1"), ECHA125 (1-1/4")
1
Use outer two poles.
12
Wire range per NEC wire-bending requirements.
For questions on this device please call 1-800-241-4453.
http://www.usa.siemens.com/powerdistribution
s
240VAC 240VAC
1
1Ø 3Ø
10
Lug Size
14 – 2 AWG
14 – 4 AWG
240 Volts AC (V
250 Volts AC (V
250VDC
15 10
Wire Range
12
14 – 6 AWG 35 lb-in. 14-10 AWG / 40 lb-in. 8 AWG /
14 – 6 AWG 20 lb-in. 14-10 AWG / 25 lb-in. 8 AWG /
1
Wire Tightening Torque
45 lb-in. 6 AWG
35 lb-in. 6 AWG
Patents Pending
Siemens Industry, Inc.
Norcross, GA 30092 U.S.A.
Assembled in Mexico
Pc. No. R500587S00
Type VBII
) Maximum
) Maximum
