E-Z UP SR104TCBL04 Instructions

S S U
idewall et
Step 1.
Completely set up your E-Z UP
in the area that you intend to shade according to the
owners manual instructions.
To get full optimal sidewall coverage, set frame legs to the
3rd height adjustment hole/or middle setting.
Step 2.
Attach sidewall to frame as shown. (2a) Attach
quick attachment truss clips around the top truss as shown.
Step 3.
Wrap quick attachment hook and loop straps around the
legs of the shelter. (3a) Press straps into pad firmly.
Note:
•
The top of the sidewall tucks underneath the valance of the
fabric top.
•
All professional E-Z UP
sides to fully enclose your E-Z UP
sidewalls if desired.
•
To ensure proper sidewall fit, slightly position legs inward and then attach sidewalls. Walls should be
attached BEFORE frame is staked or secured down.
Sidewall Care:
Use a mild soap (not detergent) and plenty of water for cleaning.
Let the E-Z UP ® Instant Shelter
Important Information:
• Always stake or weigh down your shelter. Do not use in any
potentially windy or rainy weather. Wind and rain can damage the
E-Z UP Instant Shelter product and may also result in injury to you
® ®
or others. Therefore, do not rely on shelter for protection in heavy
or prolonged rain storms.
• The E-Z UP Instant Shelter
®
shelter. Do not leave up for extended periods.
© Copyright 2015 International E-Z UP, Inc. USA. All rights reserved. IN.SH.SW.0325
S
helter
p
Instant Shelter
®
sidewalls have zippers on both
®
® Instant Shelter
® top, frame and sidewalls dry completely before closing or storing to avoid mildew.
product is designed as a temporary
®
INTERNATIONAL E-Z UP, INC.
1900 Second Street, Norco, California 92860 USA
Phone (951) 279-0999 • Fax (951) 279-0888
I
nstructIons for
S
idewall
®
Auto Slider
®
Pull Pin
Quick
Attachment Strap
Leg
Diagram of installed sidewall
