Corsair K63 Manual

INTRODUCTION

Experience ultimate gaming freedom with the CORSAIR K63 Wireless Mechanical Gaming Keyboard featuring ultra-fast, 1ms 2.4 GHz wireless technology combined with CHERRY MX mechanical keyswitches for maximum performance. Advanced wireless features include Bluetooth 4.2 for flexible connectivity and 128-bit AES wireless encryption to help protect the transmission of your data. The compact, tenkeyless design is space saving and travel friendly with up to 25 hours of battery life at low brightness. Vibrant, blue LED backlighting is customizable per-key using iCUE software to create dynamic lighting effects. Dedicated multimedia controls, 100% anti-ghosting, full-key rollover, and Windows key lock mode delivers complete and responsive control. Detachable, soft-touch wrist rest provides comfort to enhance your gameplay.

BEFORE FIRST USE

The K63 wireless keyboard must be fully charged before its first use.

EXTENDING BATTERY LIFE

Reducing brightness to low (33%) will provide up to 25 hours of battery life. Increased brightness levels will use more power and reduce battery life.

LOW POWER MODES

The keyboard will turn off the backlighting after 15 minutes and go to sleep which will greatly extend battery life. This setting can be adjusted or disabled via the iCUE software (corsair.com/downloads).
When the battery level is critical, the backlighting will automatically turn off to ensure continued usage, and will return once the keyboard is recharged.

FACTORY RESET

To reset the keyboard to factory settings, hold the ESC key while turning the keyboard on, then release the ESC key after two seconds. The keyboard will then power on normally.

CHARGING THE KEYBOARD

Connect the K63 wireless keyboard to an available USB 3.0 or USB 3.1 (Type-A) port on your PC with the USB charging/data cable. The keyboard's power LED indicator will begin pulsing green to denote battery charging and will turn solid green when charging is complete.

Connecting to a USB 2.0 port could result in reduced charging speed or connection issues.
The power LED indicator will briefly blink a color corresponding to the battery charge level when first turned on and will turn red when charging is required. The battery has no "memory effect" and should not be completely discharged before recharging to ensure it will last for hundreds of charge/ discharge cycles.
NOTE: Reducing brightness, unplugging power when charged, and not leaving the battery discharged for long periods of time will help to maximize battery life.*

*Rechargeable batteries have a limited life.

SETTING UP YOUR KEYBOARD

FOR WINDOWS^® USING 2.4 GHz WIRELESS

• Turn on your computer and K63 wireless keyboard.
• Connect the USB wireless receiver to an available USB 2.0 or USB 3.0 port on your PC and press FN + F9 on the keyboard.
• The wireless LED indicator on the keyboard will turn solid white when automatically connected.

NOTE: If the connection isn't automatic, initiate pairing mode in the iCUE software and hold FN + F9 on the keyboard until the wireless LED indicator rapidly blinks white.
For the best 2.4 GHz wireless performance, move the USB wireless receiver closer to the keyboard either by plugging it into a front panel USB port on your PC or by connecting it to the USB charging/ data cable via the USB cable adapter.

FOR WINDOWS 8/10 OR ANDROID^™ USING BLUETOOTH^®

• Turn on your Bluetooth 4.0 or higher enabled product and the K63 wireless keyboard.
• Initiate Bluetooth pairing mode on your device.
• Hold FN + F10 on the keyboard until the wireless LED indicator rapidly blinks blue.
• Input the code from your Bluetooth device on the keyboard and press the Enter key.
• The wireless LED indicator on the keyboard will turn solid blue when connected.

WIRELESS ENCRYPTION

The K63 wireless keyboard features 128-bit AES wireless encryption that is automatically enabled and works to protect the wireless transmission of your keystrokes against eavesdropping when typing sensitive login, personal, or payment information.
The Win Lock key allows you to disable the Windows key by default, but can also be used to disable wireless encryption via an option in the iCUE software for a slight reduction in latency when gaming.

FUNCTION KEYS

GETTING TO KNOW YOUR KEYBOARD

1. DEDICATED MULTIMEDIA KEYS
2. BACKLIGHT BRIGHTNESS KEY
3. WIN LOCK KEY
4. POWER LED INDICATOR
5. WIRELESS LED INDICATOR
6. CAPS LOCK LED INDICATOR
7. SCROLL LOCK LED INDICATOR
8. DEDICATED VOLUME KEYS
9. FUNCTION KEYS (F1-4, F9-12)
10. POWER SWITCH
11. USB CHARGING/DATA PORT
12. WRIST REST
13. USB WIRELESS RECEIVER
14. USB CHARGING/DATA CABLE
15. USB CABLE ADAPTER
16. RETENTION SLOTS FOR K63 LAPBOARD
    (SOLD SEPARATELY)

Read the Quick Start Guide before using this product and refer to the Warranty Guide for warranty and service information. If damage is caused by failure to follow any of the instructions or guidelines, the warranty does not apply.
CORSAIR K63 Wireless Mechanical Keyboard product name and model: Wireless Keyboard/RGP0045
CORSAIR K63 Wireless Mechanical Keyboard product name and model: Wireless Dongle/RGP0058

PRODUCT SAFETY GUIDELINES

• Use this product in accordance with the Quick Start Guide and manufacturer instructions.
• Charge this product only with the included USB charging/data cable and a USB Type-A port on your PC.
• Use and store this product in a room temperature controlled environment.
• Clean this product only with a dry cloth.
• Use this product only with manufacturer approved accessories.
• Unplug this product when unused for a long period of time or during power-related events such as a power outage or lighting storm.
• Refer this product to qualified service personnel in the event that it and/or included accessories have been damaged and/or do not function properly.
• DO NOT cover, block any ventilation openings, or use this product in a confined space.
• DO NOT use or store this product near heat sources or in direct sunlight.
• DO NOT use near or expose this product to liquids, and power it off immediately if liquids come in contact.
• DO NOT place this product on or near power cords or other electrical equipment.
• DO NOT insert foreign objects into product openings.

BATTERY SAFETY GUIDELINES

• DO NOT replace the battery with a different model.
• DO NOT use this product if the battery shows signs of damage including, but not limited to tearing, deformation, leakage, or the smell of electrolytic material.
• DO NOT touch the battery if material is leaking and seek immediate medical attention if any material comes into contact with your skin or eyes.
• DO NOT expose the battery to liquid, heat sources, electricity (outside of the product itself), or other non-standard operating condition.
• DO NOT remove the battery except for proper disposal and recycling as required by local laws and regulations.
• DO NOT impact, bend, alter, dissemble, or otherwise damage the battery as the contents are volatile, hazardous, and can be harmful.

Failing to follow all safety guidelines may result product damage, explosion, fire, and/or electric shock.

BATTERY REMOVAL INFORMATION
This product uses a rechargeable battery and safety guidelines must be followed in the event that the product is disabled for disposal and recycling. To safely remove the battery for disposal and recycling, follow the numbered steps with the below diagrams.

CORSAIR MEMORY, Inc. encourages customers to recycle used electronic hardware and rechargeable batteries in accordance with local laws and regulations.

WEB: corsair.com
PHONE: (888) 222-4346
SUPPORT: support.corsair.com
BLOG: corsair.com/blog
FORUM: forum.corsair.com
YOUTUBE: youtube.com/corsairhowto
