Valve FX Owner's Manual
• From the Program, press the <UTILITY> key once. The display
reads:
¡MIDI Contrst:4
™Foot £Tuner ≥
• Press Function key 2. The display reads:
¡Patches ™CC Ped
£PrgList Assign≥
• Press Function key 2 once. The display reads:
¡Assign Pedal CC
™Calibrate Pedal
• Press Function key 2. The display reads:
Calibrate Pedal
¡IntPed ™ExtPed
• Select whether you want to calibrate the internal (built-in) Control
One foot controller pedal or an externally connected pedal by
pressing the appropriate Function key. The display reads:
Set Pedal Down
(Forward) press¡
This step sets the maximum value of the CC pedal when it is in
the fully forward position.
• Move the pedal to its full forward (toe down) position and press
Function key 1. The display reads:
Set Pedal Up
(Back), press ™
• Move the pedal to its full back (toe up) position and press
Function key 2. When the display returns to the Utility setup
menu, you have successfully calibrated the CC pedal.
• Press the <UTILITY> key to exit to your last position in the
Program.
61
Section 5 - The Utility Menu
