Delta HDRS4100 Assembly Instructions

Multi Ball Holder
Storage Net
Assembly instructions
Parts
A
x1 — Back Plate
B
x2 — Wire Ends
C
x1 — Front Plate
D
x2 — Screws
E
x1 — Net
Tools Required
Hand Drill 1/8" (3mm)
Way of locating studs within the wall (see hardware store for advice)
Identify where wooden stud lies within wall,
1
drill pilot holes for wood screws.
IMPORTANT SAFETY NOTE
Beware of drilling into electrical wire
or pipes within wall!
Place front plate on the corner of a table/ at surface.
Position wire ends face down into slots of front plate
Slide under small center plate. (FIGURE 1).
NOTE: Be sure front of wire ends are facing down.
Insert back plate on top. Be sure wire ends are
covered and t securely between back and front
plates. (FIGURE 2)
BACK VIEW OF PLATES AND WIRE ENDS
CORNER OF TABLE SURFACE
FIGURE 1
CORNER OF TABLE SURFACE
FIGURE 2
WARNING
Do not exceed maximum total weight limit of 4.5kg/10lbs.
To avoid injury, Do not overload.
HDRS4100
Assembly video
Visit designbydelta.com/downloads
A C
B
Once assembled, transport to pre-drilled wall location.
2
Secure to wall with both screws.
STUD
After wall installation, slide net onto each arm.
3
Service:
Please do not return to store;
for immediate response email
service@designbydelta.com
D E
WALLBOARD
STUD
CENTERLINE
