NORTH STATES Toddleroo 026107046185 Manual

EXTR A-WIDE WIRE MESH GATE
Installation Instructions:
No Tools Required
Fig. A
1
Measure the width of the opening
where the gate will be used. (Fig. A)
2
While holding the gate with the locking
bar toward you (numbers will be
upright), lift the locking bar and slide
the locking pin into the slot that
matches the opening size. (Fig. B) Be
sure to adhere the wall cups (door
sockets) to the opening wall or surface
Fig. B
where the four bumpers touch.
NOTE: Be sure to place the gate so the
locking bar is on the side of the gate
that will be away from the child.
3
Push down on the locking bar. (Fig. C)
This should put pressure on the 4 rubber
bumpers holding the gate in place.
• You MUST install wall cups to keep gate
in place. Without wall cups the child can
push out and escape.
• STOP using when a child can climb over
or dislodge the gate.
• Children have died or been seriously
injured when gates are not securely
installed.
• ALWAYS install and use gates as
directed, using all required parts.
• Use only with the locking mechanism
securely engaged.
PN 2594618
N O R T H S T A T E S I N D U S T R I E S , I N C . | 5 4 5 5 H I G H W A Y 1 6 9 N , P L Y M O U T H , M N 5 5 4 4 2 | 1 . 8 0 0 . 8 4 8 . 8 4 2 1 | W W W . N O R T H S T A T E S I N D . C O M
Fig. C
• NEVER use to keep child away
from pool.
• Intended for use with children from
6 months through 24 months.
• Install with locking mechanism on
side away from child.
• This product will not necessarily
prevent all accidents. NEVER leave
child unattended.
• To prevent falls, NEVER use at top
of stairs.
If the gate is loose in the opening, move
the locking pin to the next slot until you
get a good solid fit in the opening. Do not
force the locking bar down. This could
put too much pressure on the gate,
causing damage to your opening, the
gate or both. (The locking bar will have a
slight bow. However, if the bow is large,
ease off one slot, making sure it still has a
good solid hold in the opening.)
4
To open the gate, simply pull up on the
locking bar.
29.5"
ADJ USTS 29
31"
50"
• NUNCA debe usarse para mantener a un niño
• DEBES instalar copas de pared para
alejado de una piscina.
mantener la puerta en su lugar. Sin vasos de
pared, el niño puede empujar y escapar.
• Este producto está diseñado para niños de 6 a 24
• DEJE de usarla cuando un niño pueda trepar meses de edad.
sobre la puerta o desprenderla.
• Instálela solamente con el mecanismo de
cierre/traba activado firmemente en el lado
• Niños han muerto o sufrido lesiones graves
opuesto al niño.
porque una puerta no estaba instalada de
manera segura.
• Este portón no necesariamente evita todos los
• SIEMPRE instale y use la puerta conforme a accidentes. NUNCA deje a los niños sin
supervisión.
las instrucciones, utilizando todas las piezas
requeridas.
• Para prevenir caídas, NUNCA use el portón en la
parte superior de las escaleras.
• Use sólo con el mecanismo de bloqueo y
fijación firmemente enganchado.
Care and maintenance:
To clean: Wipe with a clean, soft,
damp cloth and dry thoroughly.
Do not use harsh or abrasive
cleaners. Always keep the rubber
bumpers clean.
Discontinue the
use of the gate
if it becomes
damaged,
broken or
disassembled.
/ " TO 50"
1
2
THIS PACKAGE CONTAINS ONE PRE-
ASSEMBLED GATE AND WALL CUPS.
Due to product improvements, the actual product
styling and colors may vary.
4618A
