ECO-WORTHY FD-100W User Manual

Portable Solar Panel
1 0 0 W / 1 8 V
USER GUIDE
Technical Parameter
Rated Power
Solar Cell
Maximum/Peak Voltage(Vmp)
Open Circuit Voltage(Voc)
Short circuit current(Isc)
Maximum current
Demension(Unfolded) 94.5x62.5x3.0cm(37.2x24.6x1.2 inch)
Demension(Folded) 46.5x62.5x5.7cm(18.3x24.6x2.2inch)
Solar panel cable 3 meters，5.5*2.1mm connector
(8in 1 plug DC-DC Connector,
8 in 1 plug
DC-DC Connector - F
DC-DC Connector - J
DC-DC Connector - A
DC-DC Connector - C
DC-DC Connector - E
DC-DC Connector - H
DC-DC Connector - F
DC-DC Connector - H
Connector
DC-MC4 Connector
DC-Anderson Connector
- 1 -
Safety Tips
* Do not put the Solar Panel into fire or direct heat to it.
100W
Monocrystalline
* Do not put the Solar Panel into water or used in the rain.
18V
* Do not drop the Solar Panel from more than 1 meter,handle with
21.6V
care.
5.9A
* Do not pierce the Solar Panel casing with a nail or other sharp
5.6A
object, break it open with a hammer, or step on it.
* This product cannot contact with strong corrosive objects.
What's in box
DC-MC4 Connector,
DC-Anderson Connector)
7.86*5.75mm
7.41*5.16mm
100W Solar
6*4.3mm
5.5*2.5mm
5.5*1.7mm
5.5*3.5mm
4.8*1.7mm
DC-Anderson Connector
3.5*1.35mm
H F
5.5*2.1mm
5.5*2.1mm
Foldable Solar Panel
O U T P U T: 1 0 0 W / 1 8 V
USER GUIDE
Built-in Adjustable Kickstand Manual
DC - MC4 Connector
J
H E C A
8 in 1 plug
- 2 -
