- Page 1 400W solar panel SUPPORT If you are experiencing technical problems and cannot find a solution in this manual,please contact ECO-WORTHY for further assistance. ·Call：1-866 939 8222(US) +44 20 7570 0328(UK) +49 693 1090 113(GE) ·Email：ecoworthy.ca@gmaicom...
-
Page 2: Table Of Contents
Contents ................1 1.General safety ..............1 2.Product Introduction .............2 3.Solar Panel Installation ................2 3.1 Location ................2 3.2 Installation ..............4 4.Connection Method ........4 4.1 How to connect as a 12V system ........7 4.2 How to connect as a 24V system .............9 5.Testing and Troubleshooting ...................11 6.QA ................12... -
Page 3: General Safety
1.General safety *Do not disassemble the module or remove any attached nameplates and components from the module. *Please abide with all local, regional and national statutory regulations when installing the system or mounting on vehicles. Obtain a building permit when necessary. *Please cut off the electricity before carrying out the installation. -
Page 4: Solar Panel Installation
3.Solar Panel Installation 3.1 Location Determine a location for the solar panel that is in direct sunlight and clear of any shading by adjacent obstacles such as trees, roof over- hangs, etc. Ideally, the panels will be positioned to minimize the wiring distance between the solar panel and the charge controller. - Page 5 Step2:Mark and drill holes Mark the holes for the well-nut. Step 3: Attaching the panel to the roof Figure picture below illustrates the correct way to use the well-nut. The rubber flange has to be flush with the roofline. The Z-Bracket,along with the flat washer and lock washer, hold the well-nut in place when the screw is fastened.
-
Page 6: Connection Method
Gently insert the well nut into the drill hole . Be careful not to push the well nut flange completely into the holes. Make sure the flange is flushed on the roofline.Before attaching the panel to the roof, a film of caulk can be laid between the RV roof and the Z-Bracket. - Page 7 2.Connect the battery to the controller. First, connect the negative cable to the negative (−) battery post. The best way to secure the battery cable to the battery post is by using a ring terminal. A bolt is sufficient to secure the ring terminal onto the battery post, allowing for better electrical contact.
- Page 8 4.Connect solar panels to controller Finally, With 1 pair of solar-controller cable to connect solar panel and controller.
-
Page 9: How To Connect As A 24V System
4.2 How to connect as a 24V system (Battery not included) 4.21.Connect the battery pack(If you want to equip the kit with batteries). Firstly, use battery-to-battery cables to form the 2 batteries in series by connecting the positive terminal to the negative terminal, and the nega- tive terminal to the positive terminal. - Page 10 (Battery not included) 3.Connect panels in 2S2P To build a 24v DC solar panel kit with 4 panels, wire each two in series first, then use the Y branch for parallel connection.
-
Page 11: Testing And Troubleshooting
5.Testing and Troubleshooting Testing Test all electrical and electronic components of your system before commissioning it. Follow the instructions in the guides supplied with the components and equipment. ·Test modules connected in series before they are connected to the system. ·To determine Voc and Isc in the following tests, the module(s) must be exposed to the sun and not connected to a load. - Page 12 ·Determine the short-circuit current (Isc) of every series circuit. It can be measured directly by connecting the digital multimeter to the two termi- nals of the series circuit or module. Attention, the rated scale of the ammeter or the rated current of load should be more than 1.25 times of the rated short-circuit current of the series module.
- Page 13 6.QA Q1. Why doesn't my photovoltaic panel display charging after it is connected? A1. Check whether the photovoltaic panel wiring is correct, whether there is reverse connection, whether the photovoltaic panel voltage is higher than the battery voltage, whether the photovoltaic panel has obstructions that cause the voltage to drop, under normal circumstanc- es, please use a photovoltaic panel with a rated voltage of 18V for a 12V battery.
-
Page 14: Maintenance
(without limitations) and suggestions do not constitute a warranty, expresses or implied. ECO-WORTHY reserves the right to change the manual, the PV prod- ucts, the specifications, or product information sheets without prior notice. - Page 15 This product is covered by a 1 year warranty provided by ECO-WORTHY Ltd. We will refund or partial refund or replace any prod- ucts with defects due to our imprudence. If you are experiencing technical problems and cannot find a solution in this manual, please contact ECO-WORTHY for further assistance.
