- Page 5 Insert wooden dowel (A) into parts (3,4), secure cam bolt (B) into part (1), then using screw(Q) attach door stopper (P) to part (1) with Philips head screwdriver as per diagram.
- Page 6 Using Screw (G) attach parts (9) to part (2) ,and then turn bottom panel over up, secure cam bolt (B) into part (2) with Philips head screwdriver as per diagram.
- Page 7 Using Cam lock(C) secure parts (3,4,5) to part (2) with Philips head screwdriver as per diagram.
- Page 8 Put part (7) as per diagram.
- Page 9 Using cam lock (C) secure part (1) to parts (3,4,5) with Philips head screwdriver as per diagram.
- Page 10 Using screw (F) secure plastic wedge (E) to part (7) with Philips head screwdriver as per diagram.
- Page 11 Place sticker (D) cover the holes as per diagram .
- Page 12 Insert shelf support pin (J) into parts (3,4,5) as per diagram. Make sure you place three shelves support pins (J) in the same level. So the shelf is not titled .Put part (6) into unit as per diagram. Tilt and rest the adjustable shelf(6) onto the shelf support pins .
- Page 13 Using bolt (N) attach Europe hinge (M) into part (8) ，then using handle bolt (K) secure handle (L) to part (8) with Philips head screwdriver as per diagram.
- Page 14 Using bolt (N) attach Europe hinge (M) into part (4) with Philips head screwdriver as per diagram.
- Page 15 Using bolt (N) attach Europe hinge (M) into part (3) with Philips head screwdriver as per diagram.
- Page 16 Using screw (R) attach plastic strap (T) into part (5) with Philips head screwdriver as per diagram.
- Page 17 Using screw (S) attach plastic strap (T) into Nut (U) to wall with Philips head screwdriver as per diagram.
