TM
Holmes L-Shaped Desk
SKU#
AZHOL42OS1
Option B
For Residential Use Only
Please visit our website for the most current instructions, assembly tips, report damage,or request parts. www.walkeredison.com
Revised 12/09/2024 (D)
©
1
1
Copyright
2024 by Walker Edison Furniture Co., LLC. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Holmes L-Shaped Desk AZHOL42OS1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Walker Edison Holmes L-Shaped Desk AZHOL42OS1

Summary of Contents for Walker Edison Holmes L-Shaped Desk AZHOL42OS1

  • Page 1 Holmes L-Shaped Desk SKU# AZHOL42OS1 Option B For Residential Use Only Please visit our website for the most current instructions, assembly tips, report damage,or request parts. www.walkeredison.com Revised 12/09/2024 (D) © Copyright 2024 by Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 2 You can cause cracking or damage to the material and easily strip the hardware. If you choose to use a power tool, your product will no longer be covered under Walker Edison’s warranty. Glue is provided to secure wood dowels in place When inserting dowels, locate the appropriate hole, place a small amount of glue in the hole, and then insert the dowel.

  • Page 3: Parts List

    Parts List Part Number Description Quantity Top Cabinet Panel Left Cabinet Foot Frame Right Cabinet Foot Frame Left Cabinet Panel Right Cabinet Panel Shelf Bottom Cabinet Panel Cabinet Divider Board Cabinet Trim Panel Cabinet Back Panel Drawer Front Drawer Left Panel Drawer Right Panel Drawer Back Panel Drawer Support...

  • Page 4: Hardware List

    Hardware List Part Size Name Quantity 8x30mm Wooden dowel 6x35mm Cam bolt 15x11mm Cam lock 15x9mm Cam lock 6x50mm Bolt 6x35mm Bolt 6x25mm Bolt Hex Key M4x57mm 4x38mm Screw Drawer pull Screw 3x12mm L-shape bracket 4x12mm Screw...
  • Page 5 Hardware List Part Size Name Quantity 4x45mm Screw Plastic wedge 3x17mm Screw 12" 2 Set Drawer Glide* 12" 2 Set Drawer Glide* 30mm Sticker Glue tube The hardware quantities listed above are required for proper assembly. Extra hardware pieces may be included.
  • Page 6 Step 1 Let's get started! Insert Wooden dowels (A) into the corresponding spots in the Right Cabinet Panel (5). Then, using a Phillips head screwdriver, screw the Cabinet member side of the (T) Drawer Glides into the Right Cabinet Panel (5) using the (L) Screws.
  • Page 7 Step 2 Now, follow that same process for the Cabinet Divider Boards (8)! Insert Wooden dowels (A) into the corresponding spots in the Cabinet Divider Boards (8). Screw the Cabinet member side of the (S) Drawer Glide into each Cabinet Divider Board (8) using the (L) Screws.
  • Page 8 Step 3 Insert Wooden dowels (A) into both the Left Cabinet Panel (4) and the Shelf (6). Then, screw Cam bolts (B) into both pieces.
  • Page 9 Step 4 Making sure the finished edge of the Cabinet Divider Board (8) is facing out, secure the Cabinet Divider Board (8) to the Shelf (6) using the (E) Bolts. Tighten with the Hex key. Finished edge...
  • Page 10 Step 5 While still ensuring that the finished edge of the Cabinet Divider Board (8) is facing out, secure the Cabinet Divider Board (8) to the other side of the Shelf (6) using the (C) Cam locks. Tighten with a screwdriver! Finished edge Cam Locks Cam Locks help securely join two pieces together.
  • Page 11 Step 6 Secure the right side of the Shelf (6) to the Right Cabinet Panel (5) using the (C) Cam locks. Tighten with a screwdriver.
  • Page 12 Step 7 Now, repeat that for the other side! Secure the left side of the Shelf (6) to the Left Cabinet Panel (4) using the (C) Cam locks. Tighten with a screwdriver.
  • Page 13 Step 8 Slide one Cabinet Back Panel (10) into place using the grooves as a guide.
  • Page 14 Step 9 Secure the Bottom Cabinet Panel (7) to the rest of the unit using the (E) Bolts. Tighten with the provided Hex key.
  • Page 15 Step 10 Insert Wooden dowels (A) into each Cabinet Trim Panel (9).
  • Page 16 Step 11 Attach the Cabinet Trim Panels (9) to the Bottom Cabinet Panel (7) using the (P) Screws.
  • Page 17 Step 12 Insert Wooden dowels (A) into the Left Cabinet Foot Frame (2) and the Right Cabinet Foot Frame (3). Then, screw Cam bolts (B) into each piece.
  • Page 18 Step 13 Secure the Left Cabinet Foot Frame (2) to the Left side of the unit using the (G) Bolts. Tighten with the Hex key. Make sure to also insert the Cam locks (C) and tighten with a screwdriver.
  • Page 19 Step 14 Now, repeat that process for the other side! Secure the Right Cabinet Foot Frame (3) to the right side of the unit using the (G) Bolts. Tighten with the Hex key. Make sure to also insert the Cam locks (C) and tighten with a screwdriver.
  • Page 20 Step 15 Slide the other Cabinet Back Panel (10) into place using the grooves as a guide.
  • Page 21 Step 16 Screw Cam bolts (B) into the Top Cabinet Panel (1).
  • Page 22 Step 17 Attach the Top Cabinet Panel (1) to the rest of the unit. Secure with Cam locks (C) and tighten with a screwdriver.
  • Page 23 Step 18 Fit the Plastic wedges (Q) in between the Back Panels (10) and the rest of the unit. Secure the Plastic wedges (Q) with (R) Screws.
  • Page 24 Step 19 Secure the Drawer Left Panel (12) and the Drawer Right Panel (13) to the Drawer Back Panel (14) using the (J) Screws. Do this for both drawers.
  • Page 25 Step 20 Now, slide the Drawer Bottom (16) into place using the grooves as a guide. Do this for both drawers.
  • Page 26 Step 21 Fasten the Drawer Support (15) to the Drawer Back Panel (14) using the (J) Screws.
  • Page 27 Step 22 Screw Cam bolts (B) into each Drawer Front (11). Then, attach the Drawer pull (K) to each Drawer Front (11) using the (L) Screws.
  • Page 28 Step 23 Secure the Drawer Front (11) to the Drawer using Cam locks (D). Tighten with a screwdriver. Do this for both drawers.
  • Page 29 Step 24 Attach the Drawer member side of the Drawer Glides (S) and (T) to the drawer using the (L) Screws. T (Drawer member) S (Drawer member)
  • Page 30 Step 25 Ensure a clean finish by covering each Cam lock with the provided Stickers (U).
  • Page 31 Step 26 Insert each drawer into the cabinet. Cabinet member Drawer member...
  • Page 32 Step 27 Let’s move on to the desk! Screw Cam bolts (B) into the Desktop (17).
  • Page 33 Step 28 Attach the Desk Left Trim Panel (18) and the Desk Right Trim Panel (19) to the Desk Back Trim Panel (20) using the (J) Screws.
  • Page 34 Step 29 Insert Wooden dowels (A) into the Trim Panels (18), (19), and (20).
  • Page 35 Step 30 Secure the Desktop (17) to the Trim Panels using the (J) Screws.
  • Page 36 Step 31 Insert Wooden dowels (A) into the Back Desk Panel (23) and the Desk Bottom Trim Panel (24).
  • Page 37 Step 32 Secure the Back Desk Panel (23) to the Desktop (17) using Cam locks (C). Tighten with a screwdriver.
  • Page 38 Step 33 Attach the Desk Bottom Trim Panel (24), the Back Desk Panel (23), and the Desktop (17) to the Right Desk Foot Frame (22) using the (F) and (E) Bolts. Tighten with the Hex key.
  • Page 39 Step 34 Now repeat that for the other side! Attach the Desk Bottom Trim Panel (24), the Back Desk Panel (23), and the Desktop (17) to the Left Desk Foot Frame (21) using the (F) and (E) Bolts. Tighten with the Hex key.
  • Page 40 Step 35 Secure the L-shaped bracket (M) to the Desktop (17) and the Left Desk Foot Frame (21) using the (N) Screws.
  • Page 41 Step 36 Repeat that for the other side! Secure the L-shaped bracket (M) to the Desktop (17) and the Right Desk Foot Frame (22) using the (N) Screws.
  • Page 42 Step 37 Ensure a clean finish by covering each Cam lock with the provided Stickers (U).
  • Page 43 Step 38 Slide your finished desk on top of your finished cabinet and you’re done!

  • Page 44: Final Assembly

    Final Assembly Option B Congratulations on your new piece of furniture! We would love to hear about it and see it. Please leave us a review or post a picture with #mywalkeredisonhome...
  • Page 45 Assembling furniture can be tricky sometimes. Our customer service team, located in Utah, is here for product information, help assembling a product, or for any other customer support issue Call us at 801-433-3008 Email us at service@walkeredison.com Visit our Customer Service website at walkeredison.com/pages/customer-service We are available to help Monday -Thursday 8am-5pm, Friday 8am-3pm MST...
