Item# : AF18MXST
Assembly Instructions
Please visit our website for the most current instructions, assembly tips, report damage,
or request parts. www.walkeredison.com
Revised 04/10/2018
Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved.
P.1
Advertisement
Related Manuals for Walker Edison Sedalia AF18MXST
Summary of Contents for Walker Edison Sedalia AF18MXST
- Page 1 Item# : AF18MXST Assembly Instructions Please visit our website for the most current instructions, assembly tips, report damage, or request parts. www.walkeredison.com Revised 04/10/2018 Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 5 Insert wooden dowel (A) and bolt (E) into part (3,4). Attach bracket (D) to part (3,4) using screw (C) with screwdriver. Repeat this step. Attach part (3,4) to part (5) using screw (B) with screwdriver.
- Page 6 Attach part (3,4) to part (2) using nut (G), washer (F), and bolt (E) with wrench (H). Attach part (1) to part (3,4).
- Page 7 Secure part (1) using screw (C) with screwdriver through bracket (D). Place sticker (J) over holes as per diagram.
