To avoid electrical shock, do not use this probe
when voltages exceeding 24 V ac rms or 60 V dc
are present. The probe tip is electronically
connected to the output terminals.
Introduction
The 80PK-22 SureGrip
designed for use in liquids or gels. The probe can also be used
as a general purpose temperature probe. The thermocouple
junction is protected from tip to handle by an Inconel sheath.
The 40-inch (1 meter) cable is terminated with a Type K
miniature thermocouple connector with 0.792-mm (0.312-in)
pin spacing. The 80PK-22 can be used with any temperature-
measuring instrument that is designed to accept Type K
thermocouples and has a miniature connector input.
The 80PK-22 is not recommended for use in food or
beverage preparation. Use 80PK-25 for food
preparation.
Specifications
Type
K Standard grade Ni-Cr vs. Ni-Al (Chromel vs. Alumel)
Measurement Range
-40 °C to 1090 °C (-40 °F to 1994 °F)
Accuracy
(With respect to ANSI MC96.1-1982-Standard Limits of Error)
All error calculations should be done in °C, then
scaled to °F.
Range
-40 °C to 293 °C
(-40 °F to 559.4 °F)
293 °C to 1090 °C
(559.4 °F to 1994 °F)
November 2004 Rev.2, 9/09
© 2004-2009 Fluke Corporation. All rights reserved
All product names are trademarks of their respective companies.
SureGrip
Temperature Probe
XWWarning
TM
Immersion Temperature Probe is
Note
Note
±2.2 °C
±0.75 %
80PK-22
TM
Immersion
Instruction Sheet
Accuracy
(% of reading)
®
Advertisement
Table of Contents
Related Manuals for Fluke SureGrip 80PK-22
Summary of Contents for Fluke SureGrip 80PK-22
- Page 1 -40 °C to 293 °C ±2.2 °C (-40 °F to 559.4 °F) 293 °C to 1090 °C ±0.75 % (559.4 °F to 1994 °F) November 2004 Rev.2, 9/09 © 2004-2009 Fluke Corporation. All rights reserved All product names are trademarks of their respective companies.
- Page 2 Output @ 25 °C (77 °F) =1.00 mV (reference junction @ 0 °C) Seebeck Coefficient @ 25 °C (77 °F) = 40.50 μV / °C Measurement Time (Time Constant): 3.0 seconds in 100 °C still water at sea level pressure. Complete step change equals 5 time constants (3.75 seconds).
-
Page 3: Measurement Considerations
Some temperature measuring instruments have a built-in circuit to indicate if the connected probe is open. (All Fluke Temperature-measuring instruments have this feature.) Refer to the owners manual accompanying the measuring instrument to see if this feature is available. -
Page 4: Contacting Fluke
Use the following equation to convert °F to °C: (°F –32) x 0.5556 = °C bai01f.eps Figure 1. 80PK-22 Contacting Fluke For application or operation assistance, or information on Fluke products, call: USA: 1-888-44-FLUKE (1-888-443-5853) Canada: 1-800-36-FLUKE (1-800-363-5853) Europe: +31 402-675-200... - Page 5 ONE YEAR LIMITED WARRANTY This Fluke product will be free from defects in material and workmanship for one year from the date of purchase. This warranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
