Symcode MJ-6000Engine User Manual

Wireless 2d qr barcode scanner with stand 2.4ghz & usb wired barcode reader handhold bar code scanner for store
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MJ-6000Engine User Set Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MJ-6000Engine and is the answer not in the manual?

Questions and answers

Related Manuals for Symcode MJ-6000Engine

Summary of Contents for Symcode MJ-6000Engine

  • Page 1 MJ-6000Engine User Set Manual...
  • Page 2 Previous Versions Version Description Data V1.0 Create 2020/09/28...

  • Page 3: Table Of Contents

    Table of Contents Getting Started..........................4 Introduction........................4 About the Manual......................4 MJ-6000Set........................4 1.3.1 Set Code Enable/Disable..................4 1.3.2 Restore Factory Settings..................5 1.3.3 User default Settings...................5 1.3.4 Software version....................5 Communication Interface......................5 Serial Communication Interface..................5 2.1.1 Baud Rate Set......................6 2.1.2 Check........................

  • Page 4: Getting Started

    1 Getting Started 1.1Introduction With leading image intelligent recognition algorithm, MJ-6000bar code recognize-read module developed a set of advanced bar code read algorithms for smaller and higher version bar code recognition and read. The module combines image intelligent recognition algorithm and its chip design technology, dramatically simplifies development difficulties of bar code recognition and read products.

  • Page 5: Restore Factory Settings

    1.3.2 Restore Factory Settings This selection erases all your settings and resets the engine to the original factory defaults. Scan the Restore factory settings barcode. This will erase all previous settings and return to the engine’s factory default settings. Restore factory settings 1.3.3 User default Settings In addition, users can save the current settings as user default settings.

  • Page 6: Baud Rate Set

    mode. While using serial communication interface, parameters of both engine and Host device must be completely matched for smooth communication and correct contents. *Serial output Engine serial communication interface uses TTL-232 which is compatible with most system structures. If it is needed to use RS-232 structure, external change-over circuit is needed. Default serial communication parameters as shown in Table 2-1.

  • Page 7: Check

    38400 57600 115200 2.1.2 Check There are three kinds of checksum, including no-checksum, odd checksum and even checksum *No check Odd parity Even parity 2.2USB HIDKBW While module is connected with Host via USB cable, scan USB HIDKBW set code to configure module to standard keyboard input mode.

  • Page 8: Usb Cdc

    2.3USB CDC When module is connected with Host via USB cable and the host uses serial communication, scan USB CDC set code to be as virtual serial port. USB CDC 3 Recognize-Read Mode 3.1Trigger Mode Trigger mode is default recognize-read mode. Under the mode, after trigger key’s been pressed, engine starts to read, after read success and output, or trigger key’s been released to stop reading.

  • Page 9: Sensor Mode

    *Disable interval Enable interval Infinite 1000ms 1500ms 3000ms 3.2Sensor Mode After setting, engine starts to detect brightness of the ambient environment without being triggered. While scene changes, engine holds until the set image stabilized and starts to read. After read success and output or single read timeout, engine holds for a while (duration to be set) and restarts to detect.

  • Page 10: Image Stabilization Duration

    *Disable interval Enable interval Infinite 1000ms 1500ms 3000ms 3.2.3 Image stabilization duration Under the mode, with the detected changing scene, engine needs to hold until image stabilized before detecting the scene. Default duration is 60ms. *60ms 500ms 1000ms 3.3Continuous Mode After finish setting, engine starts to read without been triggered, after read success and output or single read, engine holds for a while (duration to be set) and starts next read automatically.

  • Page 11: Single Recognize-Read Duration

    Continuous mode 3.3.1 Single recognize-read duration Under the mode, the parameter means the max duration allowed for engine to acquire and recognize before read success. Default duration is 3.0s. *3000ms 5000ms 3.3.2 Recognize-read interval duration The parameter means interval duration between the adjacent 2 read, which is after the last read (read success or not), engine enters a do-not-read interval until next read.

  • Page 12: Lighting And Aiming

    1500ms 3000ms 4 Lighting and Aiming 4.1Lighting Light is auxiliary lighting for recognition and read, light beam on the target helps with the read performance and weak environmental lighting adaptability. Users can set status according to the application environment as below: Normal (default setting): Light on while it is shooting for recognition and read, otherwise off.

  • Page 13: Prompt Output

    No aiming Constant light 5 Prompt Output 5.1All Alert Tone Read “Enable mute” to disable all alert tone. Read “Disable mute” to disable mute. Enable mute *Disable mute 5.2Power-on Alert Tone Read “Disable power-on alert tone” to disable power-on alert tone ringing, read “Enable power-on alert tone”...

  • Page 14: Data Editing

    read “Enable set code read success alert tone” to resume set code read success alert tone. * Enable set code read success alert tone Disable set code read success alert tone 6 Data Editing 6.1Terminator Enable the function for Host to distinguish current decoding results quickly. Under serial mode, read “Add terminator”, after enable, if read success, engine adds corresponding terminator according to terminator set.
