Symcode R40 User Manual

2.4g/bluetooth wireless barcode scanner
Hide thumbs
Table of Contents

Advertisement

Quick Links

2.4G/Bluetooth Wireless
Barcode Scanner
User 's manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R40 and is the answer not in the manual?

Questions and answers

Related Manuals for Symcode R40

Summary of Contents for Symcode R40

  • Page 1 2.4G/Bluetooth Wireless Barcode Scanner User 's manual...

  • Page 3: Notice

    2.4G/Bluetooth Wireless Barcode Scanner Precautions 1.Please read the user manual carefully before using this barcode scanner. 2.The working voltage of this barcode scanner is 3.3V, charging voltage 5V. Please use our original USB cable and AC power adapter to ensure the scanner is working properly. 3.Copyright and Patent Notice Our company reserves the copyright,software copyright and sufficient patents of the ring barcode scanner and its accessories(including firmware,MR Configurator,illustration documents,...

  • Page 4: Table Of Contents

    2.4G/Bluetooth Wireless Barcode Scanner Contents 1.Notice.........................1 2.Introduction & Features..................3 3.Application & Execution Standands..............4 4.Working Conditions& Related regulations...........5 5.Appearance.......................6 6.How to use the barcode scanner..............7-8 7.How to use the pedestal.................9-10 8.Reset Configuration to Defaults+Pair with PC terminals HID bluetooth mode ..................11 9.Pull up and Hide iOS Keyboard&Caps Lock Switch........12 10.

  • Page 5: Introduction & Features

    2.4G/Bluetooth Wireless Barcode Scanner Introduction The series of barcode scanner produced by our company feature as strong light source， enhanced long-distance scanning technology. It can read the damaged,stained and poor printed barcode fast under different ambient light conditions. It is durable in use, since it is protected by the industrial safty technique. High volume buzzer is another hint of success scanning besides LED light in the noisy industrial environment.

  • Page 6: Application & Execution Standands

    2.4G/Bluetooth Wireless Barcode Scanner Application * Applicable to Business (electrical, book, clothing, medicine, cosmetics, etc.), retail industry, postal service, telecommunications industry,warehousing, logistics industry, public security system, customs systems,banking system, medical system. * Compatible with Microsoft, Android, Linux and other operating systems and bluetooth protocol * Support multi-national keyboard language Scanner Execution Standards...

  • Page 7: Working Conditions& Related Regulations

    2.4G/Bluetooth Wireless Barcode Scanner Working Conditions Working Temperature： 32°F to 104°F/0°C to 40°C Storage Temperature： -40°F to 140°F/-40°C to 60°C Humidity： 5% to 95% relative humidity (no condensation) Ruggedness: Resist about 6 times drops from 1.5m to concrete ground Ambient Light Immunity： Under normal office and factory ambient lighting conditions, or exposed to the sun won’...

  • Page 8: Appearance

    2.4G/Bluetooth Wireless Barcode Scanner Appearance Introduction Indicator light Switch Scan button Charging Ports& Data Transmission Micro USB logo Vibration Hand strap hole Indicator light Charging Ports& 2.4G receiver Data Transmission USB port Micro USB...

  • Page 9: How To Use The Barcode Scanner

    2.4G/Bluetooth Wireless Barcode Scanner How to use the barcode scanner When use the scanner alone： When using 2.4G feature,you can match desktop PCs or PC terminals that do not support Bluetooth.Scanner supports systems such as XP, Win7, Win8, Win10,etc. (Please refer to page 13th for specific pairing steps) B：...
  • Page 10 2.4G/Bluetooth Wireless Barcode Scanner When used along with the pedestal： When used with the base: A:Charge the base: Connect base with PC via USB cable, the base will work as a charger.When turn off the scanner and put it on the base, the base can charge the scanner.(Bluetooth and 2.4G mode available) B：...

  • Page 11: How To Use The Pedestal

    2.4G/Bluetooth Wireless Barcode Scanner How to use the pedestal Pedestal consists of ①② parts ① ② Two ways to use ① alone A: Place it directly on the table B:It can fix on the wall cause the botton of base has hanging holes hanging holes...
  • Page 12 2.4G/Bluetooth Wireless Barcode Scanner When ①②combined to use： A: Assemble like graph blow, the hanging holes on the back can help the pedestal hang on the wall. hanging holes Non-slip mat B： Assemble like graph blow， place its botton on the table.When scanner finishes its work, just put it on the base.

  • Page 13: Reset Configuration To Defaults+Pair With Pc Terminals Hid Bluetooth Mode

    2.4G/Bluetooth Wireless Barcode Scanner &Version Information Initialization Setting During usage,if you scan other set-up barcode by mistake and the scanning cannot perform as normal way, you can scan the initialization set-up barcode to revert. Initialization Setting Display Version Information Bluetooth Pairing Steps： Pair with operating system （Including Android、...

  • Page 14: Pull Up And Hide Ios Keyboard&Caps Lock Switch

    2.4G/Bluetooth Wireless Barcode Scanner Pull up and Hide iOS Keyboard Pull up and Hide iOS Keyboard Trigger twice to pull up iOS keyboard Trigger twice to disable iOS keyboard Caps Lock Switch Compulsory to Lower Case Compulsory to Capital No Caps Lock Switch Caps Lock Switch...

  • Page 15: Pairing Method

    2.4G/Bluetooth Wireless Barcode Scanner Pairing with 2.4G Dongle： PC terminals ,like desktop computer, which is not equipped with bluetooth,need to pair with Dongle,Dongle Pairing Steps as follow: A:Scan Dongle setup Barcode B:Scan “Compulsory Pair with Dongle Setup Barcode” so that enter into pairing state.The blue light on the left flickers quickly.

  • Page 16: Sound And Vibration Setting

    2.4G/Bluetooth Wireless Barcode Scanner Sound and Vibration Setting Select the desired to turn on/off the sound or vibration setup barcode turn off the sound turn on the sound vibration off （optional） vibration on （optional）...

  • Page 17: Sleep Time Setting

    2.4G/Bluetooth Wireless Barcode Scanner Standby time Setting Standby after 1 min Standby after 5 mins Standby after 10 mins Standby after 30 mins Never Standby Standby fastly...

  • Page 18: Language Settings

    2.4G/Bluetooth Wireless Barcode Scanner Language Settings English German French Spanish Italian Japanese Only apply for PC and output by American Keyboard...

  • Page 19: End Character Setting

    2.4G/Bluetooth Wireless Barcode Scanner End Character Setting Select the end barcode you want to add Add CR Add LF Add CR+LF Cancel CR+LF Add TAB...

  • Page 20: Transmission Speed Setting And Bluetooth Protocol

    2.4G/Bluetooth Wireless Barcode Scanner Transmission Speed Setting Select the corresponding transmission speed according to PC receiving speed. Fast Medium slow very low Bluetooth protocol bluetooth HID mode bluetooth SPP mode bluetooth BLE mode Note: Scan above barcode to enter the bluetooth searching state...

  • Page 21: Operating Mode

    2.4G/Bluetooth Wireless Barcode Scanner Operating Mode In normal mode, the scans are uploaded directly to computer via USB cable or WIFI dongle. If succeeds, barcode scannner will make a low-frequency short tone. If it fails, there willl be three low frequency short tones to alarm.
  • Page 22 2.4G/Bluetooth Wireless Barcode Scanner Upload the stored data by scanning the "Data Upload" barcode. Data Upload Note: When uploading data, please ensure the wireless signal is perfect, or upload after connecting with USB cable By scanning “Clear Data” to clear the scans in storage, the cleared scans won't be uploaded once cleared.

  • Page 23: Bluetooth Name Change Setting

    2.4G/Bluetooth Wireless Barcode Scanner Bluetooth Name Change Setting A.Scan Bluetooth Name Change Set-up Barcode： Bluetooth Name Change Set-up Barcode B.Scan the user-defined barcode of bluetooth name within 16 characters (Symbology unlimited,letter,number or symbol works). If customer wants to change the bluetooth name as you like it, you should equipped with bar code generator yourself.

  • Page 24: Hide Front And Back Characters

    2.4G/Bluetooth Wireless Barcode Scanner Hide front and back characters A : Scan” Hide front character” or” Hide back character” Setting Barcode Hide front character Hide back character B: Scan hide quantity of characters Hide 2 characters Hide 1character Hide 4 characters Hide 3 characters...
  • Page 25 2.4G/Bluetooth Wireless Barcode Scanner Hide 5 characters Hide 6 characters Hide 8 characters Hide 7 characters Note: If you want to cancel “Hide front and back characters” operation,please scan barcodes of “Hide front character” or” Hide back character” Setting Barcode...

  • Page 26: Set Prefix And Suffix Setting

    2.4G/Bluetooth Wireless Barcode Scanner Set Prefix and Suffix Setting A : Scan the "Allow for Prefix Adding" or "Allow for Suffix Adding" setting barcode Allow for Prefix Adding Allow for Suffix Adding B : Select the desired contents of prefix or suffix （ Appendix A） Note: If you want to cancel Prefix or Suffix Adding operation, please scan barcodes of “Allow for Prefix Adding”...
  • Page 27 2.4G/Bluetooth Wireless Barcode Scanner Appendix A:...
  • Page 28 2.4G/Bluetooth Wireless Barcode Scanner...
  • Page 29 2.4G/Bluetooth Wireless Barcode Scanner...
  • Page 30 2.4G/Bluetooth Wireless Barcode Scanner...
  • Page 31 2.4G/Bluetooth Wireless Barcode Scanner...
  • Page 32 2.4G/Bluetooth Wireless Barcode Scanner...
  • Page 33 2.4G/Bluetooth Wireless Barcode Scanner...
  • Page 34 2.4G/Bluetooth Wireless Barcode Scanner...
  • Page 35 2.4G/Bluetooth Wireless Barcode Scanner...
  • Page 36 2.4G/Bluetooth Wireless Barcode Scanner...
  • Page 37 2.4G/Bluetooth Wireless Barcode Scanner...

  • Page 38: Faq

    2.4G/Bluetooth Wireless Barcode Scanner What should I do if I can not pair scanner with Bluetooth devices? A.Please make sure that scanner is in the matching state under corresponding bluetooth protocol B.If the devices has connected successfully with other barcode scanner via bluetooth,or other devices.Please delete the bluetooth connection record before connecting.

  • Page 39: Buzzer And Indicator Light State

    2.4G/Bluetooth Wireless Barcode Scanner Buzzer Sound Type Description a long sound （First low then high frequency ） Means power on a long sound （First high then low frequency ） Means power off a short sound （ low frequency ） Means read barcode a short sound （First low then high frequency ）...
  • Page 40 Electric Quantity Display...
