Summary of Contents for Hoteche P805251A
-
Page 2: Table Of Contents
Table of Contents 1. Components and parts(standard delivery) ....................3 2. Instead use..............................4 3. General Safety.............................. 4 4. Specific Safety.............................. 5 5. Grounding Instructions..........................7 6. Symbols on the Machine..........................7 7. Machine Details............................8 8. Transport................................ 8 9. Install and Maintenance..........................9 10. -
Page 3: Components And Parts(Standard Delivery)
1. Components and parts(standard delivery) Front Rear 1. Upper housing door 16. Setting knob for blade tracking adjustment 2. Setting knob for band saw blade tension 17. DC Motor 3. Upper band saw wheel 18. Machine base 4. Closure housing door 19. -
Page 4: Instead Use
Keep children and bystanders away while 2. Instead use operating a power tool. Distractions can cause you to lose control. This bandsaw is suitable for cutting wood, plastics, and metals (no hard metal or hardened metal). Electrical safety Do not cut round stock transverse to its Power tool plugs must match the outlet. -
Page 5: Specific Safety
used for appropriate conditions will reduce Disconnect the plug from the power source personal injuries. before making any adjustments, changing Prevent unintentional starting. Ensure the accessories, or storing power tools. Such switch is in the off-position before connecting preventive safety measures reduce the risk of starting to power source and/or battery pack, picking the power tool accidentally. - Page 6 - NEVER OPERATE THE SAW ON THE FLOOR. COVERS, GUARDS OR BLADES, unplug the saw AVOID AWKWARD OPERATIONS and remove the switch key. HANDPOSITIONS where a sudden slip could - HOLD THE WORKPIECE firmly against the saw cause your hand to move into the blade. ALWAYS table.
-
Page 7: Grounding Instructions
frequently and use them to instruct other users. If 6. Symbols on the Machine you loan someone this tool, loan them these instructions also. Read these instructions before use! 5. Grounding Instructions General warning sign. ·This product must be grounded. In the event of a malfunction or breakdown, grounding provides a Always wear safety glasses when path of least resistance for electric current to... -
Page 8: Machine Details
· The lower blade 7. Machine Details guard(B) protects against inadvertent contact with the band saw blade, it is ACCESSORIES integrated with the table insert. ·3mm Allen key…………………1 ·4mm Allen key…………………1 · The lower blade guard must be installed during ·Push stick………………………1 operation. -
Page 9: Install And Maintenance
installations(Door, guard e.g.). ·Lift and carry the saw at the table top or housing. · Transport the saw with the help of another person. · Transport in the original packaging where possible. 9. Install and Maintenance WARNING! Start only after following preparations have been completed: ·the saw is securely mounted;... - Page 10 (e.g. band saw blade change, tensioning of the band saw blade, saw table alignment). WARNING! Turn the machine OFF and wait for the band saw blade to stop before adjusting the upper blade guide or the saw table. ·Loosen center lock knob(A) anticlockwise. Setting knob for blade tracking adjustment With the setting knob the tilt of the upper band saw...
- Page 11 The rip fence (A) is clamped to the front. The rip fence can be used on both sides of the blade. Mitre fence The mitre fence is inserted into the table slot from the table's front edge. For mitre cuts the mitre fence turns to 60° in both directions.
-
Page 12: Operation
Aligning the Upper Blade Guide& thrust bearing The upper blade guide consists of: - a thrust bearing (supporting the band saw blade from the rear), - two guide pins (providing lateral support). The bearings need to be readjusted after every band blade change... -
Page 13: Service, Clean, Storage
·Cut only one work piece at a time. · Select rip fence and table tilt for the type of cutting operation to be carried out. ·Always hold the work piece down on the table. ·Do not jam any work pieces. Hazard generated by a jamming workpiece! ·Do not try to slow the band saw blade down or When sawing with the rip fence and a tilted saw table,... -
Page 14: Environmental Protection
Cleaning the Saw · Open the housing doors. · Remove chips and saw dust with brush or vacuum cleaner. · Close the housing doors. Machine Storage Store saw where - it cannot be used or tampered with by unauthorized persons and - nobody can get hurt by the machine. -
Page 15: Troubleshooting Guide
13. Troubleshooting Guide WARNING! Before carrying out any fault service or maintenance work, always: · Switch machine OFF; · Unplug power cable; · Wait until the b`and saw blade has come to a complete stop Check to see that all safety devices are operational after each fault service. PROBLEM CAUSE SOLUTION... -
Page 16: Technical Specifications
14. Technical Specifications Voltage AC110-120V~ 50/60Hz 2A(250W) Power rating Rated no-load speed 1500 min (940 m/min, 3084 FPM) Max. cutting height 80 mm Max. Throat capacity 200 mm Dust extraction port 35 mm 6.5 mm Max. blade width Max. blade thickness 0.35 mm Table size 300x300 mm... - Page 18 Part name EN Part name EN Part name EN Screw Ball bearing Lower wheel seat lock lever Pad feet Eccentric shaft Bolt Flat washer Saw guide seat Base cap Fence fixer Set screw Cord Backing Screw Lock nut Flange bolt Saw guard(L) Teeth pulley Fence body...
