Moen Creative Specialties Brantford YB2208 Installation Instructions

Paper Holder
Stock Numbers:
YB2208BN Paper Holder
Brushed Nickel Finish
YB2208CH Paper Holder
Chrome Finish
YB2208ORB Paper Holder
Oil Rubbed Bronze Finish
Materials:
Paper Holder is constructed of zinc.
Technical Specification
Dimensions:
Installation Instructions:
Directions below are for installation into drywall. If installing product
into a stud, use the wood screws only.
1.The center to center measurement for
2.Mark this distance on the wall where you want to install the product.
3.Use a level to ensure that the pilot holes will be perfectly level.
4.
5.Position mounting posts to wall by inserting wall anchors into pilot
holes and pressing firmly. (Make sure that locking tab on mounting
post is facing down.)
6.Tighten wall anchor screw while holding mounting post firmly in
place. Tighten anchor until resistance increases. DO NOT over
tighten.
7.Using tip of screw bit press wall spikes (metal pieces on outer edge
of mounting post) into drywall.
8.Towel bar must be attached to mounting posts as a unit
towel bar into each post.
9.Attach posts by pressing firmly to mounting posts until it clicks. (The
square opening at the base of the post must be facing down to
match-up with locking tab).
Cleaning Instructions:
To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.
Stock Number:______________________Paper Holder
By Creative Specialties
2 5 3 0 0 A L MO E N D R I VE
C O R PO R A TE H E A D Q U A R TE R S : ( 8 0 0 ) 3 2 1 -8 8 0 9
I N TE R N A TI O N AL : ( 4 4 0 ) 9 6 2 - 2 0 0 0
C U S TO ME R S E R V I C E (U S A ) : 8 0 0 - 8 8 2 - 0 1 1 6
W W W . MO E N . C O M
Copyright Creative Specialties International
N O R TH O L MS TE D , O H 4 4 0 70
F A X: ( 8 0 0 ) 8 4 8 - 6 6 3 6
F A X: ( 4 4 0 ) 9 6 2 - 2 7 2 6
F A X: ( 8 8 8 ) 3 7 9 - 2 7 2 0
Literature #BA1395
