Moen Creative Specialties Eva YB2894 Installation Instructions

Eva® Technical Specification
Hotel Shelf 24"
Stock Numbers:
YB2894BN – Hotel Shelf

Brushed Nickel Finish
YB2894CH – Hotel Shelf

Chrome Finish
YB2894ORB – Hotel Shelf

Oil Rubbed Bronze Finish
Materials:
Hotel Shelf posts are constructed of
zinc. Bar is constructed of stainless
steel.
Dimensions:
Installation Instructions:
1. Remove the mounting post from the body by loosening the setscrew.
2. Position the mounting template on the wall in the desired location. Using a
level, align the template and tape it to the wall.
3. Drill pilot holes in marked location, remove template from wall
4. Attach mounting post to wall using anchors in predrilled pilot holes
5. Tighten all screws.
6. Place each post over the mounting plate with setscrew down. Tighten both
setscrews.
Cleaning Instructions:
To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.
Stock Number:______________________Hotel Shelf
By Creative Specialties
2 5 3 0 0 A L MO E N D R I V E  N O R TH O L MS TE D , O H 4 4 0 7 0
C O R P O R A TE H E A D Q U A R TE R S : ( 8 0 0 ) 3 2 1 - 8 8 0 9  F A X: ( 8 0 0 ) 8 4 8 - 6 6 3 6
I N TE R N A TI O N A L : ( 4 4 0 ) 9 6 2 - 2 0 0 0  F A X: ( 4 4 0 ) 9 6 2 - 2 7 2 6
C U S TO ME R S E R V I C E ( U S A ) : 8 0 0 - 8 8 2 - 0 1 1 6  F A X: ( 8 8 8 ) 3 7 9 - 2 7 2 0
W W W . MO E N . C O M

Copyright Creative Specialties International
YB2894
Literature #BA1479
