Winegard Wingman RV-WING Manual

WINEGARD
For use with Sensar II or III Antenna Heads Manufactured after 1990
Enhances UHF Performance. No tools required for installation. No wires to connect.
Parts Included:
(1) Wingman unit, (4) Push Rivet
NOT ALL PUSH RIVETS WILL
BE USED WITH ALL MODELS.
Installation:
NOTE: Skip steps 1, 2 & 5 for antennas
mounted to a permanent structure.
1. Allow at least 10" of clearance between the Sensar
2. Raise the Sensar antenna.
®
3. Remove the rubber bumpers from the bottom of the Sensar. This can be done with your fingers or pliers.
4. Line the holes in the Wingman up with the holes from which you removed the rubber bumpers. Gray models will not
have bumpers.
5. Insert the push rivets provided into these holes. Push the rivet tabs until they click and lock into place.
6. Lower Antenna.
