Dynacord SUB 2.18 Datasheet

Features:

• Power Handling Rated 1000 W / 4 Ohms
Peak 4000 W
• Dual 18'' EVS-18S LF Transducer
• 102 dB Sensitivity, 138 dB Maximum SPL
• Four Integrated Handles for Easy Portability
• Mounting Points to attach optional WK-C18
Wheel Kit
Wir weisen ausdrücklich darauf hin, dass bei
gehängten Lautsprecherboxen die einschlägigen
Sicherheitsbestimmungen zu beachten sind. Es
muss unbedingt qualifizierte Fachberatung in
Anspruch genommen werden!
We expressly point out that the relevant safety
regulations must be observed for "flying"
loudspeaker systems. It is imperative that quali-
fied expert advice is sought.
Technische Informationen
Engineering Data Sheet
Sub 2.18
2 x 18"
Subwoofer
Order No.
Cabinet
Configuration
Nominal impedance
Minimum Impedance
Rated Power RMS
Peak Power
Sound pressure level
SPL 1 W / 1 m
Max. SPL 1 m (calculated
with peak power)
Frequency Range (-10 dB)
Nominal Coverage Angle
(Horizontal x Vertical)
LF Transducer
Connectors
Dimensions (W x H x D)
Net Weight
Shipping Weight
Enclosure material
Grille Steel, Black Finish with Acoustic Gauze
Warranty
Optional Accessories
WK-C18
Spare Parts
LF Transducer
Sub 2.18
F01U165096
Subwoofer
Vented-Direct Radiator
4 Ohms
3.3 Ohms
1000 W
4000 W
102 dB
138 dB
35 Hz to 250 Hz
Omnidirectional
2x EVS-18S, 18 '' (457 mm) Driver
2x Neutrik Speakon NL4
Sub 1+ / 1-
Wired through 2+ / 2-
513 mm x 1200 mm x 710 mm
(20.2" x 47.2" x 28.0")
66.3 kg (146.2 lbs)
71.7 kg (158.1 lbs)
MDF with D-PUR PLUS
5 years
F01U169672
F01U105741
